S-Track HIPPO D1608 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HIPPO D1608
Digital Mixer
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HIPPO D1608 and is the answer not in the manual?

Questions and answers

Related Manuals for S-Track HIPPO D1608

Summary of Contents for S-Track HIPPO D1608

  • Page 1 HIPPO D1608 Digital Mixer User Manual...

  • Page 2: Symbol Conventions

    HIPPO D1608 Digital Mixer Preface The purpose of this section is to ensure that the user is able to use the product correctly through this manual in order to avoid danger in operation or property damage. Before using this product, please read the product manual carefully and keep it for future reference.
  • Page 3 HIPPO D1608 Digital Mixer  Keep the working environment well ventilated so that the heat generated by the equipment at work can be discharged in time to avoid damage to the equipment due to high temperature.  Always unplug the unit's AC power cord from the AC power outlet before: A. Removing or reinstalling any part of the unit;...
  • Page 4 HIPPO D1608 Digital Mixer Qualifications or experience in the installation and commissioning of audio and video systems and qualifications to perform related work, in addition to the knowledge and operational skills listed below. − Basic knowledge and installation skills of audio and video systems and components.

  • Page 5: Table Of Contents

    HIPPO D1608 Digital Mixer TABLE OF CONTENTS Chapter 1 Product Introduction ......................1 1.1 Introduction ........................1 1.2 Product Features ........................ 1 1.3 Functions ..........................1 Chapter 2 Specification ........................2 Chapter 3 Interface/Keypad Description ..................... 4 3.1 Front Panel ......................... 4 3.2 Rear Panel ..........................
  • Page 6 HIPPO D1608 Digital Mixer 4.6.4 FX AUX Sends ......................25 4.6.5 Effects ........................26 4.7 Playback/Recording ......................31 4.8 Other Functions ....................... 32 4.8.1 Menu Settings ......................32 4.8.2 DCA Grouping ......................33 4.8.3 Mute Grouping ......................35 4.8.4 Scene Configuration ....................36 4.8.5 Noise Generator ......................37 4.8.6 Real-Time Analyzer ....................38...

  • Page 7: Chapter 1 Product Introduction

    HIPPO D1608 Digital Mixer Chapter 1 Product Introduction 1.1 Introduction This digital mixer effectively integrates digital mixing systems with innovative design and powerful DSP functions. It adopts a new concept that combines modern digital technology with traditional operation, offering users a highly professional functional experience. Its compact size, simple...

  • Page 8: Chapter 2 Specification

    HIPPO D1608 Digital Mixer  Built-in USB recording and playback function, support APE, FLAC, MP3, WAV and other audio formats; built-in 4G storage space, you can upload audio files into the machine to play;  8-channel DCA grouping, 8-channel mute grouping, inputs and outputs, effects channels can be programmed;...
  • Page 9 HIPPO D1608 Digital Mixer 2-way USB playback channels; 2 channels of L, R XLR Main bus outputs; 4 XLR AUX output channels; Outputs 1 set (2-way) TRS 6.35mm, stereo monitoring channels; 2-way USB recording channels; ＜0.003% @ 4dBu A+ C THD &...

  • Page 10: Chapter 3 Interface/Keypad Description

    HIPPO D1608 Digital Mixer Operating Power DC 19V/2A Power Consumption Dimension 410×250.4×69mm Weight 2.7KG Package Size 590x340×110mm Packing Weight 3.1KG Chapter 3 Interface/Keypad Description 3.1 Front Panel CH1-CH8: Balanced XLR/TRS combination mono input jacks; Trim knob: Channels 1-8 to adjust analog input signal level before analog-to-digital...
  • Page 11 HIPPO D1608 Digital Mixer HI-Z 9-10: High resistance mono channels for instrument input; CH11-CH14: TRS stereo input interface; 7-inch high-definition LCD touch screen; Home button: Return to the main interface; Menu button: Enter the display control and system setting interface;...

