- Page 1 Explosion Proof Marine Motors Motor Manual HMCX-80-400 Code: SH123018-03 Together we outsmart the ordinary...
-
Page 2: Table Of Contents
Contents Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Thermal Protection and Heater . -
Page 3: Notice
1.2.1 Explosion protection types FS 80-355 The motors have an embossed “Ex” mark clearly and permanently af- This manual must be followed to ensure proper and safe installa- fixed at the lower left corner of the nameplate. The explosion-proof tion, operation and maintenance of the motor. Products must be enclosure type, including the Ex mark, temperature group, electri- handled by qualified personnel, and health and safety requirements cal classification and equipment protection group, is shown on the and national legislation must be observed. Ignoring these instruc- nameplate. tions will invalidate all applicable warranties of Hoyer Motors. Type 1: db eb IIB/IIC T4/T5 1.1 General information Mark, Explosion-proof HMCX series explosion-proof three phase induction motors (here- Type of protection: inafter referred to as “motors”) can be used safely in locations... -
Page 4: Certification Designations Fs 400
1.3 Certification designations FS 400 Type 3: IIIB/ T130°C IIIC 0722 II 2G Ex db eb IIB T4 Gb, CNEX 21 ATEX Mark, Explosion-proof 0005X Type of protection: Dust explosion-proof type 0722 II 2G Ex db IIB T4 Gb, CNEX 21 ATEX Dust Group 0005X Max. surface temperature 0722 II 2D Ex tb IIIB/IIIC T130°C Db, CNEX Equipment Protection Level 21 ATEX 0005X 1.4 Explosion protection IECEx CNEX 21.0006X Ex db eb IIB T4 Gb Markings such as Ex db IIB/IIC T4 Gb or Ex db eb IIB/IIC T4 Gb IECEx CNEX 21.0006X Ex db IIB T4 Gb indicate where the motor is permitted be used and that it has been IECEx CNEX 21.0006X Ex tb IIIB/IIIC T130°C Db designed, built and approved according to the relevant IEC and European standards required for operation in potentially explosive 1.3.1 Explosion protection types FS 400 areas. -
Page 5: Safety Instructions
1.8 Motor type designation FS 80-355 on again. • Make sure that the equipment is de-energized. This applies to HMCX-315 motors with the following type designa- • Earth and short out the equipment. tion: • Cover any adjacent electrically live parts, or block them with a 1 HMCX-315ab-c screen or barrier. 2 HM Hoyer Motor • Carefully follow the assembly instructions provided for the 3 C Cast iron equipment. Work on the equipment or system must only be 4 X Explosion proof performed by suitable qualified personnel in accordance with 5 315 Shaft height (80, 90, 110, 112, 132, 160, 180, EN 50110-1/-2 (VDE 0105, Part 100) and IEC 60079-14-17- 200, 225, 250, 280, 315, 355) 19 . -
Page 6: Motor Type Designation Fs 400
1.8.1 Motor type designation FS 400 Duty: S1 (continuous operation) or S2–S10 This applies to HMCX-400 motors with the following type designa- The stator windings are designed with Class F or Class H insulation. tion: 1.9.3 Electrical conditions FS 400 1 HMCX-400Ha-b 2 HM : Hoyer Motor Rated frequency: 50Hz/60Hz 3 C Cast iron Rated voltage: 4 X Explosion proof • 380 V, 400 V, 415 V, 440 V, 460 V, 480 V, 500 V, 525 V, 550 5 400 Shaft height 400 V, 575 V, 600V, 660 V, 690 V, 720 V, 950 V and up to 1000 V 6 H Length of frame 7 a Core length: 1, 2, 3, 4, 5, 6, 7, 8 … Duty: S1 (continuous operation) or S2–S7 8 b Number of poles: 2, 4, 6, 8, 10, 12, 14, 16 The stator windings are designed with Class F or Class H insulation. Note: If the ambient and electrical conditions are different from the above mentioned, please see the motor’s main and auxiliary... -
Page 7: Specific Conditions For Use 400
For VFD operation, the manufacturer’s instructions for machine fed All fasteners used for connecting parts of the flameproof motor en- from converters have to be respected The following VFD operation closure together shall have a minimum yields stress of 640 N/mm parameters must be complied with: • switching frequency: ≥2000 Hz (this includes: end-shields to frame, cover plate to frame, main ter- • inverter output du/dt: ≤1500 V/µs minal box adapter to frame, auxiliary terminal box base to frame, inner/external bearing cover to end-shields, main terminal box Use fasteners with a minimum yield stress of 640 N/mm adapter to terminal box-base). After repainting of explosion-protected motors or after impregna- All other fasteners shall have a minimum yield stress of 320 N/mm tion of a complete stator that has been rewinded, bigger layers of paint or resin can be found on the surface of the motors (This can After repainting of explosion-protected motors or after impregna- result in electrostatic charges with risk of explosion during dis- tion of a complete stator that has been re-winded, bigger layers charge). Nearby charging processes can also result in electrostatic of paint or resin can be found on the surface of the motors (This charge of complete surfaces or parts of the surface. There is the... -
