- Page 1 5 BURNERS BUILT-IN GAS COOKTOP 4 GAS BURNERS + 1 CERAMIC GLASS ELK131GH5 USER MANUAL Please read this manual carefully and retain for future references.
-
Page 2: Technical Specifications
Pay particular attention to ventilation provisions and guidelines. For gas type conversions, please consult the nearest KB ELEMENTS point of sales for appropriate replacements. 2. Power and Gas Supply Shutdown: Before installing, ensure both the power and gas supplies are switched off. - Page 3 BUILT-IN STRUCTURE DESIGN FEATURE: IMPORTANT: Ensure the chosen location has easy access to electricity and gas for ope ration. Operation Instructions Gas Burner: Gas Adjustment: To adjust the gas intensity, use the switch (see picture 2). Press the switch fully and rotate it counterclockwise to the desired position.
- Page 4 Ignition Procedure: Follow these steps for ignition: 1. Switch Activation: Gently press the switch (refer to picture 3) and rotate it counterclockwise until it reaches the position for the largest flame. Once in position, press the switch to initiate ignition. 2.
- Page 5 Cleaning Instructions Suggestions: 1. Timing: Clean the built-in gas after it cools off, Always pay particular attention to porcelain enameled parts. 2. Avoidance: Refrain from leaving alkaline or chlorine-based substances on it. 3. Safety Measure: Always unplug the electric cord from the outlet before initiating the cleaning process.
- Page 6 Range Hood To ensure optimal flame conditions, it is essential to select an appropriate location for your built-in gas cooktop. Follow these guidelines for selecting the proper location: 1. Air Circulation: Ensure there is sufficient air circulation in the room. Pay attention to ventilation by incorporating more than one wind-in opening, with each opening having a square area of not less than 100 square centimeters.
- Page 7 Installation Guidelines: Remarks: Before proceeding with the installation of the built-in gas hob, please follow these steps: 1. Place the template on the cooktop. 2. Install the hob accordingly. REMEMBER: When installing your built-in gas hob, keep the following considerations in mind: 1.
- Page 8 Detailed Installation Instructions: To ensure optimal safety and performance, follow these detailed installation instructions: 1. Electrical Outlet Compatibility: Verify that the electrical outlet provides the correct voltage and possesses the appropriate ampere rating to accommodate the machine's electrical requirements. 2. Secure Grounding: Ensure it is securely grounded according to the provided instructions.
- Page 9 www.kbelements.de...
