Page 1 KNX/EIB BUS Black & White Touch Thermostat Product Manual Black & White Touch Thermostat Manual-Ver1.0 TC0103...
Page 2: Table Of Contents
KNX/EIB BUS Black & White Touch Thermostat Product Manual Content 1. Overview .......................................3 2. Product and functional application overview ............................3 2.1 Product ......................................3 2.2 Functions .....................................3 3. Specification ......................................4 4. Dimensional drawings and connection diagrams ...........................4 5. Product operation and installation instructions ............................5 5.1 Product operation ..................................5 5.2 Installations ....................................6 6.
Page 3: Overview
KNX/EIB BUS Black & White Touch Thermostat Product Manual 1. Overview This manual provides you with detailed technical information on controlling the black and white full-screen temperature control panel, including installation and programming details, and explains how to use the device based on practical examples of use.
Page 4: Specification
KNX/EIB BUS Black & White Touch Thermostat Product Manual 3. Specification Bus Voltage 21-30V DC Bus Current ≤ 12mA Bus Rate ≤ 360mW Auxiliary Power 24 V DC Auxiliary Current ＜30 mA Auxiliary Power consumption < 0.72 W Temperature detection accuracy ±0.5 ℃...
Page 5: Product Operation And Installation Instructions
KNX/EIB BUS Black & White Touch Thermostat Product Manual 5. Product operation and installation instructions 5.1 Product operation ①On/off button; ②Air conditioning mode switching button, cooling mode → heating mode → air supply mode → dehumidification mode; ③The wind speed adjustment button is used to adjust the low, medium, high and automatic gears of the wind speed in the corresponding mode;...
Page 6: Installations
KNX/EIB BUS Black & White Touch Thermostat Product Manual 5.2 Installations (1) Remove the fixing bracket embedded in the back cover of the panel and install it on the standard 86 bottom box, and tighten the fixing screws; (2) Snap the control panel into the fixed bracket, that is, the installation is successful; (3) When you need to remove the panel, use a flat-blade screwdriver to gently pry the fixing bracket at the groove at the lower end of the panel;...
Page 7: Temperature Correction
KNX/EIB BUS Black & White Touch Thermostat Product Manual 2）“Toggle temperature unit”option：“Disabled”,“Enabled” When choose“Enabled”, will show the parameter as“Temperature unit polarity”，Options： “0：Centigrade,1:Fahrenheit”（When the value "0" is received, the temperature unit is Celsius; when the value "1" is received, the temperature unit is Fahrenheit.）、 “0：Fahrenheit,1: Centigrade”...
Page 8 KNX/EIB BUS Black & White Touch Thermostat Product Manual Figure 6.1.5.2 Backlight mode, options:“always”,“delay” ； When "always" is selected as the parameter, the following parameters appear: Parameter Description Backlight brightness Indicates the backlight brightness value, optional：0%、1%……100% Overwrite backlight brightness via Overwriting the brightness value through the object，option：“Yes”,“No”...
Page 9: Air Conditioning
KNX/EIB BUS Black & White Touch Thermostat Product Manual output" indicates the time detection sensor circularly outputs, optional: only once when triggered (Only trigger once), "1second" (1 second delay), 2seconds (2 second delay) ... "15seconds" (15 second delay). Indicates waking up the backlight through the object, optional: "Yes", "No"; when "Yes"...
Page 10 KNX/EIB BUS Black & White Touch Thermostat Product Manual Figure 6.2.2 1) Switching func. Indicates the switching function. When "Enabled" is selected, the following two parameters appear: ① "Switching polarity" indicates the switching polarity. The options are: 0: off, 1: on (the value 0 is sent out, which is off, and the value 1 is open), 1: off, 0: on (the value 1 is sent out, it is off, and the value 0 is open).
Page 11 KNX/EIB BUS Black & White Touch Thermostat Product Manual Figure 6.2.4 Parameter Description Heating mode, option：Disabled, Heating value Heating mode sends a value, filled in 0-255; enabled; when choose Enabled, Heating value for feedback Heating mode feedback value, filled in 0-255; Cooling mode, option：Disabled, Cooling value Cooling mode sends a value, filled in 0-255;...
