Summary of Contents for Zline IGMD-ST-15
- Page 1 Installation and User Manual ICE MAKERS IGMD ST 15, IGMDP 15, ICCD ST 15, & ICCDP 15 MODELS www.zlinekitchen.com...
- Page 2 ZLINE Kitchen and Bath provides Attainable Luxury, where the kitchen and bath of your dreams is never out of reach. Through our unique designs and unparalleled quality, we’re dedicated to providing you an elevated experience in the heart of your home. With an endless selection of...
- Page 3 ZLINE is fueled by a passion for innovation; A relentless pursuit of bringing the highest end luxury designs and professional features into everyone’s homes. Because we continually strive to improve our products, we may change specifications and designs without prior notice.
-
Page 4: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ........1 Power Cord Precautions . -
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS • IMPORTANT: Read all instructions before using this appliance. Use this appliance only for its intended purpose as described in this manual. Always exercise basic safety precautions, as described below. After reading this manual, store it in an accessible place where users and services can easily reference it. - Page 6 IMPORTANT SAFETY INSTRUCTIONS Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. WARNING Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. WARNING Do not damage the refrigerant circuit.
-
Page 7: Power Cord Precautions
IMPORTANT SAFETY INSTRUCTIONS POWER CORD PRECAUTIONS • Do not use the appliance if the power cord is damaged. If the power cord is damaged, have a qualified electrician replace the power cord. • Never lift, carry, or drag the appliance by the power cord. •... -
Page 8: Installation Precautions
• Disconnect the unit if it is behaving abnormally, and do not reconnect until the situation is corrected. If normal troubleshooting measures do not work, contact ZLINE at 1-614-777-5004 for assistance. -
Page 9: Moving Precautions
The plug should always be accessible. • Never use an appliance with a damaged cooling system. If system is damaged upon arrival, contact ZLINE at 1-614-777-5004. DISPOSAL The appliance cannot be treated as normal domestic trash and must be disposed of at a collection point for recycling electric and electronic appliances. -
Page 10: Other Precautions
IMPORTANT SAFETY INSTRUCTIONS OTHER PRECAUTIONS • To ensure proper ventilation for the appliance, keep obstructions away from the front of the unit. • Keep fingers out of the “pinch point” areas. Clearances between the door and cabinet are necessarily small. Be careful closing the door when children are in the area. •... -
Page 11: Before Installation
BEFORE INSTALLATION PRODUCT SPECIFICATIONS NOTE: Technical data and performance information are provided for reference only and subject to change. Model ICCD-ST-15 & ICCDP-15 IGMD-ST-15 & IGMDP-15 Image Electrical requirements 1 15VAC/60Hz Maximum amp fuse 15 amps Indoor/outdoor* *The unit cannot be directly exposed to water or elements such as snow Indoor/Outdoor or ice. -
Page 12: Before Using Your Ice Maker
BEFORE INSTALLATION BEFORE USING YOUR ICE MAKER INCLUDED PARTS DESCRIPTION IMAGE QUANTITY Ice scoop Installation and user manual Installation Manual ICE MAKERS IGMD ST 15, IGMDP 15, ICCD ST 15, & ICCDP 15 MODELS www.zlinekitchen.com Anti-tip brackets Screws for anti-tip brackets Foot adjustment wrench *Door limiting pins **Screws for custom panel installation... -
Page 13: Installation
INSTALLATION PLUMBING AND ELECTRICAL TIPS • A licensed plumber must install this appliance. • This appliance must be installed with all electrical and water connections in accordance with state and local codes. • This unit requires a standard electrical supply properly grounded in accordance with National Electrical Code and local codes and ordinances. -
Page 14: Built-In Installation
INSTALLATION BUILT-IN INSTALLATION A built-in installation will allow you to install the ice maker under a counter or in a kitchen cabinet if you follow the required clearance space around the clear ice maker. The appliance must be located in a manner that allows clearance for water, drain, and electrical connections in the rear of the unit. -
Page 15: Leveling The Unit
1. Check the power cord and make sure it is not plugged into the outlet. 2. Place the drain hose into a suitable container that can hold at least one gallon. 3. Pour one gallon of water into the ice storage bin. INSTALLATION 4. -
Page 16: Installing The Anti-Tip System
