Installation Instructions
►
To prevent damaging the door or door gasket, make sure the door is open at least 90-degrees
when pulling shelves out of the rail compartment.
►
The door opens to a maximum of 115 degrees with a door stop on the bottom hinge preventing the
door from opening further.
Removing the Wooden Roll-Out Shelves
1. Open the door completely.
2. Remove all of the contents loaded on the roll-out shelf, if applicable.
3. Line up the roll-out shelf notches with the rail posts as shown below. During this process, it is
recommended to hold onto both rails as you move the roll-out shelf to line up the rail posts with
the notches on both ends.
4. Evenly lift the shelf up and then pull the roll-out shelf out.
16
Rail Posts
Notch
Rail
PRPB24C01CG Use, Care, and Installation Guide
P R E S R V ™
B E V E R A G E
C O O L E R
S I N G L E ZO N E
Rail
