- Page 1 EW8HL72W4 Tumble Dryer User Manual...
- Page 2 1369/2017......................23 WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time.
- Page 3 ENGLISH SAFETY INFORMATION Before beginning the installation and use of this appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damages that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.
- Page 4 1.2 General Safety Do not change the specification of this appliance. • If the tumble dryer is put on top of a washing machine, • use the stacking kit. The stacking kit, available from your authorized vendor, can be used only with the appliance specified in the instructions supplied with the accessory.
- Page 5 ENGLISH Items that have been soiled with substances such as • cooking oil, acetone, alcohol, petrol, kerosene, spot removers, turpentine, waxes and wax removers should be washed in hot water with an extra amount of detergent before being dried in the tumble dryer. Items such as foam rubber (latex foam), shower caps, •...
- Page 6 • Always use a correctly installed • Do not use water spray and steam to shockproof socket. clean the appliance. • Do not use multi-plug adapters and • Clean the appliance with a moist soft extension cables. cloth. Only use neutral detergents. Do •...
- Page 7 ENGLISH 3. PRODUCT DESCRIPTION Water container Control panel Appliance door Filter Rating plate Airflow slots Heat Exchanger lid Heat Exchanger cover Adjustable feet For ease of loading laundry or ease of installation the door is reversible. (see separate leaflet). 4. CONTROL PANEL Programme knob and RESET On/Off button...
- Page 8 4.1 Display Symbol on the display Symbol description time drying option on delay start option on check Heat Exchanger indicator: clean filter indicator: drain the water container indicator: child lock on wrong selection or knob is in the "Reset" po‐...
- Page 9 ENGLISH Programme Load Properties / Fabric type Single or double duvets and pil‐ Piumoni 3 kg lows (with feather, down or syn‐ thetic fillings). Refresh Refreshing textiles that were in storage. Gentle drying of hand-washable 1 kg Seta silks. Woollen fabrics. Gentle drying for hand-wash‐ able woollens.
- Page 10 Programme Load Properties / Fabric type Mix of garments made of cotton, Misti XL 6 kg cotton-synthetic blend and syn‐ thetic fabric. 1) The maximum weight refers to dry items. 2) For fabric mark meaning see chapter HINTS AND TIPS: Preparing the laundry.
- Page 11 ENGLISH Asciuga‐ Extra Si‐ Livello Asciugatura Antipiega tura a Programmes lent Tempo Refresh ■ ■ ■ Seta ■ Lana ■ Outdoor Denim ■ ■ ■ Lenzuola XL ■ ■ ■ ■ Misti XL ■ ■ ■ ■ 1) Together with the programme you can set 1 or more options. To activate or deactivate them, press the related touch button.
- Page 12 1. Press the on/off button to activate the is completed or when it is necessary to appliance. empty the water container. 2. Use the programme knob to set any If a draining kit is installed programme. (additional accessory), the 3.
- Page 13 ENGLISH 9. DAILY USE 9.1 Start a programme without 9.3 Change a programme delay start 1. Press the on/off button to deactivate appliance 1. Prepare the laundry and load the 2. Press the on/off button to activate the appliance. appliance. CAUTION! 3.
- Page 14 • After 5 minutes if you do not start the Always clean the filter and programme. empty the water container • After 5 minutes from the end of the when a programme is programme. completed. The time is reduced to 30 9.5 Stand-by function...
- Page 15 ENGLISH 5. 1) 1) If necessary remove fluff from the filter socket and gasket. You can use a vacuum cleaner. 11.2 Emptying the water container You can use the water from the water container as an alternative to distilled water (e.g.
- Page 16 11.3 Cleaning the Heat Exchanger...
- Page 17 ENGLISH 11.5 Cleaning the control panel CAUTION! and housing Do not touch the metal surface with bare hands. Use a standard neutral soap detergent to Risk of injury. Wear clean the control panel and housing. protective gloves. Clean Use a moist cloth to clean. Dry the carefully to avoid damaging the metal surface.
- Page 18 Problem Possible solution Make sure that the filter is clean. The laundry is too wet. Spin the laundry in the washing machine again. Ensure that the room temperature is higher than +5°C and lower than +35°C. Optimal room temperature is 19°C to 24°C.
- Page 19 ENGLISH Total power 900 W Energy efficiency class Energy consumption on the standard cot‐ 1,74 kWh ton programme with the full load. Energy consumption on the standard cot‐ 0,99 kWh ton programme with the partial load. 210,70 kWh Annual energy consumption 0,13 W Left-on mode power absorption 0,13 W...
- Page 20 Energy Drying consump‐ Programme Spun at / residual humidity time tion Pronto Stiro 1400 rpm / 50% 87 min. 1,04 kWh 1000 rpm / 60% 104 min. 1,29 kWh Cotoni Eco 3,5 kg Normale 1400 rpm / 50% 70 min.
- Page 21 ENGLISH 14.2 Cleaning the filter At the end of each cycle the filter symbol appears on the display and you must clean the filter. 14.3 Programme table Programme Load Properties / Fabric type Cycle to be used to dry cotton with "cotton cupboard"...
- Page 22 Programme Load Properties / Fabric type Woollen fabrics. Gentle drying for hand-wash‐ able woollens. Remove items immediately when the programme is completed. 1 kg Lana The wool drying cycle of this machine has been approved by The Woolmark Company for the drying of wool garments labelled as "hand wash"...
- Page 23 15. PRODUCT INFORMATION SHEET IN REFERENCE TO E.U. REGULATION 1369/2017 Product Information Sheet Trade Mark Electrolux Model EW8HL72W4, PNC916098207 Rated capacity in kg Air vented or condenser tumble dryer Condenser Energy efficiency class Energy consumption in kWh per year, based on 160 dry‐...
- Page 24 Average condensation efficiency of the standard cotton programme at partial load as a percentage Weighted condensation efficiency for the 'standard cotton programme at full and partial load' Sound power level in dB Built in appliance Y/N The information given in the chart above is compliant with the EU Commission regulation 392/2012 implementing directive 2009/125/EC.
- Page 25 ENGLISH...
- Page 26 www.electrolux.com...
- Page 27 ENGLISH...
- Page 28 www.electrolux.com/shop...