Page 8: Receipt, Transport And Storage
• Use transport locks for all transport operations. motor is equipped with anticondensation heaters, they should • Avoid moisture and shocks during transport. be energized. Proper operation of the anti-condensation heat- • Check the motor for external damage. ers must be checked periodically. If the motor is not equipped • If damage is found, inform the sales representative of Hoyer with anti-condensation heaters, other methods of heating Motors. the motor must be used to prevent water vapor from condens- • Check all nameplate data and compare it with the require- ing in the motor. ments for the motor. • A stable support free from excessive vibration and shocks. If • Remove transport locks if present. - Page 9 Do not use the eyebolts when the ambient temperature is below Table 1: Minimum dimensions of eyebolts and spreader beams -20°C. At this temperature the eyebolts may break, causing per- Frame Diameter t Horizontal Vertical sonal injury and/or damage to equipment. The direction of the load size applied to the eyebolts must not exceed 45° (Øt) from the center line of the threaded shank. Spreader beams are recommended for lifting. See Table 8 for installation dimensions of eyebolts and mini- mum dimensions of spreader beams and chain lengths. Do not remove the transport safety device on the shaft until after the motor has been placed on the specified base. To protect the bearings in case of further transport, the transport safety device must be fitted again.
-
Page 10: Installation And Commissioning
Installation and Commissioning MΩ. The insulation resistance is not acceptable if the meas- ured value is less than 5 MΩ. When oven drying the windings, ATTENTION! set the oven temperature to approximately 85°C for 10 to 18 The electrical control system must ensure that the motor hours, followed by 100°C for 7 to 9 hours. The nominal insu- voltage and the heater voltage cannot be applied at the same lation resistance drops by 50% for every 20°C rise in motor time. temperature. Measuring equipment must always be calibrated at least every year. 3.1 Preparation During installation, the motor must be aligned with the driven •... -
Page 11: Removing The Terminal Box Cover
• Horizontal positioning: Fix the motor axial position and make sive starts per hour is 2 with the motor cold or 1 with the motor sure the axial gap is uniform. warm. • Stable support: Vibration free, accurate machine alignment and balanced drive. • Foot/Foot-flange mounting: Mount the motor with the correct bolts and tightening torques. Make sure the motor feet and/ or flange bolts are in full contact with the mounting surface. 3.4 Removing the terminal box cover ATTENTION! Follow the instructions carefully to remove the terminal box cover. Motors frame size 180 and below have a special threaded terminal box cover design. Frame size 400: See separated appendix; Disassemble and assemble of terminal box cover Ex db eb 400. 3.4.1 Removing the terminal box cover, frame size 80 to Unscrew the locking bolt on the terminal box cover. -
Page 12: Electrical Connection And Wiring
The motors are designed to operate with supply variations con- minal box to the desired position. Then retighten the fasteners to forming to IEC 60034-1, Zone A: ±5% voltage and ±2% frequency. the torque specified for the thread size. The motors will operate with greater variations according to Zone B of IEC 60034-1 section 7.3, but with larger variation in perfor- Table 2: Tightening torques - Terminal box mance. Thread size Tightening torque 6 Nm Three-phase motors manufactured by Hoyer Motors are designed 10 Nm according to IEC 60034-1 and can operate with the rated power 25 Nm and torque load within the mains voltage and frequency variations 49 Nm of zone A and, for a short time, of zone B. 85 Nm Earthing must be carried out according to local regulations before 210 Nm the motor is connected to the supply voltage. 425 Nm The power connection of the explosion-proof motor must comply with the provisions of EN IEC 60079-14 in addition to the usual installation provisions. Overload protection by means of a motor... -
