- Page 1 VeSTIMs ® Pressure Off 8955P MRS Instructions for Use For use by clinicians Read the instr uctions in this booklet thor oughly pr ior to use. IM POR TAN T! Keep these instr uctions for future r efer ence.
-
Page 2: Table Of Contents
Guidance and manufacturer’s declaration – electromagnetic emissions ______________________________ 37 11.2 Guidance and manufacturer’s declaration – electromagnetic immunity ______________________________ 38 12. VeSTIMs System: Weekly Checklist _______________________________________________ 41 13. Contact Squirrel Medical _______________________________________________________ 43 Page 2 of 44 8955-P Copyright Squirrel Medical ®... -
Page 3: Introduction
1. Introduction Foreword Thank you for purchasing a Squirrel Medical VeSTIMs Mattress Replacement System. In doing so, you have chosen a quality MRS which has been designed to provide excellent functionality in a safe manner. To ensure the MRS is always operated correctly and safely please read this document thoroughly and strictly follow all the assembly, operating, cleaning and maintenance instructions. -
Page 4: Product Models & Swl
VeSTIMs Mattress, 120cm This is identical to the standard supplied mattress with the VeSTIMs MRS, but VES120200 30cm wider. Size: W 118cm x L 198 cm x D 15cm Page 4 of 44 8955-P Copyright Squirrel Medical ® 2018 - E&OE... -
Page 5: Warning Symbols
Warning Symbols WARNINGS given in this manual identify possible hazards in procedures or conditions, which if not correctly followed, could result in death, injury or other serious adverse reactions. Cautions given in this manual identify possible hazards in procedures or conditions, which if not followed, could result in equipment damage or failure, and indicate moderate risk. -
Page 6: Intended Use
2. Intended Use The Squirrel Medical Active Mattress Systems are intended to be used as an aid to assist in the managed treatment and prevention of pressure ulcers when used in conjunction with a patient care plan and/or pressure ulcer prevention program and must not be considered or relied on as an independent curative device. -
Page 7: General Warnings
General Warnings WARNING: DO NOT modify your VeSTIMs System, its components or any of its accessories in any way; doing so could result a potential hazard. Do not use mattress transfer mode with a patient in the bed. The transport mode is designed to transport a semi inflated mattress NOT a patient. Do not use as an overlay. - Page 8 WARNING: Prior to use of bed side rails, rely on clinical judgment and MHRA / HSE bed rail risk assessment guidance. WARNING: Only the designated VeSTIMs System pump and mattress combination should be utilized to guarantee the product's correct function. Page 8 of 44 8955-P Copyright Squirrel Medical ® 2018 - E&OE...
-
Page 9: General Product Description
3. General Product Description The VeSTIMs System The VeSTIMs System provides active therapy for the managed prevention and treatment of pressure ulcers. It is scientifically shown to promote endothelial function, enhance skin blood flow, and boost overall skin health and functionality when utilized in its standard alternating mode. This is achieved by automatically applying and then relieving pressure on the skin tissue through a research-based approach. -
Page 10: Product Description
VeSTIMs PressureOff Pump VeSTIMs PressureOff Pump Unit Air Filter Control Panel Pump Hooks Tube Set Connector Socket Mains Cable Socket Fuse Holder Serial Number Labels Carry Handle Service Port (USB) Page 10 of 44 8955-P Copyright Squirrel Medical ® 2018 - E&OE... -
Page 11: Identification Of Mattress Components
3.2.2 Identification of Mattress Components VeSTIMs Mattress Mattress Top Cover Tubeset Connector Plug VeSTIMs Stacked Air Cells Transport Cap Mattress Base Straps & Buckles (underside of mattress) Tubeset Cable Guide Strap July 2024 Issue 7.0 Page 11 of 44... -
Page 12: Installation
Before putting the VeSTIMs System into service for the first time, the Instructions for Use must be read conscientiously and in detail by the User / Care personnel. Page 12 of 44 8955-P Copyright Squirrel Medical ® 2018 - E&OE... - Page 13 Fit the M attress Foot Hea d Cor r ect M attr ess or ientation on a B ed Position the Mattress onto the bed with the tube set towards the foot end of the bed. Also, the print on the mattress should be face up, with the image of ‘feet’ towards the foot end. ...
- Page 14 Doing so and raising a bed will pull the tubes apart and damage your unit. ALWAYS route any cabling around the sides of the bed, or above the castors Page 14 of 44 8955-P Copyright Squirrel Medical ® 2018 - E&OE...
