Vestil HDU-C Series Instruction Manual

HDU-C-S
Receiving instructions:
After delivery, IMMEDIATELY remove the packaging from the product in a manner that preserves the
packaging and maintains the orientation of the product in the packaging; then inspect the product closely
to determine whether it sustained damage during transport. If damage is discovered during the
inspection, immediately record a complete description of the damage on the bill of lading. If the
product is undamaged, discard the packaging.
NOTES:
1) Compliance with laws, regulations, codes, and non-voluntary standards enforced in the location where
the product is used is exclusively the responsibility of the owner/end-user.
2) VESTIL is not liable for any injury or property damage that occurs as a consequence of failing to apply either:
a) Instructions in this manual; or b) information provided on labels affixed to the product.
responsible for any consequential damages sustained as a result of failing to exercise sound judgment
while assembling, installing, using or maintaining this product.

Table of Contents

Hazard identification: explanation of signal words.............................................................................. 2
Safety Guidelines....................................................................................................................... 2
Product Specifications by Model........................ ........................................................................... 3
FIG. 1A: MDU-C exploded parts diagram......................................................................................... 4
FIG. 1B: Upright posts................................................................................................................ 4
MDU-C-6 & MDU-C-8 bills of materials.......................................................................................... 5
MDU-C-10 bill of materials.......................................................................................................... 6
Assembly instructions............................................................................................................. 6-8
Maintenance..................................................................................................................................... 8
Limited warranty......................................................................................................................... 9
