Summary of Contents for AEG LTR6E40268
- Page 1 EN User Manual | Washing Machine LTR6E40268 aeg.com\register...
-
Page 2: Table Of Contents
FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it. -
Page 3: Safety Information
SAFETY INFORMATION Before beginning the installation and use of this appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference. -
Page 4: General Safety
1.2 General Safety • This appliance is for washing domestic-type, machine- washable laundry only. • This appliance is designed for single household domestic use in an indoor environment. • This appliance may be used in, offices, hotel guest rooms, bed & breakfast guest rooms, farm guest houses and other similar accommodation where such use does not exceed (average) domestic usage levels. -
Page 5: Safety Instructions
2. SAFETY INSTRUCTIONS 2.1 Installation • WARNING: This appliance is designed to be installed / connected to a grounding connection in the building. • Always use a correctly installed The installation must comply with shockproof socket. relevant national regulations. • Make sure that the parameters on the rating plate are compatible with the •... -
Page 6: Product Description
• Make sure that there is access to the tap valves, filters and aquastops, printed after the installation. circuit boards, electronic displays, pressure switches, thermostats and 2.4 Use sensors, software and firmware including reset software, door, door hinge and seals, other seals, door locking assembly, WARNING! plastic peripherals such as detergent Risk of injury, electric shock, fire, burns... -
Page 7: Appliance Overview
3.2 Appliance overview 10 11 Control panel Drain hose Mains cable Lid handle Transit bolts Drain pump filter Hose support Lever to move the appliance Rating plate Feet for levelling the appliance Inlet hose Information for register product. The rating plate reports the model name The info label reports the model name (A), (A) , product number (B), electrical ratings (C) product number (B ) and serial number (C). -
Page 8: Technical Data
4. TECHNICAL DATA Dimension Width/ Height/ Total depth 39,7 cm /90,3 cm /59,9 cm Electrical connection Voltage 230 V Overall power 2200 W Fuse 10 A Frequency 50 Hz Level of protection against ingress of solid particles and moisture ensured IPX4 by the protective cover, except where the low voltage equipment has no protection against moisture... -
Page 9: The Inlet Hose
We recommend that you keep the packaging and the transit bolts for any transport of the appliance. Adjust the appliance correctly to prevent vibration, noise and movement of the appliance when it operates. WARNING! Do not put cardboard, wood or equivalent materials below the appliance feet to adjust the level. -
Page 10: Water-Stop Device
Accessories delivered with the appliance may vary depending on the model. 3/4” 3/4” Make sure there is no damage to hoses and there are no leaks from the couplings. Do not use an extension hose if the inlet hose is too short. Contact the service centre for a replacement inlet hose. -
Page 11: Water Drainage
5.4 Water drainage min.600 mm max.1000 mm The drain hose should stay at a height of no less than 600 mm and not more than 1000 mm. You can extend the drain hose to maximum 4000 mm. Contact the authorised service centre for the other drain hose and the extension. -
Page 12: Control Panel
6. CONTROL PANEL 6.1 Control panel description Ein/Aus touch button Option touch button • Flecken option Programme dial • Vorwäsche option Display Schleudern reduction touch button Zeitvorwahl touch button Temperatur touch button Zeit Sparen touch button Start/Pause touch button 6.2 Display ENGLISH... -
Page 13: Programme Chart
The digital indicator can show: • Programme duration (e. g. • Delay time (e. g. • Cycle end ( ). • Warning code ( • Indication of total operating hours of the appliance. Refer to the 'Operating hours counter' section in the 'Settings' paragraph for more details. - Page 14 Programme Programme description All fabrics, except woollens and very delicate fabrics. Programme for rinsing and spinning the laundry. The default spin speed is the one used for cotton pro‐ Spülen grammes. Reduce the spin speed accordingly to the type of laundry. If necessary, set the Extra Spülen option to add rinses.
-
Page 15: Programme Options Compatibility
Programme Default temperature Reference spin speed Maximum Temperature range Spin speed range load 40 °C 800 rpm 2 kg Daunen 800 rpm - 800 rpm 60 °C - Cold ( 1200 rpm 6 kg Schleudern/Pumpen 1200 rpm - 800 rpm 1200 rpm 6 kg Spülen... - Page 16 Programme Leichtbügeln ■ ■ ■ ■ ■ ■ ■ Feinwäsche ■ ■ ■ ■ ■ ■ Wolle/Seide ■ ■ ■ ■ Daunen ■ Schleudern/Pumpen ■ ■ ■ Spülen ■ ■ ■ Anti-Allergie ■ ■ ■ ■ ■ ■ ■ Jeans ■...
