Berghoff HOT-W17AH-D1-3 Quick Start Manual

HOT-W17AH-D1-3
220-240V- 50-60HZ. 1500W
TEA MAKER
Product structure diagram
Glass pot
Handle
Body
Base
LED display
Instructions for function operation
Before using the tea maker,Please follow below preparation:
Using for the first time or after a long time without using, please add
water to the maximum water level and boil it for 1-2 times to clean
the inside of the tea maker body. Please do not drink it.
Do not touch the spout and the overflowing hot steam from the pot
during boiling water.When boiling water,please close the lid, and do
not open the lid during boiling to avoid burning.
Stand-by Mode
After connecting to the power, all the function lights will be on for one
second, then all the function pattern will be on and the LED display will
flash"- -" and " " the button light will flash with red color. If there's no
operation within 5minutes, there will be only the" "button flashing with
red color and all the other lights will be off,then can press the flashing
" " button to awaken the stand-by mode.
" "Fast Boiling Button
1. When on the stand-by mode, press the " " button to enter the
boiling mode,all the function lights are on,and the the "
on with red color .After finish boiling it will automatic enter into the
keep warm mode.And the " " button light will turn into blue color.
The defaulted keep warm time is with 90±5 for 2 hours.(Or can press
the"Timing"button before boiling to choose the desired keep warm
time,the setting time rang is from 1 to 10 hours. During the keep
warm time,the LED display will show the instant temperatures.
2. During the working mode, can press the " " button to stop working.
Then it will go back to the stand-by mode, all the functions lights are
on, and the LED display will flash"- -". If without operation within 5
minutes,then it will enter into sleeping mode. The " " button light will
flash with red color, and all the other function lights will be off.
"Tap Water" Button For Tap Water
1. When on the stand-by mode, press the"Tap Water"button to set the
keep warm temperature,the setting temperature ranges are 45-50-
55-60-65-70-75-80-85-90C. If there's no further operation within 3
seconds after setting,it will automatically start boiling,during the boiling
time,all the lights are on and the "Tap Water" button is flashing. After
finish boiling then will enter into the keep warm mode, the "
light will turn into blue color. The defaulted keep warm time is 2 hours.
(Or can press the "Timing"button before boiling to choose the desired
keep warm time,the setting time rang is from 1 to 10 hours). After enter
into the keep warm mode,the"Tap Water" button light will flash each 3
seconds, and the LED display shows the instant temperatures.
2. During the working mode, can press the "
working. Then it will go back to the stand-by mode, all the
functions lights are on, and the LED display will flash"- -". If
without operation within 5 minutes,then it will enter into
sleeping mode. The " " button light will flash with red color,
and all the other function lights will be off.
"Purified"Button for Pure Water
1. When on the stand-by mode, press the"Purified" button to
choose the desired temperatures,the setting temperature
ranges are 45-50-55-60-65-70-75-80-85-90C. If there's no
operation within 3 seconds after setting,it will automatically
start boiling,during the boiling time,all the lights are on and
the "Purified" button is flashing. After finish boiling then will
enter into the keep warm mode, the "
turn into blue color.The defaulted keep warm time is 2 hours.
(Or can press the"Timing"button before boiling to choose the
desired keep warm time ,the setting time rang is from 1 to 10
hours). After enter into the keep warm mode,the "Purified"
button light will flash each 3 seconds, and the LED display
shows the instant temperatures.
" button is
2. During the working mode, can press the "
working. Then it will go back to the stand-by mode, all the
functions lights are on, and the LED display will flash"- -". If
without operation within 5 minutes, then it will enter into
sleeping mode. The " " button light will flash with red color,
and all the other function lights will be off.
"Timing"Button
1. After selecting the desired function and press the "Timing"
button, then the"Timing"button light is flashing which means
can choose the desired keep warm time.
2. The set keep warm time range is1H-2H-3H-4H-5H-6H-7H-
8H-9H-10H, and each time is 1 hour.
" button
" button to stop
" button light will
" button to stop
