Before servicing this chassis, it is important that the " " service technician read the Important Safety Note in this Service Manual. SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT COLOUR TELEVISION OCT 2003 Digital Media System Group, Hitachi Asia Ltd. tammutech@yahoo.com...
PURITY AND CONVERGENCE ADJUSTMENT COLOUR PURITY ADJUSTMENT (1) Before colour purity adjustment,warm up the TV set over 15 minutes and fully degauss. (2) Receive pure white signal in AV status and press PIC.MODE key to set picture in DYNAMIC mode. (3) Loosen the clamp screw of the deflection yoke and pull the deflection yoke towards the purity magnet.
Page 8
OPERATION INSTRUCTIONS SETUP Insert The Batteries Remove the battery cover by pressing it and sliding it down. Insert the two 1.5V (AAA size) batteries making sure the polarity (+ or -) of the batteries matches the polarity marks inside the unit. Replace the battery cover by sliding it in until you hear a click sound.
CONTROL LOCATION FUNCTIONAL PARTS Front View of TV Set 1. Power Switch 2. Power Indicator 3. Remote Sensor 4. Side Panel 5. Speakers 6. Program Down / Up Button 7. Volume Down / Up Button Menu Button 9. TV/AV Button PROG.
INPUT AND OUTPUT TERMINALS Rear View of TV Set 1. AV OUT Terminals 2. AV IN 1 Terminals 3. YCbCr IN Terminals(YUV) 4. S-Video In Terminal 5. Antenna Input Socket (75 Ohm) 6. AC Power Cord YCbCr IN AV OUT AV IN 1 VIDEO VIDEO...
Page 11
REMOTE CONTROLLER FUNCTIONS Remote Control Unit POWER ON / STANDBY button Press this button to switch on the TV when at standby mode or vice versa. Press any number 0-9, buttons will also switch on the TV from standby mode. SLEEP button SOUND SLEEP...
REMOTE CONTROLLER FUNCTIONS Remote Control Unit MUTE button Press once to mute the sound. Press again to restore the sound volume. RECALL button Press this button to display the settings on the screen. (e.g. Channel number, system) SOUND SOUND MODE button SLEEP SYS.
Page 13
REMOTE CONTROLLER FUNCTIONS Remote Control Unit MENU button Press this button to enter the menu screens for various optional adjustable settings. TV/AV button Press this button to switch between TV broadcasts and AV input programs. YCbCr S-VIDEO SOUND SLEEP SYS. CH I/II SOUND MENU button Press this button to enter into the [SOUND]...
REMOTE CONTROLLER FUNCTIONS TELETEXT OPERATIONS For models with Teletext function only. This page shows the function of the buttons on the remote control unit when in Teletext mode. TV/TEXT button Press this button to enter Teletext mode. Press this button the second time to superimpose the teletext page over the TV SOUND programme.
Page 15
REMOTE CONTROLLER FUNCTIONS HOLD button Press this button to hold the Teletext page on display to prevent the page from changing. Press again to release the hold state. SOUND SLEEP SYS. CH I/II SUB PAGE button Some Teletext pages may contain several sub-pages which are automatically paged RECALL in a certain cycle by the TV station.
ON SCREEN DISPLAYS SOUND SLEEP SYS. CH I/II RECALL MENU SCREENS SOUND MODE PIC. AV/TV MODE This TV set allows you to adjust any settings by selecting from the menu screens. --/--- --/--- LANG. SOUND PIC. SETUP TUNE U.N.L REVEAL HOLD SUBPAGE Press the...
Page 17
ON SCREEN DISPLAYS This menu allows you to adjust the sound settings according to your [SOUND] menu preference. Press the MENU button 2 times or press SOUND button directly. SOUND VOLUME BASS TREBLE BALANCE Select the desired item using the buttons.
Page 18
ON SCREEN DISPLAYS This menu allows you to adjust the various setup functions. [SETUP] menu MENU Press the button 4 times or press SETUP button SETUP directly. LANGUAGE ENGLISH BACKGROUND CHILD LOCK Select the desired item using the buttons. Use the buttons to adjust the settings.
Page 19
ON SCREEN DISPLAYS This menu allows you to arrange channel numbers by [EXCHANGE] exchanging between 2 preset channel numbers. menu Press the MENU button 6 times. EXCHANGE PROGRAM Select the first PROGRAM item using the buttons. PROGRAM EXCHANGE Use the buttons to select the channel number you want to exchange from.
MECHANICAL ASSEMBLY REAR COVER REMOVAL 1.Remove screws from the rear cover as shown in Figure 1. 2.Remove the rear cover. CHASSIS REMOVAL 1.Remove the rear cover (refer to REAR COVER REMOVAL instructions ). 2.Discharge the picture tube anode (2nd anode lead )to the dag coating (picture tube grounding lead). 3.Disconnect the degaussing coil (KE),picture tube socket, deflection yoke connector (KDY),speaker connectors (KL and KR)and 2nd anode lead .
