MICROWAVE OVEN

º√Àƒ¡√™ ªπ∫ƒ√∫Àª∞∆ø¡

OWNER'S MANUAL

∂°Ã∂πƒπ¢π√ ∫∞∆√Ã√À

PLEASE READ THIS OWNER'S MANUAL THOROUGHLY BEFORE OPERATING.

MB404

P/No:MFL40347308

Table of Contents

Need help?

Do you have a question about the MB4047C and is the answer not in the manual?

Questions and answers

Summary of Contents for LG MB4047C

Page 1 MICROWAVE OVEN º√Àƒ¡√™ ªπ∫ƒ√∫Àª∞∆ø¡ OWNER’S MANUAL ∂°Ã∂πƒπ¢π√ ∫∞∆√Ã√À PLEASE READ THIS OWNER’S MANUAL THOROUGHLY BEFORE OPERATING. MB404 MB404 P/No:MFL40347308...
Page 3 4~ 31 MICROWAVE OVEN OWNER’S MANUAL Please read this owner’s manual thoroughly before operating. 32~ 59 º√Àƒ¡√™ ªπ∫ƒ√∫Àª∞∆ø¡ ∂°Ã∂πƒπ¢π√ ∫∞∆√Ã√À...
Page 4: Precautions
Precautions Precautions to avoid possible exposure to excessive microwave energy. When heating liquids, e.g. soups, sauces and beverages in your microwave You cannot operate your oven with the door open due to the safety interlocks built into the door mechanism. These safety interlocks automatically switch off oven, delayed eruptive boiling can occur without evidence of bubbling.
Page 5: Table Of Contents
Contents Precaution s How the Microwave Oven Works Contents Microwaves are a form of energy similar to radio and television waves and Unpacking & Installi ng 6 ~ 7 ordinary daylight. Normally, microwaves spread outwards as they travel Setting the Cl ock through the atmosphere and disappear without effect.
Page 6: Unpacking & Installi Ng 6
Unpacking & By following the basic steps on these two pages you will be able to quickly check that your oven is operating correctly. Please pay particular attention to the guidance on where to install your oven. When unpacking your Installing oven make sure you remove all accessories and packing.
Page 7 Open your oven door by pulling the DOOR HANDLE. Plug your oven into a standard household socket. Place the ROTATING RING inside the oven and place the Make sure your oven is the only appliance connected to the socket. If your oven does not operate GLASS TRAY on top.
Page 8: Setting The Clock
Setting the You can set either 12 hour clock or 24 hour clock . Clock In the following example I will show you how to set the time for 14:35 when using the 24 clock. Make sure that you have removed all packaging from your oven. Make sure that you have correctly installed your oven as described earlier in this book.
Page 9: Child Lock
Child Lock Press STOP/CLEAR . Your oven has a safety feature that Press and hold STOP/CLEAR until “L” appears in the display and BEEP prevents accidental running of the oven. sounds. Once the child lock is set, you will be The CHILD LOCK is now set.
Page 10: Micro Power Cooking
Micro Power In the following example I will show you how to cook some food on 80% power for 5 minutes and 30 seconds. Cooking Make sure that you have correctly installed your oven as described earlier in this book. Press STOP/CLEAR.
Page 11: Micro Power Leve L
Micro Power Your microwave oven is equipped with 5 power levels to give you maximum flexibility and control over cooking. Level The table below shows the examples of food and their recommended cooking power levels for use with this microwave oven. POWER LEVEL OUTPUT 100%...
Page 12: Two Stage Cooking
Two stage In the following example I will show you how to cook some food in two stages. The first stages will cook your Cooking food for 11 minutes on HIGH; the second will cook for 35 minutes on 320. Press STOP/CLEAR.
Page 13: Quick Start
Quick In the following example I will show you how to set 2 minutes of cooking on high power. Start Press STOP/CLEAR. Press START four times to select 2 minutes on HIGH power. The QUICK START feature allows you to Your oven will start before you have finished the fourth press.
Page 14: Grill Cooking
Grill Cooking In the following example I will show you how to use the grill to cook some food for 12 minutes and 30 seconds. Press STOP/CLEAR. Press Grill. This feature will allow you to brown and crisp food quickly. Set the cooking time.
Page 15: Combination Cooking
Combination In the following example I will show you how to programme your oven with combi mode Co-3 for a cooking time Cooking of 25 minutes. Press STOP/CLEAR . Press COMBI three times “Co-3” appears on the display. Your oven has a combination cooking feature which allows you to cook food with heater and microwave at the same Set the cooking time.
Page 16: Auto Cook 16
Auto In the following example I will show you how to cook 0.5 kg of jacket potato. Cook Press STOP/CLEAR. Press AUTO COOK one time. “AC-1” appears on the display. AUTO COOK allows you to cook most of your favorite food easily by selecting the food type and entering the weight of the food by pressing the key.
Page 17: Frozen Vegetable
FUNCTION CATEGORY WEIGHT LIMIT UTENSIL FOOD TEMP. INSTRUCTIONS Choose medium sized potatoes 170 -200g. AUTO 1. JACKET 0.1 kg ~ 1.0 kg Room Wash and dry potatoes. Pierce the potatoes several times with fork. Place the potatoes on COOK POTATO the glass turntable.
Page 18: Auto Defr Ost 18