-
Page 15: Setup Complete
Check M attr ess Assem bly Ensure that the mattress cover is zipped into place. There are zips all the way around the mattress cover, and they should all be fastened. Setup Complete! Plug the pump into a power socket ensuring that electric cables are routed so they do not pose a trip hazard. -
Page 16: Vestims Pressureoff Operation
The Power Failure Alarm sounds when the mains supply is interrupted. The Power Failure Alarm must be tested at least once per year, and also after any prolonged period of storage before commissioning the Pump for use. Page 16 of 44 8955-P Copyright Squirrel Medical ® 2018 - E&OE... -
Page 17: Vestims Pump8955P Controls
VeSTIMs PUMP8955P Controls CONTROL Pressing the power button will toggle the pump on & off. The green Power light will illuminate when the pump is running. Used to mute audio alarm and clear warning lights. Alarm Mute SYSTEM STATUS Flashing: System start-up / Automatic Adjustment Ready Light Solid: System ready for use. -
Page 18: Initial Startup
There has not been a general power cut to the building, apartment or room. • Resuming operation after power loss Once the power is reconnected, the pump will re-run start-up checks. Page 18 of 44 8955-P Copyright Squirrel Medical ® 2018 - E&OE... -
Page 19: Low Pressure Alarm
The ready light will flash while this process is underway. When start-up checks have completed, the Ready light will stop flashing and remain lit. Note: If the pump had the Egress Alert feature activated when the power was interrupted, Egress Alert mode will be cancelled. It can be re-activated by holding the Egress Alert button down for 3 seconds once the pump has completed its start-up sequence. -
Page 20: Alarm Mute
The transfer mode must not be used if a patient is using the mattress. Disconnect the Tubeset connector from the pump and attach the transport cap into place. Page 20 of 44 8955-P Copyright Squirrel Medical ® 2018 - E&OE... -
Page 21: Storage & Transport
6. Storage & Transport When storing the Pump and Mattress, following the guidance below will help to ensure the working life of your VeSTIMs System. Also see 10 - Technical Specifications, page 34. Before the VeSTIMs System is stored or transported, please ensure all components are; Thoroughly cleaned and are fully dry ... -
Page 22: Cleaning And Decontamination
VeSTIMs System, use detergent/disinfectant on a damp cloth only. Do not use phenol-based disinfectant solutions. Never attempt to clean a VeSTIMs System while there is a patient occupying it. Excessive heat can damage the cover Page 22 of 44 8955-P Copyright Squirrel Medical ® 2018 - E&OE... -
Page 23: Cleaning The Mattress
Cleaning the Mattress Whilst cleaning the Mattress, it is always good practice to look for signs that the VeSTIMs System may have been damaged or is requiring service. Such indicators include (but are not limited to) rips or tears, air bubbles appearing as you wipe Air Cells, signs of fluid ingress into the interior of the Mattress or damaged components. - Page 24 M ax tem p Cover must be completely dry before zipping back on to the mattress. Dr y Do Not Iron Tumble Dry at 40 Do Not Dry Clean Page 24 of 44 8955-P Copyright Squirrel Medical ® 2018 - E&OE...
