- Page 1 Refrigerator User Manual HPG2 6573W XP4UK 15 7550 0143/ EN/ AA/ 17/10/2024 10:44 7285540746...
- Page 2 If you have any questions or concerns, please call our Customer Service Team or find help and information online at docs.hotpoint.eu The following symbols are used in the user manual: Hazard that may result in death or injury.
-
Page 3: Table Of Contents
1 Safety Instructions......Intention of Use ......Safety of Children, Vulnerable Persons and Pets ......Electrical Safety......Handling Safety ......Installation Safety......Operational Safety......Food Storage Safety...... 12 Maintenance and Cleaning Safety 13 Lighting .......... 14 1.10 Disposal of the Old Product..14 2 Environmental Instructions .... -
Page 4: Safety Instructions
1 Safety Instructions • This section includes the In the staff kitchens of the safety instructions necessary stores, offices and other work- to prevent the risk of personal ing environments, injury or material damage. In farm houses, • Our company shall not be held In the units of hotels, motels or responsible for damages that other resting facilities that are... -
Page 5: Electrical Safety
• Children between 3 and 8 heavy items on the power years are allowed to put and cable. The power cable should take out food into/from the not be bent, crushed, and cooler product. come into contact with any • Children and pets must not heat source. -
Page 6: Handling Safety
the mains (fuse, switch, main • Be careful not to damage the switch, etc.) shall be available cooling system and the pipes on the electrical installation. while handling the product. Do • The product must not be oper- not operate the product if the ated with an external switching pipes are damaged, and con- device such as a timer, or a re-... - Page 7 • Check for any damage on the • The product shall be installed product before installing it. Do in a dry and ventilated environ- not have the product installed ment. Do not keep carpets, if it is damaged. rugs or similar covers under •...
- Page 8 small rooms, a flammable gas- • Plug the product in a grounded air mixture may occur in case socket that conforms with the of a gas leak in the cooling Voltage, Current and Fre- system. At least 1 m³ of quency values specified in the volume is required for each 8 type label.
-
Page 9: Operational Safety
dry room, etc.) If the refriger- • Do not get on the product. Risk ator is wet by water, unplug it of falling and injury! and contact an authorized ser- • Do not cause damage to the vice. pipes of the cooling system us- •... - Page 10 • Do not touch the inner walls, ilar materials and products metal parts of the freezer or that are subject to the Medical food kept inside the freezer Products Directive. with wet hands. Risk of frost- • If the product is used against bite! its intended purpose, it may •...
- Page 11 • Do not place objects that may cooling system and the pipes fall/tip over on the product. while operating the product. In These objects may fall while case of damage to the pipes; opening or closing the door 1. Do not touch the product or and cause injuries and/or ma- the power cable.
-
Page 12: Food Storage Safety
• If there is a lock available on bar) or has a water impact ef- the product’s door, keep the fect, use a pressure limiting key out of children's reach. valve on your mains system. Ask help from professional For Products with Water Dis- plumbers if you do not know penser / Icematic how to control your water pres-... -
Page 13: Maintenance And Cleaning Safety
• Store raw meat and fish Maintenance and products in appropriate com- Cleaning Safety partments within the product. • Unplug the refrigerator or de- Thus, it does not drip on or energise the fuse before clean- come into contact with other ing it or starting to perform foods. -
Page 14: Lighting
ing the ice inside it. Steam con- 1.10 Disposal of the Old tacts the live areas in your re- Product frigerator and causes short cir- When disposing of your old cuit or electric shock. product follow the instructions • Do not use any mechanical below: tools or any other tools than •... -
Page 15: Ective And Disposing Of The Waste Product
2 Environmental Instructions Compliance with RoHS Directive 2.1 Compliance with the WEEE Dir- ective and Disposing of the The product you have purchased complies with EU RoHS Directive (2011/65/EU). It Waste Product does not contain harmful and prohibited materials specified in the Directive. This product complies with EU WEEE Directive (2012/19/EU). -
Page 16: Your Refrigerator
3 Your Refrigerator 1 Freezer compartment 2 Cooler compartment 3 Fan 4 *Cooler compartment glass shelves 5 Egg holder 6 *Bottle shelf 7 *Cooler compartment door shelves 8 *Dairy (cold storage) bin 9 *Bottle shelf 10 *Crispers 11 Frozen food storing compartments 12 *Freezer compartment door shelves 13 *Freezer compartment door shelves 14 Frozen food storing compartments... -
Page 17: Installation
4 Installation Right place for installation Do not use extension or multi sock- ets in the power connection. Read the “Safety Instructions” sec- tion first! The manufacturer assumes no re- sponsibility for any damage caused Your product requires adequate air circula- by the work carried out by unau- tion to function efficiently. - Page 18 Adjusting the Legs If the product is not in a balanced position, you can adjust the balance of the product by rotating the stands on the front right or left. When doing so, pay attention not to jam For adjusting the doors vertically, your hand between the product and the Loosen the fixing bolt at the bottom.
