Sunset West Newport 4801-T90-120 Assembly Instructions

4801-T90-120 Newport Extension Dining Table Assembly Instructions
IMPORTANT: PLEASE READ COMPLETE INSTRUCTION SHEET PRIOR TO ASSEMBLY!
Identify all parts packed in carton against the parts list. Remove all protective materials, place
parts on a nonabrasive surface to avoid scratching. If any parts are missing or damaged, DO NOT
attempt to assemble.
Step 1 : Place table top upside down on a flat,soft surface. Attach legs with supplied bolts and lock
washers and metal washers. Turn the table in the upright position.
Step 2 : Press the lock to open the extension table.
Step 3 : Open the left table top and right table top.
Step 4 : Open the middle table top and put each table top together.
Step 5 : Press the lock to fix the extension table. Your table is now ready for use.
PARTS LIST
TABLE TOP
A
TABLE LEG
B
BOLT(M8*35)
C
D LOCK WASHER(M8)
E METAL WASHER(M8)
PLASTIC BOLT CAP
F
HEX WRENCH
G
1
4
8
8
8
8
1