Page 13: Connection Diagram
The main wires must be connected to the respective terminals and • Motors with nameplate data D/Y 400/690 V and 440 V are must be secured with compression nuts, metal washers, etc. Un- conected as delta (D). used cable entries must be closed to maintain the IP rating of the terminal box. Check that the gasket is intact before refitting the The connection diagram is labelled inside the terminal box. terminal box and cover. IECEx/ ATEX certified cable glands suitable Generally, power to motors must be supplied and protected for the environment must be used. The IP rating of the cable gland through protective devices such as RCDs, fuses, MCBs, MCCBs, should be at least same as the motor protection rating. -
Page 14: Thermal Protection And Heater
Thermal Protection and Heater The thermal sensors in the stator windings, and the Ex eb certified thermal sensors for the bearings, shall be connected to a suitable Thermal protection is used to prevent motor overheating and for tripping units that have been functionally tested for this purpose. monitoring purposes. 5.4 Winding temperature sensor and heater 5.1 Thermal protection with thermistors (PTC) The cable lugs should be connected between two spring wash- All standard motors have PTC thermistors located in the stator ers or terminal clamps. The cable lugs of the earthing conductors windings. should be fitted between the spring washers of the earthing stud and earthed reliably to ensure good electrical contact and clear- These PTC thermistors must be connected to the variable speed ance. - Page 15 Temperature sensors connection diagram (D2 SPARE) (E2 SPARE) 1-12 for connecting bearing temperature measurement resistor (T2 SPARE) (R2 SPARE) (S2 SPARE) 13-30 for connecting stator temperature measurement resistor Heater connection diagram Figure 7: Wiring diagrams for temperature sensors and heater...
-
Page 16: Motor Data And Parts
Motor Data and Parts The insulating parts of terminal bushings and connecting plates in the terminal box are made of insulating material. 6.1 General information The mechanical construction of the motors in this series is designed The basic mounting arrangements of the motors are IMB3, IMB35, such that if an explosive mixture at the service site penetrates into IMB5 and IMV1. Other special mounting arrangements are also the motor and ignites for any reason, the flameproof enclosure will available upon customer request. prevent ignition of the explosive mixture surrounding the enclosure. The cooling type of the motors is IC411. The motors are designed with a sturdy enclosure, proper air gap The motors are provided with a cylindrical shaft extension with or electrical clearance and length of flameproof joint surfaces for power transmission by means of a coupling or a spurgear unit. -
Page 17: Terminal Boxes
6.3 Terminal boxes Frame size 132–160: The terminal box of the motor is located on top of the motor frame. The terminal boxes of motors with frame size 80 to 355 are de- signed with six terminals suitable for the various voltage options defined in the associated certificates. A steel or copper electroplat- ed stud for earthing is present inside the terminal box. Before working on the motor or attached machinery: • Ensure that all supply voltages are switched off and locked out. • Switch off auxiliary power circuits for accessories such as anti- condensation heaters. • Check the supply voltage and frequency by comparing them Frame size 180–225: with the rated data on the nameplate and the data sheet. • Ensure that the terminal box is clean and dry. • Ensure that the flame path of the terminal box is intact and free of any form of damage. - Page 18 Terminal box for CAR-Ex d Frame size 315: Frame size 80–112: Frame size 355: Frame size 132–160: Frame size 400: Frame size 180–200: Frame size 225–280: For motors with EAR-Ex e or CAR-Ex d terminal boxes, ensure strict compliance with the clearances specified in EN IEC 60079-7 between all enclosure components, the flameproof joint and bare conductors inside the terminal box, bare conductors and the metal enclosure (see Table 4). Tighten the screws and nuts on live parts to the torques specified below (see Table 5).