-
Page 19: Electrical Connection
Fixing Bolt Adjusting Nut Fixing Bolt Adjusting Bolt 4.1 Electrical Connection Before transport or use, never open the control board cover on the WARNING: Do not use extension product. Risk of electric shock and cables or multi sockets in power fire! connection. -
Page 20: First Use
as compressor, fan, heater, defrost, light- • The temperature change caused by open- ing, display and so on will operate ac- ing and closing of the door while using cording to the needs by consuming min- the product may normally lead to con- imum energy. -
Page 21: Operating The Product
6 Operating the Product • Turn off the water valve if you will be Read the “Safety Instructions” sec- away from home (e.g. at vacation) and tion first! you will not be using the Icematic or the • Do not use any mechanical tools or any water dispenser for a long period of time. - Page 22 The vacation mode will be activated and Water, Ice Cube, Crashed Ice Selection the LED on the key will be illuminated. “- -” shall be displayed on the Cooler Compart- This key allows you to switch between wa- ment temperature indicator and the cooler ter, ice cube and crushed ice selections.
-
Page 23: Use Of Your Appliance
WARNING The temperature can be set between 1-8°C for the chiller com- partment and between -24 and -15°C for the freezer compartment. Adjustable temperature values may vary provided that they are within these ranges according to product specifications. 8 Use of Your Appliance 8.1 Storing Food in the Freezer and •... - Page 24 Freezer details • In order not to cause odour and taste changes, the food should be stored in the As per the IEC 62552 standards, the freezer closed containers. must have the capacity to freeze 4,5 kg of • Do not store too much food in your refri- food items at -18°C or lower temperatures gerator.
-
Page 25: Replacing The Illumination Lamp
• Take green vegetables out of the plastic • Except the cases where extreme circum- bag and place them in the refrigerator stances are available in the environment, after wrapping them in a paper towel or if your product (on the recommended set drying cloth. -
Page 26: Product Features
minutes, if the door is still not closed, a 120 s) when any key on the product screen, visual warning (lighting flash) is activated. if any, is pressed. Then the process will The door open alert will be delayed for a start again. - Page 27 drip tray by pulling it toward yourself or separate ice cubes, remove the ones that pressing on its edge. You can clean the wa- cannot be separated from the bin and put ter in the drip tray in this way. the remaining cubes back into the bin.
-
Page 28: Egg Holder
We recommend you to remove the water in for meat, chicken or fish to be consumed the grid regularly. quickly. It is not suitable to store fruits and vegetables in this drawer. It is normal to hear a sound when ice cubes are falling down from the ice storage bin. - Page 29 Depending on the model, you can connect your product to a carboy or directly to the water network. To make this connection, you must first connect the water hose to the product. Depending on the model of your product, check whether the following parts are in- cluded with the product: Union (1 piece) : Used for attaching the water hose to the back of the product.
- Page 30 Connecting to mains water Thread the union onto the faucet ad- apter and tighten by hand/tool. (This feature is optional) If you are going to use the product by con- necting it to the cold water line, you need to install a standard 1/2"...
- Page 31 WARNING After opening the faucet, make sure that there is no water leakage at both joints of the water hose. In case of leakage, close the valve im- mediately and tighten all joints with a pipe wrench or pliers. For products to be used in carboys; (This feature is optional) In order to connect carboy water to the After completing the connection, plug...
- Page 32 10. Connect the water hose coming out of the top of the filter to the water con- nection adapter of the product. Union (1 piece) : Used for attaching the water hose to the back of the product. Faucet adapter ( 1 piece ) : Used for cold water mains line connection.
- Page 33 Do not use the first 10 glasses of water after connecting the filter. For filter installation, the “Ice Off" indic- ator must be active. Switching between ON and OFF indicators on the display is done by pressing the “Ice” button. Water line Remove the crisper compartment to access the water filter.
-
Page 34: Maintenance And Cleaning
The water filter removes some for- eign particles from the water. It does not purify the water from mi- croorganisms. 10 Maintenance and Cleaning • The water tank and the components of WARNING: the water dispenser shall not be washed Read the “Safety Instructions”... - Page 35 • Do not place your hands, feet or metal and removal of prints on the plastic part. objects under the refrigerator. Jamming Use warm water and a soft cloth for may occur or any sharp edge may cause cleaning, and then dry it. personal injuries..
-
Page 36: Troubleshooting
Protecting Plastic Surfaces Oil spilled on plastic surfaces may damage the surface and must be cleaned immedi- ately with warm water. 11 Troubleshooting Compressor is not working. Read the “Safety Instructions” sec- • In case of sudden power failure or pulling tion first! the power plug off and putting back on, Check this list before contacting the ser-... - Page 37 • Large quantities of hot food may have perature of relevant parts reach the suffi- been recently placed into the product. cient level by changing the temperature >>> Do not place hot food into the of cooler or freezer compartments. product.
- Page 38 There is condensation on the product's • The product is not standing in full upright exterior or between the doors. position on the ground. >>> Adjust the stands to balance the product. • The ambient weather may be humid, this •...
-
Page 39: Disclaimer / Warning
12 DISCLAIMER / WARNING Some (simple) failures can be adequately Therefore, unless otherwise authorized in handled by the end-user without any safety the “Self-Repair” section below, repairs issue or unsafe use arising, provided that shall be addressed to registered profes- they are carried out within the limits and in sional repairers in order to avoid safety is- accordance with the following instructions... - Page 40 Hotpoint, and will void the war- ranty of the product. Therefore, it is highly recommended that end-users refrain from the attempt to carry...
