  • Page 1 SolShare Installation Manual AUS/NZ VERSION...
  • Page 2 The technical instructions and illustrations contained in this manual are to be treated as confidential and no part may be reproduced without the prior written permission of Allume Energy and end users may not divulge the information contained herein or use this manual for purposes other than those strictly connected with correct use of the equipment.
  • Page 3 As a result, please follow the guidelines in this manual carefully. Installations that contravene these guidelines are not covered under warranty unless a written exemption from Allume is provided. SolShare is designed to meet Australian and New Zealand conditions, regulations and codes.
  • Page 4: Table Of Contents

    Contents Commissioning Document Handling and Safety Instructions Safety symbols information Important safety instructions I/ What's in the box SolShare Box Regional Pack Installation overview II/ Mounting SolShare A. Installation site selection B. Installation III/ Electrical connection A. Input connection B. Output connections C.
  • Page 5: Commissioning Document

    Commissioning Document Important: ☝ To be completed during installation and entered to commissioning app. Please leave a copy of this page in the main switchboard for service purposes. Installer Electrician Name: License Number: Installer Training Certificate Company: Number: Installation Address: Postcode: State SolShare Serial...
  • Page 6: Handling And Safety Instructions

    Handling and Safety Instructions This guide is provided to help the installer understand a typical SolShare installation procedure. Installations may vary depending on the existing electrical infrastructure and local electrical safety standard. It is the responsibility of the electrician to ensure their installation meets the local electrical safety standard.
  • Page 7: Important Safety Instructions

    Important safety instructions Save these instructions: ☝ This manual contains important instructions for SolShare 3P-35A that shall be followed during installation and maintenance of the power division control system. Warning: Opening of SolShare must only be performed by a certified electrician. Warning: This equipment is connected to multiple sources of supply.
  • Page 8 Caution: The unit must be operated according to the technical specification datasheet provided with the unit. Caution: Installations may vary depending on the existing electrical infrastructure and local electrical safety standard. It is the responsibility of the electrician to ensure their installation meets the local electrical safety standard.
  • Page 9: I/ What's In The Box

    I/ What's in the box SolShare Box Make sure SolShare is intact following transportation. If there are any signs of visible damage, please contact your dealer immediately. Carefully check that all of the components have been supplied. If anything is missing, contact your dealer. SolShare unit Mounting bracket Locking plate...
  • Page 10: Installation Overview

    Guidance on this is covered below and in the supporting SolShare System and SLD Design guidelines document that is available from the Allume Document Library. A hard copy of the project SLD must be kept on-site at all times and be located in the Main Switchboard (MSB).
  • Page 11: Ii/ Mounting Solshare

    II/ Mounting SolShare A. Installation site selection To minimise cabling required, SolShare should be mounted as close to the main switchboard as possible. The following mounting requirements must be met when selecting the install location. Failure to do so will void warranty. Minimum clearances, shown below, are required for installation and maintenance ●...
  • Page 12: Installation

    B. Installation Follow the steps below to mount the brackets and enclosure: Important: ☝ The mounting wall and fastener selection is at the discretion of the installer. Weight rating fasteners should be rated to at least 30kg of shear force per fastener. It is the installer's responsibility for appropriate site selection and bracket fastener choice.
  • Page 13 Insert the locking bar through the mounting bracket as shown. If required, a customer supplied padlock can be fitted to the locking bar to secure the SolShare to the wall. Ensure SolShare is securely fastened to the wall and locked into place.
  • Page 14: Iii/ Electrical Connection

    III/ Electrical connection Lift up cover into the Connection Position to reveal the lower section of SolShare, where the electrical connections are made. SolShare as you find it, with cover in the Closed To reveal the lower section, slide cover up about Position.
  • Page 15 The primary SolShare install interfaces are as follows: connector sockets Input and output terminals Earth bar Pre-existing ground connections Replace the supplied caps with suitable cable entry glands. Underside of SolShare The cables should be inserted through the appropriate glands, per the ‘SolShare underside view’...
  • Page 16: Input Connection

    A. Input connection All wiring is conducted on the AC side of the inverter. SolShare requires a three-phase, grid-connected inverter to be used in the PV installation. The solar input cables must come from an Inverter Supply Main Switch, ideally located in an accessible location from the main switchboard. To wire the input cables into SolShare, the following steps should be taken: Measure out the input cables and cut to Strip cable sheath back by approximately 100mm.
  • Page 17: Output Connections