  • Page 12: Rear Panel

    HIPPO D1608 Digital Mixer 3.2 Rear Panel Power: Please use the power supply that came with the mixer, do not use other power supplies instead; USB2.0 (Class A): for connecting USB storage devices and Wi-Fi adapters; Remote: Ethernet interface for connecting to PC-based interactive software;...

  • Page 13: Pc Software Login Connection

    HIPPO D1608 Digital Mixer View device IP address: Enter [Menu] [Network] to view the device IP address information, the default is automatically assigned by DHCP, you can choose to manually set the IP address; Download: open the browser, enter the IP address of the device, click "Enter" to navigate...

  • Page 14: Main Interface

    HIPPO D1608 Digital Mixer 4.3 Main Interface Navigation bar: displays the type of channel and the channel range; Channel Name: displays the channel name (customizable name), touch to navigate to the channel configuration interface; Function Overview: displays the functions (EQ, COMP, Gate) that have been enabled for the current channel;...

  • Page 15: Input Channel

    HIPPO D1608 Digital Mixer 4.4 Input Channel 4.4.1 Overview Overview: displays the enabled channel controls for the current channel; Reset: restores all parameter configurations of this interface to the default state; Phase: change the polarity of the current input signal;...

  • Page 16: Configuration

    HIPPO D1608 Digital Mixer 4.4.2 Configuration Configuration: parameter configuration interface; Reset: restores the current interface parameter configuration to the default value; Channel Name: display the channel name, touch and then display the keyboard to customize the channel name; Link: link the channel with the neighboring channel, the channel settings will be copied to the neighboring channel;...

  • Page 17: Equalizer

    HIPPO D1608 Digital Mixer 4.4.3 Equalizer Equalizer configuration interface; Equalizer switch: turn on/off the equalizer; Real-time Analyzer: turn on/off the real-time analyzer to display the channel signal amplitude and peak value; Reset: restores the current interface parameter configuration to the default value;...

  • Page 18: Compressor

    HIPPO D1608 Digital Mixer High Shelf: Enables/disables the High Shelf filter, which changes the equalizer band 1 to band 6 from the parametric filter to the High Shelf filter; High Cut Filter On/Off Button: The filter takes the frequency set by the frequency controller as the cutoff frequency rate and attenuates the frequencies higher than the cutoff frequency rate;...

  • Page 19: Noise Gate

    HIPPO D1608 Digital Mixer Gain: Adjust the total output gain to compensate for the loss of signal level after compression; Build-up time: for when the signal exceeds the threshold, set the start-up time for the compressor to start working; Release time: for the signal below the threshold, set the release time for the compressor to stop compression.

  • Page 20: Aux Sends

    HIPPO D1608 Digital Mixer Hold Time: Set the time for the noise gate to remain open after it is turned on and the length of time for the noise gate to remain open when the input level drops below the threshold;...

  • Page 21: Fx Sends

    HIPPO D1608 Digital Mixer 4.4.7 FX Sends FX sends: Effects sends configuration interface; Reset: restores all parameter settings in this interface to their default values; FX channel name; Send slider: sets the audio signal level of the channel to send to the effect mix signal;...

  • Page 22: Main Lr Output Channel

    HIPPO D1608 Digital Mixer 4.5 Main LR Output channel 4.5.1 Overview Overview interface; Reset: restores all parameter settings of this interface to the default values; Delay: displays the delay configuration as well as the delay information; DCA Groups: shows that the channel has been assigned to DCA Groups;...

  • Page 23: Configuration

    HIPPO D1608 Digital Mixer 4.5.2 Configuration Config: parameter configuration interface; Reset: restores all the parameter settings of this interface to the default values; Channel Name: display the channel name, touch the display keyboard to customize the channel name; Delay Switch: turn on or off the Delay;...

  • Page 24: Parameter Equalizer

    HIPPO D1608 Digital Mixer 4.5.3 Parameter Equalizer PEQ: Parameter equalizer configuration interface; Reset: restores the current interface parameter configuration to the default value; Open: turn on or off the parameter equalizer; RTA: turn on or off the real-time analyzer; Parameter Adjustment Display: graphically represent the equalizer curve according to the equalizer parameter configuration;...