-
Page 25: Cleaning The Pump
Cleaning the Pump Disconnect the VeSTIMs Pump from the main electricity supply. Wipe all surfaces of the Pump with a solution of sodium dichloroisocyanurate (NaDCC) at a concentration of 1,000 parts per million (0.1%) of available chlorine using a soft cloth. Wipe down all surfaces of the Pump with mild detergent on a damp cloth ... -
Page 26: Routine Maintenance
Do not continue to use a Pump if you find or suspect any damage to the Mains Cable. Incompatible parts can create hazards; only use Squirrel Medical parts approved for use with your VeSTIMs System. Any faults, defects, damage or excessive wear must be dealt with immediately or... -
Page 27: Spare Parts
A full service of the VeSTIMs System should be performed by Squirrel Medical or by suitably qualified and trained personnel at least once per year or; • after long periods of inactivity if a fault or damage has been found with the VeSTIMs System •... -
Page 28: Changing The Air Filter
Replace the Air Filter Door. When it is correctly fixed, you should hear the arm ‘click’ into place. Reconnect the Tubeset and Mains Cable, and test the system Warning! Never open the VeSTIMs Pump Casing Page 28 of 44 8955-P Copyright Squirrel Medical ® 2018 - E&OE... -
Page 29: Changing The Fuse
Changing the Fuse To change a fuse, you will need the following; Flat Blade screwdriver Spare Fast Blow Fuse To Change a Fuse Disconnect the Pump from the mains supply Disconnect the Tubeset and position the Pump unit so you have easy access to the fuse holder. -
Page 30: Replacing Mattress Cover
It is essential to de-commission this Pump/Mattress in line with national and local laws and regulations. The mattress cover, mattress base and pump must be cleaned with disinfectant before disposal Page 30 of 44 8955-P Copyright Squirrel Medical ® 2018 - E&OE... -
Page 31: Warranty
Disposal of Electrical Equipment Contact Squirrel Medical for advice on disposal of the VeSTIMs System. Warranty The warranty of the Squirrel Medical VeSTIMs System shall be as detailed in the terms and conditions of the sale. Product Returns Contact Squirrel Medical for advice on product returns. -
Page 32: Troubleshooting
Press ‘Mute’ button. flashing has been interrupted System has Ensure underlying problem is resolved, Low Pressure light experienced a low and press ‘Mute’ button. flashing pressure alarm Page 32 of 44 8955-P Copyright Squirrel Medical ® 2018 - E&OE... - Page 33 Deactivate Egress Alert feature. light flashing Pump requires Contact Squirrel Medical Service Light lit service If all points in the table above have been addressed but the fault persists, or a puncture has been found, then the VeSTIMs® System will require servicing.
-
Page 34: Technical Specifications
+10°C / +40°C Temperature 10% - 90% non-condensing Relative Humidity 900 -1013.25hPa Atmospheric Pressure Mattress cover material tested and in compliance with EN Flam m ability 597-1:2015 & EN 597-2:2015 Page 34 of 44 8955-P Copyright Squirrel Medical ® 2018 - E&OE... -
Page 35: Standards
To isolate unit from Mains Supply; switch off at wall socket and remove plug. In the event of a serious incident occurring in relation to the Squirrel Medical VeSTIMs System: Report the event and details of the occurrence immediately to Squirrel Medical for further assessment (e-mail sales@squirrelmedical.com / Telephone 0044 (0)845 003... - Page 36 EN ISO 10993-1 Biological evaluation of medical devices - Part 1: Evaluation and testing within a risk management process • EN ISO 20342-1 Assistive Products for Tissue Integrity when lying down - Part 1: General requirements. Page 36 of 44 8955-P Copyright Squirrel Medical ® 2018 - E&OE...
-
Page 37: Appendix
11. Appendix The VeSTIMs 8955-A and PUMP8955P pumps are EMC compliant (emissions & immunity) 11.1 Guidance and manufacturer’s declaration – electromagnetic emissions July 2024 Issue 7.0 Page 37 of 44... -
Page 38: Guidance And Manufacturer's Declaration - Electromagnetic Immunity
11.2 Guidance and manufacturer’s declaration – electromagnetic immunity Page 38 of 44 8955-P Copyright Squirrel Medical ® 2018 - E&OE... - Page 39 July 2024 Issue 7.0 Page 39 of 44...
- Page 40 Page 40 of 44 8955-P Copyright Squirrel Medical ® 2018 - E&OE...
-
Page 41: Vestims System: Weekly Checklist
12. VeSTIMs System: Weekly Checklist This page can be removed and kept by the maintenance personnel. Inspect Mains Cable & Tubeset for any signs of damage, and ensure they are correctly routed out of harm’s way. Check legibility of all labels & instructions ... - Page 42 Page 42 of 44 8955-P Copyright Squirrel Medical ® 2018 - E&OE...
-
Page 43: Contact Squirrel Medical
13. Contact Squirrel Medical Sales & Technical Support Web: www.squirrelmedical.com Email: sales@squirrelmedical.com Tel: 0044 (0)845 003 7979 Address: Squirrel Medical ® Ltd. Unit 14, Trevol Business Park, Trevol Road, Torpoint, Cornwall, PL11 2TB July 2024 Issue 7.0 Page 43 of 44... - Page 44 0845 003 7979 ® Squirr el M edical Ltd. Unit 14, Tr evol Business Par k , Tr evol Road, Tor point, Cornwall, PL11 2TB Page 44 of 44 8955-P Copyright Squirrel Medical ® 2018 - E&OE...
