Summary of Contents for Toku MI-3800PLR
- Page 1 MI-3800PLR Manual www.rami-yokota.com...
-
Page 4: Before Taking Into Use
Recommended Technical specifications Brand Toku Square Drive 1" Version Bolt capacity (mm) Impact mechanism Gesloten Hamer 4500 Torque (Nm) 2000 Force adjustment R/L 4 Standen Airconsumption (l/s) Weight (kg) Airconnection PT 1/2" Airpress max. (MPa) 0,63 mm B Hosediameter (mm) - Page 5 The quality of the compressed air must be good, which means clean, dry and this is best assured by means of an air filter. We advise the use of a complete FRL (filter, regulator, lubricator) unit. The oiler has to be adjusted to approx. 3 to 6 droplets per minute.
-
Page 6: Using The Tool
In case that during the use of this tool dust is generated by either the process or the exhaust air blowing on dust in the environment, a risk assessment has to made. Operator must use appropriate protection to prevent inhalation or skin contact. -
Page 7: Maintenance
Warranty The warranty period from the date of purchase is as follows: • 12 months on Yokota , Toku and Red Rooster tools; • 3 months on spare parts of tools, which are repaired by us. Warranty covers material or construction mistakes of the manufacturer, which are clearly definable. Replacement of parts or repair by an official Yokota/Red Rooster service workshop is free of charge, when the tool is covered by warranty. -
Page 8: Declaration Of Conformity
Brand: Toku Product: Impact Wrenches Type: MI-3800PLR Capacity: 2000 WE, RAMI YOKOTA B.V., hereby declare that this product is conform the European Directive 2006/42/EG and, the standard EN ISO 11148-6 Technical file available from Rami Yokota BV: RAMI YOKOTA BV... - Page 9 www.rami-yokota.com...
