- Page 1 7-INCH QUAD Input “S” SYSTEM Part # SMQ7S Please read this manual completely before operating the SYSTEM A division of Component Solution Services, LLC. 56600 Twin Branch Dr., Mishawaka, IN 46545 www.VeritySafe.com Verity © All rights reserved 2021-Current...
- Page 2 ABOUT US Component Solution Services LLC. engineers the ® Verity products to meet any requirements and price point within the commercial and fire rescue industries. Designed for professional drivers, Verity develops and markets products and applications to transmit video, ®...
- Page 3 THINK Read our manual before operating or installing this system. SAFETY Most likely, your system came pre-installed so the installation section would be for reference. Thank you for your purchase of our Verity Rear Vison System SMQ7S. When installed and used properly, your SMQ7S is designed to deliver you years of trouble-free operation.
- Page 4 WARNING Do not place heavy objects on cables or cover them with carpet or mats. Do not place cables where they can be crushed in any manner. Our systems are designed as a driving aid. Watching videos, broadcasts, DVDs and/or any images other than intended driving assistance cameras is prohibited.
-
Page 5: System Features
SYSTEM FEATURES MONITOR SPECIFICATIONS (Monitor part # MKQ7S) • Screen size: 7-in 800 × 480 Pixel (RGB) • System: PAL/NTSC (automatic) • Brightness: 300 cd/m2 • Power supply: DC 12V~24V with reverse polarity protection • Operation temperature: -20°~70°C • Storage temperature: -30°~70°C •... -
Page 6: System Components
SYSTEM COMPONENTS 7-Inch digital Quad Multiplex LCD monitor Manual Weatherproof Camera 20-Meter with night vision Camera Cable 18-pin to 4-pin Monitor Fan Style Mount Harness... - Page 7 SYSTEM COMPONENTS This monitor can be mounted on the dash and also on horizontal and vertical surfaces. Make sure the view is suitable for the driver to observe the images. Take care not to block any necessary viewing area when mounting. Before mounting the system, permanently hook up all connections to ensure proper operation.
-
Page 8: Cable Connections
CABLE CONNECTIONS Fuse Chassis Ground CAM 1 Camera one trigger wire CAM 2 Camera two trigger wire CAM 3 Camera three trigger wire CAM 4 Wire Connection Key: wire to ignition hot (+) 10-26 volts BLACK wire to ground (-) (please use a chassis ground post) ... -
Page 9: Monitor Operations
MONITOR OPERATIONS Buttons from left to right 1. Menu Control Button 2. Channel 1 / decrease 3. Channel 2 / increase 4. Power Off/On button - Red color is stand-by- Blue is powered 5. Channel 3 / down movement 6. Channel 4 / up movement 7. -
Page 10: Menu Operations
MENU OPERATIONS The menu button operates the menu options: Depress menu repeatly to scroll down options. The down (CH3) and up (CH4) arrow buttons move within the menus. CH1 controls decrease, and CH2 options increase. Screen 1: BRIGHTNESS, CONTRAST, and COLOR, displayed on screen Brightness, Contrast, and Color have a value of 1-40 that come factory-set at 20, the mid-range. - Page 11 SCREEN 2: LANGUAGE The default language is English. There are seven options: English, Chinese, French, Deutsch, Italian, Spanish, and Portuguese. ROTATION Rotates the image as needed AUTO DIM Turns off/on auto-dimming LANGUAGES ENGLISH ROTATION AUTO DIM SCREEN 3: VOLUME VOLUME...
- Page 12 SCREEN 4: MIRROR CAMERA1 CAMERA2 CAMERA3 CAMERA4 SCREEN 5 : CLOCK Sets the time a camera stays on after a trigger is turned off. This setting is helpful with side camera functions. CAMERA1 CAMERA2 CAMERA3 CAMERA4 More layout options by using MODE button...
-
Page 13: System Dimensions
SYSTEM DIMENSIONS... - Page 14 Verity® A division of COMPONENT SOLUTION SERVICES (CSS) LIMITED One (1) YEAR WARRANTY 1. CSS products’ warranties are not transferable. They apply to the consumer for one (1) year and cover defects in material and workmanship. We do not warranty our cables, which are QC tested at three different stations before shipping.
- Page 15 Component Solution Services 56600 Twin Branch Drive Mishawaka, IN 46545 574-807-6002 Toll-Free 844-875-4799 We at Verity would like to personally thank you for purchasing our product.