Page 12 KNX/EIB BUS Black & White Touch Thermostat Product Manual Figure 6.2.5 Click the option in the red box above to set the relevant parameters, as shown in Figure 6.2.6 Figure 6.2.6 The parameter "Fan speed level" indicates the classification of wind speed level. The options are: Level 2, Level 3, and Level 5.
Page 13: Fan Coil
KNX/EIB BUS Black & White Touch Thermostat Product Manual Value for speed level 5 Could fill in 0-255 Value for speed level 1 for feedback Could fill in 0-255 Value for speed level 2 for feedback Could fill in 0-255 Value for speed level 3 for feedback Could fill in 0-255 Value for speed level 4 for feedback...
Page 14: Cooling Control
KNX/EIB BUS Black & White Touch Thermostat Product Manual Figure 6.3.2 1）Cooling control； Cooling control choose “Enabled”, will show below parameter： Cooling object type could choose 1bit/byte Cooling control feedback, options: disabled, Enabled 2）Heating control； Heating control choose “Enabled” , will show below parameter： Heating object type, optional 1 bit/byte Heating control feedback, option: disabled, Enabled 3）Fan speed control；...
Page 15: Floor Heating
KNX/EIB BUS Black & White Touch Thermostat Product Manual Indicates the ventilation mode, the options are: "Disabled", "Enabled"; when Venting mode "Enabled" is selected, the parameter "Value for setting heating" sets the value of ventilation, which can be filled in: 0, 1, 2...255; Recv setting fan speed Indicates receiving the set wind speed.
Page 16: Relay Control
KNX/EIB BUS Black & White Touch Thermostat Product Manual Click the option in the red box above to set the relevant parameters, as shown in Figure 6.4.2. Figure 6.4.2. 1）Relay control； Relay switch Indicates floor heating relay control output, options: Disabled, Enabled Status relay switch indicates the status of the receiving floor heating relay.
Page 17: Ventilation System
KNX/EIB BUS Black & White Touch Thermostat Product Manual Parameter Description Trigger temperature（degree） Indicates the temperature that triggers the alarm, which can be filled in 5-45; Send value for triggering alarm Indicates sending trigger alarm value, optional "off", "on" Cycle time for high temperature Indicates the time of high temperature alarm cycle, optional 1 second, 2 alarm seconds...120minutes...
Page 18: Setting Fan Speed
KNX/EIB BUS Black & White Touch Thermostat Product Manual 1) Inlet speed control； Fan speed control for air inlet, options：disabled, 1bit, 1byte； ① When "1bit" is selected, the parameter "fan inlet speed feedback" appears, indicating the intake fan speed feedback, and "Disabled" or "Enabled)" can be selected; ②When "1byte"...
Page 19: Public Function
KNX/EIB BUS Black & White Touch Thermostat Product Manual Send setting fan inlet speed Indicates sending feedback for setting the intake fan speed setting, selectable "Disabled" or "Enabled"; Recv setting fan outlet speed Indicates receiving the outlet fan speed, selectable "Disabled" or "Enabled"； Send setting fan outlet speed Indicates sending feedback for setting the outlet fan speed setting, selectable "Disabled"...
Page 20: Main Switch
KNX/EIB BUS Black & White Touch Thermostat Product Manual Figur6.6.2 1）Main switch ① Recv setting main switch means receiving setting main switch, options: Disabled, Enabled ② Send setting main switch means send setting main switch, options: Disabled, Enabled 2）Temperature Actual temperature represents the actual temperature. When "Enabled" is selected, the parameter "Source for actual temperature"...
Page 21 KNX/EIB BUS Black & White Touch Thermostat Product Manual actual humidity when the humidity changes the corresponding value)" appears, optional 1%, 2%...10% 4）Others Recv actual PM2.5 means receiving actual PM2.5 data, optional options: Disabled (, Enabled; Recv actual PM1.0 means receiving actual PM1.0 data, options: Disabled, Enabled; Recv actual HCHO means receiving actual formaldehyde data, options: Disabled, Enabled;...
