Headliner Starlight, HL90515 Manual
WINDOWS setup
Connect ROXY to a USB port on your PC using the provided USB cable. Your computer will automatically recognize the USB device and install a driver.
- Right-click the small speaker icon in the lower right corner of the screen, select Open Sound settings.
![WINDOWS setup - Step 1]( "Headliner - Starlight - WINDOWS setup - Step 1")
- Scroll down to theInput section then open the dropdown menu to select Microphone (STARLIGHT) as your selected input device.
![WINDOWS setup - Step 2]( "Headliner - Starlight - WINDOWS setup - Step 2")
- To adjust the input volume to your desired level go to Device Properties under the Input dropdown menu. Use the volume bar at the bottom of the menu to adjust the input volume.
![WINDOWS setup - Step 3]( "Headliner - Starlight - WINDOWS setup - Step 3")
OS X SETUP
Connect ROXY to a USB port on your Mac using the provided USB cable. Your computer will automatically recognize the USB device.
- Select System Preferences from the Apple menu.
![OS X SETUP - Step 1]( "Headliner - Starlight - OS X SETUP - Step 1")
- Select the Sound preferences.
![OS X SETUP - Step 2]( "Headliner - Starlight - OS X SETUP - Step 2")
- Select the Input tab, then select STARLIGHT from the device menu. Use the volume bar at the bottom of the window to adjust the input volume.
![OS X SETUP - Step 3]( "Headliner - Starlight - OS X SETUP - Step 3")
CONTENTS OF PACKAGE
- Starlight USB Microphone
- Shock Mount
- Desktop Stand
- USB Cable
TECHNICAL SPECIFICATIONS
| Element: | 16mm Back Electret capsule |
| Polar Pattern: | Cardioid |
| Sensitivity: | -35dB±2dB (0dB=1v/pa at 1kHz) |
| Frequency Response: | 40Hz-18KHz |
| Sound pressure level: | 136dB (at 1kHz≤1% THD) |
| Signal to noise ratio: | 68dBA |
| Sample Rates: | 44100Hz, 48000Hz |
| Resolution: | 16 bit |
