- Page 1 ACE 无线温度电流复合传感器 ACE wireless temperature & current sensor 使用说明 V1.1 Operation Manual V1.1 安科瑞电气股份有限公司 Acrel Co., Ltd.
- Page 2 申 明 DECLARATION 版权所有，未经本公司之书面许可，此手册中任何段落，章节内容均不得被摘抄、拷贝或以任何形式复 制、传播，否则一切后果由违者自负。 本公司保留一切法律权利。 All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form by any means, electronic, mechanical photocopying, recording, or otherwise without prior permission of our company.
- Page 3 安科瑞电气股份有限公司 目 录 Contents 1 安装指南 ..............................1 1 Installation Guide ............................1 产品概述 ............................1 1.1 Product Introduction ...........................1 1.2 型号说明 ............................1 1.2 Type Introduction ..........................1 1.3 技术指标 ............................2 1.3 Technical Features ..........................2 1.4 产品安装 ............................2 1.4 Product Installation ..........................2 1.4.1 外形尺寸...
-
Page 4: Product Introduction
的方式上传至接收装置。产品安装方便，全面检测电缆数据，可帮助用户及早发现线路隐患，保障 供电安全，实现配电网络智能化。 The ACE100 wireless temperature & current sensor is mainly used to detect the temperature and current of the transmission cable of the low-voltage switchgear. The sensor adopts the dual power supply mode of internal battery and electromagnetic energy extraction to quickly and accurately measure the temperature and current data of low-voltage cables, and upload them to the receiving device via wireless. -
Page 5: Product Installation
ACE100 无线温度电流复合传感器，采用开口型卡扣式安装方式。安装时将传感器贴紧待测电 缆，完全扣紧 CT 卡扣。当电缆电流小于传感器感应取电启动电流时，传感器使用内部电池进行工 作，如果电流大于传感器感应取电启动电流，传感器将感应取电工作，节省电池电量。 The ACE100 wireless temperature & current sensor is installed in an open snap type. During installation, the sensor shall be tightly attached to the cable to be tested, and the CT snap shall be fully... - Page 6 CT power supply, current measurement Clamping mechanism, adjustable 夹持机构，可调节 Temperature probe 温度探头 Send Data Indicator 发送数据指示灯 Battery compartment cover 电池舱盖 1.4.1 外形尺寸 1.4.1 Shape Size 1.5 使用方案 1.5 Usage scheme 触摸屏 ATP007/ATP010 搭配 ATC600-C： HMI ATP007/ATP010 with ATC600-C: ACE100 ATC600-C...
- Page 7 安科瑞电气股份有限公司 说明：触摸屏通过 RS485 接口连接一只 ATC600-C 实现集中数据显示，1 只 ATC600-C 可接收 240 只 ACE100 无线温度电流复合传感器的数据。 Note: The HMI is connected with an ATC600-C through RS485 interface to realize centralized temperature and current display, and one ATC600-C can receive 240 temperature & current sensors.