-
Page 19: Rotating Terminal Box Ex Db
6.5 Cable glands Table 4: Clearance and creepage distance The cable glands must be IECEx/ATEX certified and must comply Rated Minimum Minimum creepage with EN IEC 60079-0 and EN IEC 60079-11. Pay attention to the voltage clearance distance U [V] [mm] [mm] protection rating and locking of the cable gland. If the original ca- ble glands or blind plugs need to be replaced, please contact Hoyer. ≤200 ≤250 10.3 For the maximum size of the main cable entry for terminal boxes, ≤320 10.0 10.0 see the specifications in Table 6. Thread size for auxiliary entries, ≤400 10.0 10.0 e.g. for PTC thermistor or heater: M20×1.5. ≤500 10.0 12.5 ≤630 Table 6: Mains cable entry for Ex e and Ex d terminal boxes ≤800... -
Page 20: Special Condition For Use Fs 400
If the ambient temperature is above 40°C but does not exceed 60°C, the temperature values in the table above must be increased accord- ing to the difference between 40°C and the actual temperature. Example: With frame size 112 and Tamb = 55°C, the maximum rated operating temperature of the cable must be (55 – 40) = 15 + 56 = 71°C If the motor has direct cable entry (flying leads), the free end of the cable leading to the motor must be connected according to the regu- lations applicable to the connection range. If the cable entry fitting on the motor has a strain relief, the cable can be routed freely; otherwise the cable must be secured near the motor to provide strain relief. The maximum operating temperature of the cable must not be exceeded. 6.5.1 Special condition for use FS 400 Suitable heat-resisting cables must be applied for mains supply and for auxiliary connections. 6.6 Sealing gasket The sealing ring is made from rubber XH - 21, the mechanism phys- ical property of which conforms to GB/T7594.9. The material of sealing gasket should pass the tests for endurance top heat and to cold according to 26.8 and 26.9 of GB 3836.1-2010. If tolerance is not indicated, the limit deviation value will be that GB/T1804 - m. The sealing ring is made of rubber Shore-hardness 45-55o. The size of minimum outer diameter applied for cable is marked on end face surface by means of die cast (see the specifications in table) Specification Note: A - Manufacturing dimension B - Minimum permission cable diameter on concentric circle 6.7 Bearings The motors are designed with ball or rolling bearings. See the nameplate for the specific bearing type. -
Page 21: Variable Speed Drive Operation - Fs 80-355
Variable Frequency Drive Operation 60 Hz - FS 80-355 a. 6–60 Hz: Variable torque (VT 10:1) Motors for variable speed drive (VFD) operation are equipped as standard with positive temperature coefficient (PTC) thermistors b. 30–60 Hz, 100% TN: Constant torque (CT 2:1, 100% TN) in the windings for monitoring and protection. The permissible op- erating characteristics in this mode are stated on the nameplate or c. 6–60 Hz, 75% TN: an additional label. Constant torque (CT 10:1, 75% TN) d. 60–90 Hz, 100% P2: An output filter must be installed based upon the length of the ca- Constant power (CP, 100% P2) ble on the motor side of the VFD. Filter selection and the maximum cable length depend on the instructions and data provided by the VFD Torque Curve VFD manufacturer. Two methods are used to prevent shaft currents: If the measured shaft stray current is more than 300 mA, the bearing on the non- drive end is replaced by an insulated bearing. Otherwise a shaft earthing ring is fitted to discharge the shaft current. -
Page 22: Operation
Operation 8.1 Considerations Safety equipment must be used during installation and operation at the site. The motor is only intended for fixed installation and use by qualified personnel. Motors must only be used according to the rated nominal values on the motor nameplate. 8.2 Checklist Figure 9: Minimum distance to wall/objects Check the following before powering on the motor: • All mechanical and electrical connections are ready for start- Table 8: Minimum distance from wall or objects • The insulation resistance values correspond to the data in Sec- IEC frame size Minimum distance from fan cover to wall (X) [mm] tion 3.2. • The earthing connection is fitted correctly. • Couplings and transmissions are sufficiently aligned to allow the machinery to run smoothly. -