The temperature and density of food varies, I would recommend that the food is checked before cooking Auto commences. Pay particular attention to large joints of meat and chicken, some foods should not be completely thawed before cooking. For example fish cooks so quickly that it is sometimes better to begin cooking while still Defrost slightly frozen.
Page 19: Auto Weight Defrost Guide
AUTO WEIGHT DEFROST GUIDE * Food to be defrosted should be in a suitable microwave proof container and place uncovered on the glass turntable. * If necessary, shield small areas of meat or poultry with flat pieces of aluminum foil. This will prevent thin areas becoming warm during defrosting. Ensure the foil does not touch the oven walls.
Page 20: Quick Defros T 20
Quick Use this function to thaw only 0.5kg of Minced meat very quickly. Defrost This will require a standing time to allow the center to thaw. In the following example will show you how to defrost 0.5kg of forzen minced meat. Press STOP/CLEAR.
Page 21: Quick Defrost Guide
QUICK DEFROST GUIDE Use this function to defrost quickly for minced meat. Remove the meat completely from it’s wrapping. Place the mince onto a microwave-safe plate. When BEEP, at this point remove the mince from the microwave oven, turn the mince over and return to the microwave oven. Press start to continue. At the end of the program remove the mince from the microwave oven, cover with foil and allow to stand 5-15 minutes or until completely thawed.
Page 22: More Or Less Cooking
More or Less In the following example I will show you how to change the preset AUTO COOK programmes for a longer or Cooking shorter cooking time. Press STOP/CLEAR. If you find that your food is over or Set the required AUTO COOK programme. undercooked when using the AUTO (Select weight of food.) COOK or AUTO REHEAT programme,...
Page 23: Heating Or Reheating Gui De
Heating or Reheating To heat or reheat successfully in the microwave, it is important to follow several guidelines. Measure the amount of food in order to determine the time needed to reheat. Arrange the food in a circular pattern for best results. Room temperature food will heat faster than refrigerated food.
Page 24: Fresh Vegetable Guide
Fresh Vegetable Guide Cook time Standing Cook time Standing Vegetable Amount Instructions Vegetable Amount Instructions (at HIGH) Time (at HIGH) Time Artichokes 2 medium 1 /2 Trim. Add 2 tsp water and 2 tsp juice. 2~3 minutes Corn, Fresh 2 ears 4 ~ 8 Husk.
Page 25: Important Safety Instruc Tions 25
Important safety instructions WARNING Please do not let the POWER Read carefully and keep for future reference CORD touch the BACK COVER. 1 Do not attempt to tamper with, or make any adjustments or repairs to the 12 Before cooking, pierce the skin of potatoes, apples or any such fruit or door, control panel, safety interlock switches or any other part of the oven.
Page 26 Important safety instructions WARNING Please ensure cooking times are correctly set as over cooking may result in FIRE and subsequent Read carefully and keep for future reference DAMAGE to the OVEN. 24 Only use utensils that are suitable for use in microwave ovens. 35 The appliance is not intended for use by young children or infirm persons without supervision.
Page 27: Microwave Safe Utensils
Microwave-safe Utensils Never use metal or metal trimmed utensils in your Paper microwave oven Paper plates and containers are convenient and safe to use in your microwave oven, Microwaves cannot penetrate metal. They will bounce off any metal object in the provided that the cooking time is short and foods to be cooked are low in fat and oven and cause arcing, an alarming phenomenon that resembles lightning.
Page 28: Food Characteristics & Microwave Coo King 28
Food characteristics & Microwave cooking Moisture content of food Keeping an eye on things Since the heat generated from microwaves tends to evaporate moisture, relatively dry food The recipes in this book have been formulated with great care, but your success in such as roasts and some vegetables should either be sprinkled with water prior to cooking preparing them depends on how much attention you pay to the food as it cooks.
Page 29 Food characteristics & Microwave cooking. Stirring To Clean Your Oven Stirring is one of the most important of all microwaving techniques. In conventional cooking, food is stirred for the purpose of blending. Microwaved food, however, is stirred in order to spread and redistribute heat.
Page 30: Questions & Answers
Questions & Answers Q What’s wrong when the oven light will not glow? Q Is it possible to pop corn in a microwave oven? A There may be several reasons why the oven light will not glow. A Yes, if using one of the two methods described Light bulb has blown.
Page 31: Plug Wiring Information/Technical Specifications
Plug wiring information/ Technical Specifications Warning Technical Specification This appliance must be earthed The wires in this mains lead are colored in accordance with the MB4047C/MB4047CS following codes BLUE ~ Neutral 230 V AC /50Hz Power Input BROWN ~ Live 800 W (IEC60705 rating standard) GREEN &...

This manual is also suitable for:

Mb4047cs
