Ver 2.02v2
Date : Nov.29.2005, Nov.14.2007
Rev.
2.00
21.Nov.2005
2.01
29.Nov.2005
2.02
5.Dec.2005
Copyright 2005 DENON Co.,Ltd.
Specification
for
Serial Interface DVD -758
M.Uehara
First Issue
M.Uehara
Delete ACK, Modify Disc type code,
Delete Some value of "Answer codes"
M.Uehara
1 page of 46