    B. Output connections Please refer to your Project Single Line Diagram (SLD) on where to connect SolShare to the main switchboard. Your project Single Line Diagram (SLD) should be designed in accordance with the SolShare System, SLD Design Guidelines, and relevant standards and codes. If no project SLD exists, please contact the project owner or system design engineer.
  • Page 18 Install the Isolation Box and connect SolShare outputs Secure the Isolation Box to the wall; mounting it close to the base of SolShare but with enough distance for wiring and maintenance. Ensure it will be protected from the elements. Scan this QR code to access the Isolation Box Wiring Document Install and wire the air gap isolation components into the Isolation...
  • Page 19 Wiring from the Isolation Box to the solar point of connection, per unit to GRID from SOLAR At the Main Switchboard, ensure the ‘Tenancy Main Switch SERVICE SIDE (Inverter Supply)’ and ‘Tenancy Main Switch (Normal Supply)’ S O L S H A R E 5 0 SolShare output breakers are correctly installed for each unit.
  • Page 20 Warning: Ensure the phase of the solar supply correctly matches the phase of the unit’s supply from the grid. Additional circuit breakers must be sized to perform overload protection for SolShare output cables. The solar system max output must be less than the main circuit breaker rating of every connected unit.
  • Page 21: Running Current Transformer Tails

    C. Running current transformer tails Area of focus: Electricity Meter panel X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X CT conduit X X X X X X X X X X X X...
  • Page 22 Current transformers to SolShare connections Wiring tails to SolShare: Connect the CT cabling to the CT connector block, as per the diagram to the right. To do this: a. Push the orange tab in and hold. b. Feed the CT cable into the hole. c.
  • Page 23 Current transformer clipping Polarity of current transformers Clipping the current transformers onto the service side cable: down towards load FROM SOLAR Match the labelled CTs with their corresponding labelled service SERVICE SIDE supply cable. S O L S H A R E 5 0 L2-1 L2 Confirm correct polarity of the CT by ensuring the arrow on the CT head matches the current flow direction on the service...
  • Page 24: Labelling

    ISOLATION OF THE INVERTER ISOLATE ALL SUPPLIES Please scan this QR WILL NOT DE-ENERGISE THE PV BEFORE WORKING ON ARRAY AND ARRAY CABLING REVENUE METER, SWITCHBOARD OR CIRCUIT code to access Allume’s _____________ detailed labelling guidance document. WARNING WARNING WARNING Warning...
  • Page 25: Iv/ Commissioning

    IV/ Commissioning A. Check phase wiring before power on Caution: Grid connections must be wired to the correct phase before applying voltage to SolShare. Failure to do so could result in a phase-to-phase condition which may damage SolShare. This will not be covered by SolShare warranty. Prior to turning on SolShare isolators: Ensure the output wiring is correct and the voltage phase is connected per the SLD and terminal labelling.
  • Page 26 Additional check items There is no phase-to-phase miswiring (all phase checks read 0V). SolShare has one input neutral and earth connection, from the inverter to SolShare. Only one output neutral and earth is wired out of SolShare to the main neutral bar and main earth bar located in the main switchboard, via the neutral bar and earth bar inside the Isolation Box.
  • Page 27: Preparing Solshare

    B. Preparing SolShare Close and secure the SolShare cover Pull down cover of SolShare into the Closed Position. Fasten the cover shut by replacing the four screws on the underside of SolShare that were removed in section III/A.1. Maximum torque for cover fasteners is 1.5Nm. Power on SolShare Turn on Inverter AC Isolator located next to inverter.
  • Page 28: Connecting Solshare To Wi-Fi

    D. Connecting SolShare to Wi-Fi Press the green button on the bottom of SolShare to put SolShare into Wi-Fi access point mode. The Wi-Fi LED on the front of SolShare will flash blue. Configure new Wi-Fi network settings (must be done within 5 mins of pressing button). Using your phone or laptop (device), look at the list of available Wi-Fi networks.
  • Page 29: Commissioning Solshare

    Your Training Certificate Number (generated and provided to you upon completion of SolShare Installation Training) is required to commission SolShare. Warranty will be void if installation is carried out without completing Allume training modules. Ensure you have an installer login for the SolShare Commissioning App, and your Training Certificate Number (both of these can be generated on successful completion of the online SolShare Installer Training).
  • Page 30: Solcentre Monitoring Portal

    Wi-Fi. SolCentre access for Asset Manager (whole site) You, the Allume accredited installer, can invite the designated asset manager(s) through the Commissioning App in one of two ways: a.
  • Page 31: Appendix A: Solshare Led States

    Ensure the router has an internet connection. SolShare does not have a strong internet connection, or Yellow cannot be communicate with Ensure all required ports are open (consult the Allume’s servers. Troubleshooting section of Allume’s How to set-up/ change Wi-Fi credentials document).
  • Page 32: Appendix B: Troubleshooting Solshare Wi-Fi Connection

    Appendix B: Troubleshooting SolShare Wi-Fi Connection 1. Authentication for network with SSID: “<SSID>” failed” If “Authentication for network with SSID: “<SSID>” failed” is displayed as shown, or you see a flashing blue Wi-Fi LED on the front of SolShare after following the process above, this means you have entered the incorrect Wi-Fi credentials (i.e.
  • Page 33 This manual is intended for installations in Australia and New Zealand. Specifications are subject to changes without advanced notification. For the most up to date documentation, visit www.allumeenergy.com Allume Energy www.allumeenergy.com info@allumeenergy.com AUS: +61 3 9427 0005...
