Operation; Specification - Haier HDN655E - 65 Pint Capacity Dehumidifier User Manual

English

OPERATION

1. Press "ON/OF" button to begin unit operation and press the button
again to stop it.
2. If "Set Humidity" level is lower than the "Current Humidity" level, the
compressor will start up and unit will begin dehumidification.
If "Set Humidity" level is higher than the "Current Humidity" level, the unit's
fan will continue to run.
3. To change the set humidity level, press the " " or " " to adjust the
humidistat in 5% increments between 30% and 90%.
4. For auto Switch Off when the unit is running, press "Timer" button to set unit to
shut off automatically in 1-12 hours.
5. For auto switch On, make sure the machine is in standby mode with
power cord plugged in securely. Press "Timer" button to set unit to start
automatically in 1-12 hours.
6. Press "Speed" button to change the fan speed from "Low" to "High".

Specification

Model
Power
Moisture Removal
Power Input
Size of Shell
(H x W x D)
Weight
Operating
Temperature
7
HDN455E
45 Pints/Day (80°F/26.7°C,60% RH)
520 W
23-1/32" x 14-31/32" x 12-19/32"
35.3 lbs/16.0 kgs
AC 115V~60 Hz
65 Pints/Day (80°F/26.7°C,60% RH)
(585 x 380 x 320 mm)
41°F - 95°F (5°C - 35°C)
HDN655E
740 W
38.6 lbs/17.5 kgs