-
Page 17: Options
Programme Universal Liquid Uni‐ Liquid for col‐ Delicates Special versal oureds woollens powder 1) ▲ ▲ ▲ Jeans ▲ ▲ ▲ Sportwäsche ▲ ▲ ▲ Baumwolle 20° ▲ ▲ 20 Min. - 3 kg At temperature higher than 60 °C the use of powder detergent is recommended. ▲... -
Page 18: Zeit Sparen
Set this option to change the default heavily soiled or stained laundry with stain temperature. remover. Pour the stain remover into The indicator = cold water of the set compartment . The stain remover will be temperature comes on (the appliance does added in the appropriate phase of the not heat the water). -
Page 19: Settings
8.8 Start/Pause Touch the Start/Pause button to start, pause the appliance or interrupt a running programme. 9. SETTINGS 9.1 Acoustic signals operating time of the cycles (does not include pauses, delayed start time). To visualise this To deactivate the acoustic signals when the value, proceed as follows: programme is completed touch the 1. -
Page 20: Daily Use
4. The display will show for about 5 seconds. If the procedure does not work (due to timeout, wrong programme dial position or wrong keys combination), switch the appliance off and repeat sequence from the beginning. 10. BEFORE FIRST USE 2. -
Page 21: Liquid Or Powder Detergent
When using liquid detergents add them into a dosing ball (supplied by the detergent's manufacturer). Put the dosing ball inside the washing machine's drum, on top of the garments. Detergent compartment for prewash phase. The marks MAX are the maximum levels of the quantity of detergent (powder or liquid). When you set a programme with a stain, add detergent (powder or liquid). -
Page 22: Activating The Appliance
1. Touch the Start/Pause button to pause the appliance. The related indicator flashes. When you use the liquid detergent: 2. Touch the Zeitvorwahl button repeatedly • Do not use gelatinous or thick liquid detergents. until the display shows • Do not put more liquid then the 3. -
Page 23: Cancelling A Running Programme
1. Press button Start/Pause. The related indicator flashes. 2. Change the option set. The ProSense System is not available 3. Press the button Start/Pause again. with all programmes such as :Wolle/ The programme continues. Seide, Spülen, SchleudernPumpen, and programmes with short cycles. 11.10 Cancelling a running programme 11.12 Opening the Lid when the... -
Page 24: Draining Water Out After End Of Cycle
After five minutes from the end of the programme, the energy saving function The appliance drains and spins automatically deactivates the appliance. automatically after approximately18 hours. When you activate the appliance again, 11.16 AUTO Stand-by option the display show the end of the last set programme. -
Page 25: Stubborn Stains
b. manually redistribute the load so that • Use only detergents and other treatments the items are spaced evenly around specially made for washing machines. the tub; First, follow these generic rules: c. press the Start/Pause button. The – powder detergents for all types of spin phase continues. -
Page 26: Care And Cleaning
12.5 Water hardness programmes helps to reduce energy and water consumption. If the water hardness in your area is high or • With adequate pre-treatment, stains and moderate, we recommend that you use a limited soiling can be removed; the water softener for washing machines. -
Page 27: Maintenance Wash
13.4 Descaling 13.6 Cleaning the drum Regularly examine the drum to prevent rust particles. If the water hardness in your area is high For a complete cleaning: or moderate, we recommend that you 1. Clean the drum with special products for use a water descaling product for stainless steel. -
Page 28: Cleaning The Inlet Hose And The Valve Filter
Always keep a rag nearby to dry up any water WARNING! spillages when removing the filter. • Disconnect the mains plug from the mains socket. • Do not remove the filter while the appliance operates. • Do not clean the pump if the water in the appliance is hot. -
Page 29: Emergency Drain
13.11 Emergency drain 1. Disconnect the mains plug from the mains socket. If the appliance cannot drain the water, carry 2. Close the water tap. out the same procedure, described in 3. Put the two ends of the inlet hose in a 'Cleaning the drain pump' paragraph. - Page 30 • Make sure that the sink spigot is not clogged. • Make sure that the drain hose has no kinks or bends. The appliance does not • Make sure that the drain filter is not clogged. Clean the filter, if necessary. Re‐ drain the water.
- Page 31 Problem Possible solution • Make sure that a washing programme that ends with water in tub, has not been selected. • Make sure that the washing programme is finished. You cannot open the appli‐ • Set the drain or the spin programme if there is water in the drum. ance lid.
-
Page 32: Consumption Values
15. CONSUMPTION VALUES 15.1 Introduction See the web link www.theenergylabel.eu for detailed information about Energy Label. The QR code on the energy label supplied with the appliance provides a web link to the information related to the performance of the appliance in the EU EPREL database. Keep the energy label for reference together with the user manual and all other documents provided with this appliance. -
Page 33: Quick Guide
Power consumption in different modes Off (W) Stand-by (W) Delay start (W) 0.50 0.50 4.00 Time to Off/Standby mode is 15 minutes maximum. 15.4 Common programmes These values are indicative only. Programme Litres hh:mm °C Baumwolle 2.35 85.0 4:05 53.00 1200 95°C Baumwolle... -
Page 34: Cleaning The Drain Pump Filter
Load the laundry. the programme, touch the Start/Pause (2) button. Pour the detergent and other treatment in the 3. The appliance starts. proper compartment of the detergent At the end of the programme, remove the dispenser. laundry. 1. Push the Ein/Aus button to turn the Push the Ein/Aus button to turn the... -
Page 35: Environmental Concerns
Programmes Load Product description White cotton items. This programme helps to remove germs and 6 kg Anti-Allergie bacteria. 3 kg Denim clothing and jersey items. Jeans 3 kg Sportswear. Sportwäsche 6 kg White cotton and coloured cotton. Baumwolle 20° 3 kg Cotton and synthetic lightly soiled items or once worn items. - Page 36 135974930-A-502022...