Page 23: Maintenance
Maintenance The bearings are regreased via the grease nipples located on the bearing plates or the bearing caps, preferably while the Maintenance must be carried out regularly on motors, including motor is running. monthly maintenance and yearly maintenance (e.g. routine inspec- • The drip space in the bearing cap for discharge of old grease tion and overhaul). is large enough to collect the old grease during the nominal Motor is delivered with protected antirust at machining surfaces, bearing service life with state-of-the art regreasing. if removing the protection antirust, the surfaces must be mainte- •... - Page 24 Table 9: Regreasing intervals in hours for horizontal installation anti-corrosion grease must be applied and a close fit of the flame- proof joint with no gap must be ensured. Ambient Speed Speed temperature up to 1800 rpm up to 3600 rpm 40°C 5000 h 2500 h 45°C 4000 h 2000 h 50°C 2500 h 1000 h 60°C 2000 h 500 h ATTENTION! • For motors with enhanced performance in heavy-duty drive conditions such as belt or gear drive with addition- al bearing loads and in vertical installation, the values in the table must be reduced by 50%. •...
-
Page 25: Disposal And Environmental Protection
(WEEE) is not handled correctly. More detailed information is available from the relevant local au- thority. 10.2 RoHS and REACH All motors from Hoyer Motors comply with the RoHS directive and the REACH regulation. Official documents can be downloaded from the Hoyer Motors website hoyermotors. com. 10.3 Electric motors Electric motors are manufactured from ferrous metals (steel, cast iron), non-ferrous metals (copper, aluminum) and plastics. At the end of their service life, motors must be disposed of according to international and local regulations. Waste handling facilities must be licensed and must comply with the environmental requirements of the member states they are located in. -
Page 26: Troubleshooting
Troubleshooting Refer to the table below for common electrical faults and trouble- shooting. Trouble Cause Remedy 1) Improper power supply. 1) Check the switch, fuses, each set of contacts and cable terminals. 2) At the location where the open circuit is found, apply heat to raise the tempera- ture to the level permitted by the insulation class in order to soften the varnish 2) Open circuit in winding. coating, then repair the broken conductor with wire of the same specification. Then re-tape, varnish and dry the repair for good insulation. 1. Motor fails to start. 3) Follow the procedure described above. In addition, fit insulation on or around the 3) Windings earthed or interphase short circuit. earthed or shorted parts, then varnish and dry them. 4) Check the connection diagram and redo the connections (including binding, 4) Incorrect winding connections. insulation and varnishing). 5) Blown fuses. 5) Replace fuses with the proper type and rating. 6) Incorrect cable connections to the control system. 6) Check the connections against the diagrams supplied with control system. 1) Check the power cable, motor cables, fuse and each contact in the switch to 1) Single-phase start. locate and correct the problem. 2) Motor overloaded or blocked. 2) Adjust the load to the rated load and correct fault in the driven machinery. 2. Fuses blown after 3) Replace fuses with the proper type and rating. Fuse selection is generally based the motor is energized. 3) Fuse rating too low. on the following formula: rated current of fuse = starting current/(2–3). 4) Connecting cable between power supply and motor 4) Find the short and correct it. shorted. 1) Motor overloaded or blocked. 