Page 22: Communication Object Description
KNX/EIB BUS Black & White Touch Thermostat Product Manual 7. Communication object description The communication object is the medium through which the device communicates with other devices on the bus, that is, only the communication object can communicate on the bus. The following describes the role of each communication object in detail.
Page 23 KNX/EIB BUS Black & White Touch Thermostat Product Manual the communication object receives the value "0/1", the temperature control panel displays "ON/OFF"。 AC, Operating mode 8-bit Value-Output 1byte C,R ,T,U This communication object is enabled when the parameter "Operating mode" selects "Enable". This communication object is used to switch the operating mode.
Page 24 KNX/EIB BUS Black & White Touch Thermostat Product Manual and use the received feedback value to change the air conditioning temperature indication on the temperature control panel. Communication When the object receives the corresponding value, the temperature control panel indicates the corresponding temperature value. AC, Actual temperature 16-bit Value-Input 2 bytes...
Page 25 KNX/EIB BUS Black & White Touch Thermostat Product Manual FCU, Heating control Valve position-Output 1byte C,R, T,U This communication object is started when "Enabled" is selected in the parameter "Heating control" and "1byte" is selected in the "Heating object type". This communication object is used to send the heating valve value of the fan coil, and the data length is 1byte.
Page 26 KNX/EIB BUS Black & White Touch Thermostat Product Manual This communication object is started when "Enabled" is selected in the parameter "Recv setting mode". This communication object is used to receive the fan coil setting mode. FCU, Send setting mode 8-bit Value-Output 1byte C,R, T,U...
Page 27 KNX/EIB BUS Black & White Touch Thermostat Product Manual This communication object is used for floor heating relay control output. When the value "00" is sent, the floor heating is turned off; when the value "01" is sent, floor heating is on; FH, Status relay switch On/Off-Input 1bit...
Page 28 KNX/EIB BUS Black & White Touch Thermostat Product Manual This communication object is started when "Enabled" is selected in the parameter "Status high temperature alarm". This communication object is used to send high temperature alarm status feedback. When the floor heating exceeds the preset temperature warning value, the communication object sends the alarm value "01/00".
Page 29 KNX/EIB BUS Black & White Touch Thermostat Product Manual communication is used for fresh air outlet speed and speed status feedback (data length is 1 bit). FA, Air outlet speed 8-bit Value-Output 1byte C,R, T,U This communication object is enabled when "1byte" is selected in the parameter "Fan speed control for air outlet". This communication object is used for air outlet fan speed value control (data length is 1byte).
Page 30 KNX/EIB BUS Black & White Touch Thermostat Product Manual corresponding value. Pub, Recv main switch On/OFF-Input 1bit C,R, W,T,U This communication object is activated when "Enabled" is selected in the parameter "Public function". This communication object is used for public function switch settings of air conditioning, floor heating, and fresh air. When the value "00"...
Page 31 KNX/EIB BUS Black & White Touch Thermostat Product Manual This communication object is started when "Actual humidity" in the parameter "Public func" selects "Enabled" and "Source for actual humidity" selects "external knx bus". This communication object is used to transmit the total function through the knx bus.
Page 32 KNX/EIB BUS Black & White Touch Thermostat Product Manual backlight This communication object is started when "delay" is selected in the parameter "Backlight mode" and "Yes" is selected in "Overwrite backlight waking light via object". This communication object is used to rewrite the brightness value when waking up the backlight.
Page 33: Safe Use And Maintenance
KNX/EIB BUS Black & White Touch Thermostat Product Manual 8. Safe use and maintenance （1） Read all instructions carefully before use. （2） Establish a good ventilation environment. （3） During use, pay attention to moisture-proof, shock-proof, and dust-proof. （4） It is strictly prohibited to be exposed to rain, contact with other liquids or corrosive gases. （5）...