  • Page 25: Graphic Equalizer

    HIPPO D1608 Digital Mixer Low Shelf: Enable/disable the Low Shelf filter, change the equalizer band 1 to band 8 from parametric filter to low shelf filter; High Shelf: Enables/disables the High Shelf filter, and changes the equalizer band 1 to band 8 from parametric filter to High Shelf filter;...

  • Page 26: Compressor/Limiter

    HIPPO D1608 Digital Mixer 4.5.5 Compressor/Limiter Compressor/Limiter: Compressor/Limiter configuration interface; Reset: restores all parameter settings of this interface to default values; On: turn on/off the Compressor/Limiter; Compressor/Limiter Toggle Switch: switches between Compressor processing module and Limiter processing module; Input: display the input level;...

  • Page 27: Anti-Feedback

    HIPPO D1608 Digital Mixer 4.5.6 Anti-Feedback Anti-Feedback: Anti-Feedback parameter configuration interface; Reset: restores all parameter settings of this interface to default values; On: turn on/off the Anti-Feedback; Auto: automatically find the whistling point and suppress it; Manual: when a suspicious feedback frequency is recognized, touch this button to apply a filter at that frequency;...

  • Page 28: Fx Channel

    HIPPO D1608 Digital Mixer 4.6 FX Channel 4.6.1 Overview Overview: Overview interface; Reset: restores all parameter settings of this interface to default values; Effects Pickup: select pre-fader/post-fader signal; DCA Groups: shows that the channel has been assigned to DCA Groups;...

  • Page 29: Configuration

    HIPPO D1608 Digital Mixer 4.6.2 Configuration Config: parameter configuration interface; Reset: restores all the parameter settings of this interface to the default values; Channel Name: display the channel name, touch the display keyboard to customize the channel name; Effect Pickup: select the pre-fader/post-fader signal;...

  • Page 30: Equalizer

    HIPPO D1608 Digital Mixer 4.6.3 Equalizer EQ: Equalizer parameter configuration interface; Reset: restores the current interface parameter configuration to the default value; RTA: turn on/off the Real-Time Analyzer; Turn on/off: turn on or off the equalizer; Graphical representation of the equalizer curve according to the equalizer parameter configuration;...

  • Page 31: Fx Aux Sends

    HIPPO D1608 Digital Mixer Frequency: Sets the inflection frequency of the high shelving filter. 4.6.4 FX AUX Sends AUX Sends: Auxiliary Sends configuration interface; Reset: restores all parameter settings of this interface to the default values; AUX output channel name;...

  • Page 32: Effects

    HIPPO D1608 Digital Mixer 4.6.5 Effects I. Mono Delay Effect: Effect parameter configuration interface; Reset: restores all parameter settings in this interface to their default values; Select the type of Effect including Mono Delay, Stereo Delay, Chorus, Reverb and Pitch Shift;...
  • Page 33 HIPPO D1608 Digital Mixer II. Stereo Delay Effect: Effect parameter configuration interface; Reset: restores all parameter settings in this interface to their default values; Select the type of Effect including Mono Delay, Stereo Delay, Chorus, Reverb and Pitch Shift; Effect Preset: click the drop-down list to select the effect preset scene;...
  • Page 34 HIPPO D1608 Digital Mixer III. Chorus Effect: Effect parameter configuration interface; Reset: restores all parameter settings in this interface to their default values; Select the type of Effect including Mono Delay, Stereo Delay, Chorus, Reverb and Pitch Shift; Effect Preset: click the drop-down list to select the effect preset scene;...
  • Page 35 HIPPO D1608 Digital Mixer IV. Pitch Shift Effect: Effect parameter configuration interface; Reset: restores all parameter settings in this interface to their default values; Select the type of Effect including Mono Delay, Stereo Delay, Chorus, Reverb and Pitch Shift; Effect Preset: click the drop-down list to select the effect preset scene;...
  • Page 36 HIPPO D1608 Digital Mixer V. Reverb Effect: Effect parameter configuration interface; Reset: restores all parameter settings in this interface to their default values; Select the type of Effect including Mono Delay, Stereo Delay, Chorus, Reverb and Pitch Shift; Effect Preset: click the drop-down list to select the effect preset scene;...

