LSP inc. SLP30-DC65/2S Installation Manual

DC Surge Protector Wiring Diagram & Installation
Type 2 48V DC Surge Protector SLP30-DC65/2S
1 DC SPD Wiring Diagram & Installation
48V DC Surge Protector
SLP30-DC65/2S
Rated Operational DC Voltage U /
Maximum Continuous Operating DC Voltage
U
(DC+) - PE, (DC-) - PE
Nominal Discharge Current (8/20 µs) I
n
I
Maximum Discharge Current (8/20 µs)
max
Voltage Protection Level
U
(DC+) - PE, (DC-) - PE
U
48 Vdc
o n
65 Vdc
c
15 kA
30 kA
0 .3 kV
p
