Para systems Minuteman MMS-STP8U3 Manual

8-outlet surge protector and usb charger
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Available languages

Available languages

Table of Contents

8-outlet Surge Protector and USB Charger
Model Number: MMS-STP8U3
minutemanups.com | 800.238.7272
Introduction
Thank you for purchasing a MINUTEMAN power protection product. It has
been designed and manufactured to provide many years of trouble-free service.
This document contains instructions and important information about the
operation of the Minuteman Surge Protector and USB Charger. Please read it
carefully using and keep it handy for future reference.
Features
7
6
2
1 -
Sleek, slimline plastic case allows the device to be placed in
most any location.
2 -
Molded inserts on back side of the device allow it to be wall mounted
3 -
(8) AC outlets with 2,160 Joules of surge protection
(3) of the outlets are spaced for transformers
4* - (2) Type A USB chargers: (Single Charger Use: 5V/3A, 9V/3A, 12V/2.5A) (Dual Charger Use: 5V/3A, 18W
Maximum)
5* – (1) Type C USB charger:
(5V/3A, 9V/3A, 12V/2.5A, 15V/2A, up to 30W Maximum) (5V/3A when used with Type A
charger)
6 –
On/Off rocker switch with "Protected" LED
7 –
6-ft. molded power cord with right-angle NEMA 5-15P plug (*Maximum 30-Watt draw for combined
USB charger configuration)
minutemanups.com | 800.238.7272
4
1
3
3
5
Doc No.: 34000567

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Minuteman MMS-STP8U3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Para systems Minuteman MMS-STP8U3

  • Page 1 Introduction 8-outlet Surge Protector and USB Charger Thank you for purchasing a MINUTEMAN power protection product. It has Model Number: MMS-STP8U3 been designed and manufactured to provide many years of trouble-free service. This document contains instructions and important information about the operation of the Minuteman Surge Protector and USB Charger.

  • Page 2: Specifications

    Specifications Capacity 1800 Watts Max Current 15 Amps Outlets (8) NEMA 5-15R USB Charging Ports (2) Type A / (1) Type C Max Charging Capacity 30 Watts Maximum (Combined) Surge Protection 2,160 Joules Input 6-ft. cord with right-angle plug Operating Temperature 32°...
  • Page 3 VA capacity. be purchased for in the United States; or Para Systems, Inc. does not cover or undertake any liability in any event for any of the following: The Aggregate Limit for all Connected Equipment of $25,000, minus: Loss of or damage to data, records, or software, the restoration of data or records, or the The amount(s) of all payment you have or are entitled to receive from insurance, other reinstallation of software.

  • Page 4: Limited Lifetime Warranty

    Para Systems, Inc. will repair or replace the unit Connect the equipment into an outlet on a circuit different from that to which the receiver is and return it to you at Para Systems, Inc.'s expense, or, if Para Systems, Inc. is unable to or decides connected.
  • Page 5 Présentation Parasurtenseur à 8 prises et chargeur USB Merci d'avoir acheté un produit de protection électrique MINUTEMAN. Il a été conçu et Numéro de modèle : MMS-STP8U3 fabriqué pour offrir de nombreuses années de service sans problème. Ce document contient des instructions et des renseignements importants sur le fonctionnement du parasurtenseur et du chargeur USB Minuteman.

  • Page 6: Caractéristiques

    Caractéristiques Capacité 1 800 watts Courant max. 15 ampères (8) NEMA 5-15R Points de vente (2) Type A / (1) Type C Ports de chargement USB 30 watts maximum (combiné) Capacité de charge maximale 2 160 joules Protection contre les surtensions Saisir 6 pi cordon avec fiche coudée 32°...
  • Page 7 Para Systems, Inc. et le recours exclusif du client initial sont : la réparation (ou le paiement du coût 2. A branché le parasurtenseur directement sur la source d'alimentation et ne doit pas avoir « branché en de la réparation) ou le remplacement de l'équipement connecté...

  • Page 8: Garantie À Vie Limitée

    Branchez l’équipement sur une prise d’un circuit différent de celui auquel le récepteur est connecté. le renverra aux frais de Para Systems, Inc. ou, si Para Systems, Inc. n'est pas en mesure ou décide de ne pas réparer ou remplacer le parasurtenseur (s'il est défectueux) dans un délai raisonnable, Para Systems, Inc. vous remboursera le prix d'achat total que vous avez payé...