  • Page 37: Playback/Recording

    HIPPO D1608 Digital Mixer 4.7 Playback/Recording Player interface; Local: list of local music files; USB: List of audio files in external USB (Class A) removable hard disk devices; Record: list of recorded files; Delete: Only local files as well as recorded files are allowed to be deleted;...

  • Page 38: Other Functions

    HIPPO D1608 Digital Mixer 4.8 Other Functions 4.8.1 Menu Settings DCA Grouping: navigates to the DCA Grouping screen; Real-Time Analyzer: Navigates to the Real-Time Analyzer screen; Test Signal: Noise generator, including a, sine wave, pink noise, white noise signal; FX Overview: Navigates to the effects preview screen;...

  • Page 39: Dca Grouping

    HIPPO D1608 Digital Mixer Upgrade/U disk firmware upgrade: Upgrade is the software on the PC side to upgrade the device side, U disk firmware upgrade is the device side to upgrade the software through USB; Version: show the version information;...
  • Page 40 HIPPO D1608 Digital Mixer II. DCA Grouping Configuration Screen DCA Grouping Options: selects the relevant DCA grouping available for editing; Clear: clear all assignments in the selected DCA grouping; Select All: Select all channels to be assigned to the DCA group;...

  • Page 41: Mute Grouping

    HIPPO D1608 Digital Mixer 4.8.3 Mute Grouping I. Mute Grouping Main Interface Mute Group Edit: Click to enter the mute group detail configuration interface; Mute: mute selected grouping. II. Mute Grouping Details Screen Mute Grouping Options: Select a mute grouping that can be edited;...

  • Page 42: Scene Configuration

    HIPPO D1608 Digital Mixer Grouping Name: the name of the grouping channel is displayed, and the name can be customized and modified; Mute: mute or unmute the channels that have been assigned to the mute group; Select All: Select or clear all mute group assignments;...

  • Page 43: Noise Generator

    HIPPO D1608 Digital Mixer Manual Save: manually save the current scene; Auto save (10s): save the scene automatically every 10 seconds. 4.8.5 Noise Generator Reset: reset the noise generator settings; Assign button: touch the channel name to assign the noise to that channel output;...

  • Page 44: Real-Time Analyzer

    HIPPO D1608 Digital Mixer 4.8.6 Real-Time Analyzer The real-time analyzer sources mainly include input channels, playback channels, Main L/R, AUX auxiliary outputs, and FX effects. 4.8.7 Level Meters The level overview is used to display real-time level information for all input/output channels.

  • Page 45: Auxiliary Output Matrix Overview

    HIPPO D1608 Digital Mixer 4.8.8 Auxiliary Output Matrix Overview Group channels 1-8, high resistance channels 9-10/stereo channels 11-14/USB, and FX effects channels 1-4 can be selected in the navigation bar; AUX output channel name; Control slider: used to adjust the signal level of the aux send.

  • Page 46: Warranty Regulations

    Warranty Regulations The warranty period of this product is 1 year. In the warranty period of non-man-made damage caused by the product performance failure can enjoy three packages of service. Warranty card by the sales unit stamped after the effective. The alteration is invalid! The following conditions (including, but not limited to, this) are not covered by the three-package service: 1.
  • Page 47 SHENZHEN S TRACK SCIENCE TECHNOLOGY CO., LTD Web: www.s-track.com.cn Tel:+86 755 29983191 Mail:service@s-track.cn Add: 9F, 1B, Shangzhi Technology Park, Guangming District, Shenzhen City, Guangdong Province, China 518107...