INSTALLATION INSTALLING THE ANTI-TIP SYSTEM 1. With built-in installations, once you’ve determined the appropriate height and have ensured the appliance is level, position the unit at the front of the cutout to install the anti- tip system, which is necessary to reduce risk of tipping. 2. -
Page 17: Electrical Shock Hazard
INSTALLATION ELECTRICAL SHOCK HAZARD WARNING Always disconnect power at the source before working on the unit. Failure to unplug the ice maker could result in electrical shock or personal injury. • Do not touch the power plug when your hands are wet. •... -
Page 18: Filter Installation/Replacement
INSTALLATION FILTER INSTALLATION/REPLACEMENT The water filter must be installed in accordance with manufacturer's recommended procedures and guidelines to reduce the risk associated with property damage due to water leakage. You must read and follow installation and use instructions before installation and use this product. -
Page 19: Electrical Connection
INSTALLATION ELECTRICAL CONNECTION Do not, under any circumstances, cut or remove the third (ground) prong from the power cord. For personal safety, you must properly ground this appliance. The power cord of this appliance features a three-prong grounding plug that mates with a standard three-prong grounding wall outlet to minimize the possibility of electric shock hazard from the appliance. - Page 20 INSTALLATION DRAIN PUMP TIPS ELECTRICAL SHOCK HAZARD Be sure the floor surfaces surrounding the appliance are dry before plugging in WARNING and removing the power cord to the outlet to prevent electrical shock. Follow these steps to test the operation of the drain pump before final installation: 1.
-
Page 21: Reversing The Door
INSTALLATION REVERSING THE DOOR This appliance has the capability of the door opening from either the left or right side. The appliance is delivered to you with the door opening from the left side. Follow these instructions should you desire to reverse the opening direction. REVERSING THE DOOR This appliance has the capability of the door opening from either the left or right side. -
Page 22: Door Swing
INSTALLATION DOOR SWING All units come with doors installed at the pre-set maximum door swing of 135°. If you desire to limit the door swing to 90°, insert the 2 provided door limiting pins into the pin hole on the top and bottom door hinges, as show in the image below. Door Limiting Pin Location DOOR HINGE TIGHTENING The appliance’s door hinges may loosen over time, which is normal with regular use. -
Page 23: Handle Installation
Prior to installing a custom panel, handle(s) need to be affixed to the panel first. If you wish to install a ZLINE Autograph Edition handle onto your custom panel, reference the measurements displayed in the diagrams below regarding where to affix the mounting studs. -
Page 24: Custom Panel Installation - Models Igmdp-15 And Iccdp-15
INSTALLATION CUSTOM PANEL INSTALLATION - MODELS IGMDP-15 AND ICCDP-15 A custom door panel/frame can be fabricated for the appliance. Handle hardware must also be provided, if needed. Finish all sides of the custom panel. They may be visible when the door is open. NOTE: Hole pattern dimensions for blind pilot holes only. - Page 25 (3 mm~4 mm) INSTALLATION 14" (356 mm) 14 3/4" (374 mm) NOTE: When finishing the grill/plinth, be sure to stain front, back and all edges to prevent warping. INTEGRATED GRILL/PLINTH An integrated grill/plinth can be fabricated, if desired. The thickness of the panel should Apply double-sided tape to the surrounding edges of the integrated grill/plinth as shown in figure.
-
Page 26: Operation
Once start, window display and the clean indica Cleaning will light, the clean cycle will run for 30 minuets and the to standby. OPERATION *This function can only start on standby. Press and hold UP and CLEAN over 6 seconds to turn ON/OFF the SATTBATH. - Page 27 Notes: The Gourmet Ice - Similar Principle applies for the Gourmet Ice. For level 1 - 6, it creates a more For IGMD-ST-15 & IGMDP-15 models, the hollow shape inside each cube will increase or less Hollow Variation - that increases or decreases the volume of Ice.
- Page 28 ON/OFF the screen lock. water filter life counter. Screen Lock The control panel is located at the top of the cabinet. Including a display window, 4 buttons and 6 DOWN DISPLAY WINDOW DISPLAY WINDOW POWER POWER CLEAN DOWN CLEAN The window will be flashing and reset the filter The Screen lock indicator will light up and the screen are indicators.