1) Reduce the load and locate the blockage. 2) Replace fuses in fuse box, secure loose nuts on terminal studs. Use a multimeter 2) Power supply not completely switched on. - Page 27 Trouble Cause Remedy 1) Supply voltage too low. 1) Check the supply voltage at the motor input with a voltmeter or multimeter. 2) Windings designed for ∆ configuration are miscon- 2) Change Y connection to ∆ connection. nected in Y configuration. 5. The motor does not accelerate up to 3) Look for cracks near the rings. A new rotor may be required, as repairs are usually 3) Broken rotor bars or loose rotor. nominal speed. temporary. 4) Number of winding turns exceeds design value when 4) Rewind as necessary. rewound. 1) Damp windings 1) Heat or dry the winding. 6 Low insulation resist- 2) If the insulation can be still be used after checking, then clean, dry and revarnish 2) Ageing winding insulation ance. it. Otherwise replace the insulation. 1) Bearings worn out or short of grease. 1) Replace the bearings. 2) Stator or rotor core loose. 2) Check for the cause of vibration, repress the core. 3) Voltage too high or unbalanced. 3) Measure the voltage of the power supply, find the reason and correct it. 7. Motor emits 4) Clean bearings and regrease. The amount of grease to be added should be one- abnormal sound during 4) Bearings short of grease. third to half of the net volume of the bearing housing. operation. 5) Repair the fan and fan cover to achieve correct dimensions and clear the air 5) Fan colliding with fan cover or air vents blocked. vents. 6) Uneven air gaps or contact between stator and rotor. 6) Adjust the air gap and correct the assembly.
-
Page 28: Standard
Standard Name IEC Standard Number Explosive atmospheres - Part 0: Equipment - General requirements IEC 60079-0 Explosive atmospheres - Part 1: Equipment protection by flameproof enclosures "d" IEC 60079-1 Explosive atmospheres - Part 7: Equipment protection by increased safety "e" IEC 60079-7 Rotating electrical machines - Part 30-1: Efficiency classes of line operated AC motors (IE code) IEC 60034-30-1 Rotating electrical machines - Part 1: Rating and performance IEC 60034-1 Rotating electrical machines - Part 2-1: Standard methods for determining losses and efficiency from tests (excluding machines for traction IEC 60034-2-1 vehicles) Rotating electrical machines - Part 7: Classification of types of construction, mounting arrangements and terminal box position (IM Code) IEC 60034-7, IDT Rotating electrical machines - Part 8: Terminal markings and direction of rotation IEC 60034-8 Rotating electrical machines - Part 6: Methods of cooling (IC Code) IEC 60034-6 Environmental testing - Part 2-30: Tests - Test Db: Damp heat, cyclic (12 h + 12 h cycle) IEC 60068-2-30 Rotating electrical machines - Dimensions and output series - Part 1: Frame numbers 56 to 400 and flange numbers 55 to 1080 IEC 60072-1 Rotating electrical machines - Part 5: Degrees of protection provided by the integral design of rotating electrical machines (IP code) IEC 60034-5 - Classification Rotating electrical machines - Part 14: Mechanical vibration of certain machines with shaft heights 56 mm and higher - Measurement, IEC 60034-14 evaluation and limits of vibration severity Acoustics — Test code for the measurement of airborne noise emitted by rotating electrical machines ISO 1680 Rotating electrical machines - Part 9: Noise limits IEC 60034-9 Electrical insulation - Thermal evaluation and designation IEC 60085 Classification of environmental conditions - Part 2-1: Environmental conditions appearing in nature - Temperature and humidity IEC 60721-2-1 IEC standard voltages IEC 60038 Packaging — Distribution packaging — Graphical symbols for handling and storage of packages... - Page 30 Scan here to contact us for more information Motor Manual, October 2024 Important notice. Text and data in this manual are not binding and we reserve the right to implement changes without further notice .
