Ultimate Products EK5872 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
1
2
3
4
5
Fig. 1
1.
Air fryer main unit
2.
Cooking compartment
3.
Cooking compartment handle
4.
Power button
5.
Temperature control buttons
6.
Match cook button
7.
LED display
8.
Function buttons
6
7
8
9.
Sync cook button
10. Non-stick coated cooking tray
11. Compartment divider
12. Time control buttons
13. Start/pause button
14. Viewing window
15. Digital control panel
User manual
9
10
Air fryer
15
14
13
12
11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EK5872 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ultimate Products EK5872

  • Page 1 User manual Air fryer Fig. 1 Air fryer main unit Sync cook button Cooking compartment 10. Non-stick coated cooking tray Cooking compartment handle 11. Compartment divider Power button 12. Time control buttons Temperature control buttons 13. Start/pause button Match cook button 14.

  • Page 2: Safety Instructions

    Please retain instructions for future reference. SAFETY INSTRUCTIONS ƒ When using electrical appliances, basic safety precautions should always be followed. ƒ Check that the voltage indicated on the rating plate corresponds with that of the local network before connecting the appliance to the mains power supply. ƒ...

  • Page 3: Do's And Don'ts

    ƒ Always use the appliance on a stable, heat-resistant surface, at a height that is comfortable for the user. ƒ This appliance should not be operated by means of an external timer or separate remote control system. ƒ Use of an extension cord with the appliance is not recommended. ƒ...

  • Page 4: Care And Maintenance

    Care and maintenance Before attempting any cleaning or maintenance, switch off and unplug the air fryer from the mains power supply and allow it to fully cool. STEP 1: Wipe the air fryer main unit with a soft, damp cloth and dry thoroughly. STEP 2: Clean the non-stick coated cooking tray, compartment divider and the cooking compartment in warm, soapy water, then rinse and dry thoroughly.

  • Page 5: Preset Functions

    NOTE: Refer to the recipe booklet for additional information and cooking guidelines. Preset functions STEP 1: Press one of the function buttons to use a preset cooking function. The display will cycle automatically between the preset time and temperature. These presets can then be adjusted using the time and temperature control buttons as required. The time and temperature control buttons may be held down in order to quickly adjust the time or temperature.

  • Page 6: Using The Air Fryer

    Check that the air fryer is cool, clean and dry before storing in a cool, dry place. Never wrap the cord tightly around the air fryer; wrap it loosely to avoid causing damage. Specifications Product code: EK5872 Input: 220–240 V ~ 50–60 Hz Output: 2300 W...

  • Page 7: Cooking Chart

    Cooking chart Manual air fry chart Ingredient Amount Temperature Cooking time Vegetables Asparagus 200 g 2 tsp 200 ºC 8–12 mins Whole, trimmed Bell peppers 2 peppers None 200 ºC 16 mins Whole Broccoli 1 head (400 g) 1 tbsp 200 ºC 9 mins Cut into 2.5 cm florets...
  • Page 8 Manual air fry chart Beef Burgers 4 quarter pounders None 190 ºC 12 mins 2.5 cm thick Steaks 2 x 200 g sirloin None 200 ºC Rare: 1.5 cm–2.5 cm thick 9–10 mins Medium rare: 10–12 mins Well done: 18–20 mins Pork Bacon 4 strips...
  • Page 9 Honey pork chops RECIPES Ingredients 2 pork chops 85 g honey 3 tbsp soy sauce 1 tbsp lime juice 1 tsp garlic, minced Method Mix together all of the ingredients, except for the pork chops, in a large bowl. Dip the pork chops into the mixture, cover and refrigerate for 1–2 hours.
  • Page 10 carefully place the chicken thighs into the 1 green pepper, sliced relevant cooking compartment. 1 yellow pepper, sliced Check that the chicken is cooked through 1 orange pepper, sliced before serving. 1 courgette, sliced at an angle Serve immediately with a variety of sides. 2 tbsp olive oil 2 tbsp soy sauce Fried Cajun salmon...
  • Page 12 Manufactured by: Ultimate Products UK Ltd., Victoria Street, Manchester OL9 0DD. UK. Ultimate Products Europe Ltd., 19 Baggot Street Lower, Dublin D02 X658. ROI. MADE IN CHINA. CD290923/MD300524/V3...