- Page 29 When enter the timer setting, press UP or DOWN to select SATTBATH. Once start, window display and the clean indicator unter. Cleaning Once start, window display and the clean indicator from hours to set the timer to run ice making, be shut off, and the interior light and any audible Cleaning Press and hold POWER and CLEAN over 3 seconds on...
-
Page 30: Panel Display Notification
• Rattling noises may come from the flow of the refrigerant or the water line. Items store on top of • Rattling noises may come from the flow of the refrigerant or the water line. Items store on top of •... -
Page 31: Ice Production
IGMD-ST-15 & IGMDP-15 - The ice maker will continue to produce ice until the ice in the bin contacts the fill indicator in the bin. Once the ice level drops below the fill indicator, the ice maker will continue to produce ice. -
Page 32: Care And Maintenance
CARE AND MAINTENANCE CLEANING AND MAINTAINING THE UNIT Perform periodic cleaning and proper maintenance to ensure efficiency, top performance, and long life. Maintenance should be performed every 3 to 12 months depending on usage and environment: • Regularly inspect plumbing connections to ensure that no leaks exist. •... - Page 33 CARE AND MAINTENANCE Failure to regularly clean and maintain your ice maker may result in component Press and hold POWER and CLEAN over 3 seconds on failures or damage, which will void your warranty. Standby to toggle ON/OFF the Timed Ice Making NOTICE When enter the timer setting, press UP or DOWN to select from...
-
Page 34: Extended Periods Of Non-Use
CARE AND MAINTENANCE POWER FAILURE PROCEDURES Most power failures are corrected within a few hours and should not affect the temperature of your ice maker if you minimize the number of times you open the ice maker door. If the power is going to be off for a longer period of time, take the proper steps to disconnect your appliance. -
Page 35: Starting Up The Unit
CARE AND MAINTENANCE RECOMMISSIONING THE UNIT 1. If stored outside, it is recommended that the unit be thoroughly inspected to remove any dirt or debris as well as for animals/insects. NOTE: The unit cannot be directly exposed to water or elements such as snow or ice. 2. -
Page 36: Troubleshooting
TROUBLESHOOTING going to be off for a longer period of time, take the proper steps to disconnect your appliance. going to be off for a longer period of time, take the proper steps to disconnect your appliance. BEFORE CALLING FOR SERVICE going to be off for a longer period of time, take the proper steps to disconnect your appliance. - Page 37 Check that the water filter is installed (Possible error installed or not installed correctly. codes E4/E5) correctly. Water inlet valve Contact ZLINE Customer Service at malfunction. 1-614-777-5004 for assistance. The condenser Clean the condenser. may be dirty. Machine makes The air flow to the ice...
- Page 38 Restart the machine after turning it off. sticking together. The refrigerant leaks and/ Contact ZLINE Customer Service at or the sealed system 1-614-777-5004 for assistance. Conditions for is blocked. ice making cycle...
- Page 39 TROUBLESHOOTING ISSUE POSSIBLE CAUSE POSSIBLE SOLUTION Reconnect the power supply line. The electricity is off. The ice maker stops Cut off the electricity and let the suddenly while ice maker stop working until the The room temperature is making ice. temperature returns within the out of the stated range.
-
Page 40: Warranty
WARRANTY COVERAGE ZLINE Kitchen and Bath ("ZLINE") ice makers have a two year parts and service warranty and a five year parts warranty on the unit's sealed cooling system. ZLINE warranty periods begin from the original date of product delivery and solely cover the original purchaser of the product, delivered new and in its original carton. - Page 41 If a product qualifies within the service window provided under these warranty terms, and ZLINE is unable to repair the product or a defective part of the product after a reasonable number of attempts, ZLINE reserves the right to offer to replace the defective part or the...
-
Page 42: Serial Number Location
Always check the ZLINE website for the most up-to-date version of its product manuals: www.zlinekitchen.com/pages/manuals. Do not install or operate any ZLINE product if it has missing or broken parts or if it arrives damaged due to shipping. If ZLINE products arrive damaged, contact ZLINE Customer Experience at 1-614-777-5004 for help. - Page 43 Customer Experience Portal. Scan the QR code to view the most up-to-date version of our Installation Manual and User Manual. Need to purchase a part or accessory for your ZLINE product? Visit www.zlineparts.com, ZLINE’s official parts distribution partner.
- Page 44 1.3.1 1-614-777-5004 www.zlinekitchen.com contact@zlinekitchen.com...
