Softel GT1800 Series User Manual

GT1800 SERIES
Optical power meter &VFL
USER MANUAL
www.softel-optic.com
Optical Power Meter&VFL manual
GT1800A&GT1800C is optical power meter and VFL integrated in one set. it has two ports, one
is OPM, another is VFL(650nm). OPM port can be connected by FC,ST,SC, also can be LC(must
be reserved when user place order). Frequency Modulate recognize(opt),WEB testing(opt).
Special functions as bellow:
 GT1800 series use STN LCD, it has a wide viewing angle, you can see informations clearly in
any angle. and this LCD is bigger than others in market .
 It use a long-life 650nm red light source, and its transmitting power is full 10mW.
 it can recognize modulated frequency of the optical,270Hz,330Hz.1KHz,2KHz (paid option)
 it can test network cable use a testing module via RJ45 interface (paid option)
SPECIFICATIONS
ITEMS
Wavelength 850,980,1270,1300,1310,1490,1550,1577,1625nm
Detector InGas
Measurement Range -70~+6dBm(GT1800A)
Accuracy
±0.22dB
Resolution 0.01dBm
VFL(650nm) output power 10mW
Working Temperature -10~+65℃
Storage Temperature -25~+65℃
Auto off Time 5 minutes no operating
Working Time (VFL no output) 190 hours
Working Time (VFL output) 70 hours
Battery Type AA 3PCS
Weight 350g(include batteries)
Dimension 185X80X48mm
Accessories AA alkaline batteries ,manual 1 PC, cotton swabs
Option connector ST,SC,LC, network cable tester
Option function Network cable test, Recognize modulate frequency
Warranty 12 months
1/3 page
the best selection
SPECIFICATION
-50~+26dBm(GT1800)