ELECTRICAL PARTS LIST FOR REFERENCE ONLY The components shown in page 38-53 serve as a reference. It is not meant for ordering of components for servicing purposes. Do not quote any components from these lists. Circuit N o Part No Description 013PAST001A0M MAIN ASSEMBLY (AUTO INSERT)
Page 23
ELECTRICAL PARTS LIST FOR REFERENCE ONLY Circuit No Part No Description R380 YZ4100AB1030T0 CARBON FILM RESISTOR 10K OHM 1/16-1/6W +/-5% (TAPE TYPE) R645 YZ4100AB1030T0 CARBON FILM RESISTOR 10K OHM 1/16-1/6W +/-5% (TAPE TYPE) R646 YZ4100AB1030T0 CARBON FILM RESISTOR 10K OHM 1/16-1/6W +/-5% (TAPE TYPE) R648 YZ4100AB1030T0 CARBON FILM RESISTOR 10K OHM 1/16-1/6W +/-5% (TAPE TYPE)
Page 24
ELECTRICAL PARTS LIST FOR REFERENCE ONLY Circuit No Part No Description R735 YZ4100AB3320T0 CARBON FILM RESISTOR 3.3K OHM 1/16-1/6W+/-5% (TAPE TYPE) R737 YZ4100AB3320T0 CARBON FILM RESISTOR 3.3K OHM 1/16-1/6W+/-5% (TAPE TYPE) R741 YZ4100AB3320T0 CARBON FILM RESISTOR 3.3K OHM 1/16-1/6W+/-5% (TAPE TYPE) R742 YZ4100AB3320T0 CARBON FILM RESISTOR 3.3K OHM 1/16-1/6W+/-5% (TAPE TYPE)
Page 25
ELECTRICAL PARTS LIST FOR REFERENCE ONLY Circuit No Part No Description C880 YZ4300AF101CT0 CERAMIC CAPACITOR 100PF 50V +/-5% (TAPETYPE) C308 YZ4300AF102CT0 CERAMIC CAPACITOR 0.001uF 50V +/-5% (TAPE TYPE) C309 YZ4300AF102CT0 CERAMIC CAPACITOR 0.001uF 50V +/-5% (TAPE TYPE) C310 YZ4300AF102CT0 CERAMIC CAPACITOR 0.001uF 50V +/-5% (TAPE TYPE) C311 YZ4300AF102CT0 CERAMIC CAPACITOR 0.001uF 50V +/-5% (TAPE TYPE)
Page 26
ELECTRICAL PARTS LIST FOR REFERENCE ONLY Circuit No Part No Description C604 YZ4300AR102ET0 CERAMIC CAPACITOR 0.001uF 1KV +/-20%(TAPE TYPE ) C605 YZ4300AR102ET0 CERAMIC CAPACITOR 0.001uF 1KV +/-20%(TAPE TYPE ) C606 YZ4300AR102ET0 CERAMIC CAPACITOR 0.001uF 1KV +/-20%(TAPE TYPE ) C643 YZ4300AR471DT0 CERAMIC CAPACITOR 470PF 1KV +/-10% (TAPETYPE) C644 YZ4300AR471DT0...
Page 27
ELECTRICAL PARTS LIST FOR REFERENCE ONLY Circuit No Part No Description C863 YZ4300BF105ET0 ELECTROLYTIC CAPACITOR 1uF 50V +/-20% (TAPE TYPE) C324 YZ4300BF225ET0 ELECTROLYTIC CAPACITOR 2.2uF 50V +/-20%(TAPE TYPE) C328 YZ4300BF225ET0 ELECTROLYTIC CAPACITOR 2.2uF 50V +/-20%(TAPE TYPE) C339 YZ4300BF225ET0 ELECTROLYTIC CAPACITOR 2.2uF 50V +/-20%(TAPE TYPE) C755 YZ4300BF225ET0 ELECTROLYTIC CAPACITOR 2.2uF 50V +/-20%(TAPE TYPE)
Page 28
ELECTRICAL PARTS LIST FOR REFERENCE ONLY Circuit No Part No Description C130 YZ4300MG682DT0 MYLAR CAPACITOR 0.0068uF 100V +/-10% (TAPE TYPE) C131 YZ4300MG682DT0 MYLAR CAPACITOR 0.0068uF 100V +/-10% (TAPE TYPE) C127 YZ4300MG683DT0 MYLAR CAPACITOR 0.068UF 100V +/-10% (TAPE TYPE) C134 YZ4300MG683DT0 MYLAR CAPACITOR 0.068UF 100V +/-10% (TAPE TYPE) D172 YZ4500141481T0...
Page 29
ELECTRICAL PARTS LIST FOR REFERENCE ONLY Circuit No Part No Description Q812 YZ4600C18150T0 TRANSISTOR 2SC1815Y/2PC1815 (TAPE TYPE) Q813 YZ4600C18150T0 TRANSISTOR 2SC1815Y/2PC1815 (TAPE TYPE) Q841 YZ4600C18150T0 TRANSISTOR 2SC1815Y/2PC1815 (TAPE TYPE) Q450 YZ4600C24822T0 TRANSISTOR 2SC2482/3DG2482Y (TAPE TYPE) L302 YZ4800010100T0 PEAKING COIL 1uH +/-10% (TAPE TYPE) L351 YZ4800010680T0 PEAKING COIL 6.8uH (TAPE TYPE)
Page 30
ELECTRICAL PARTS LIST FOR REFERENCE ONLY Circuit No Part No Description W415 YZ5900G4010600 COPPER JUMPER 0.6MM DIA. L=40mm W416 YZ5900G4010600 COPPER JUMPER 0.6MM DIA. L=40mm W417 YZ5900G4010600 COPPER JUMPER 0.6MM DIA. L=40mm W421 YZ5900G4010600 COPPER JUMPER 0.6MM DIA. L=40mm W422 YZ5900G4010600 COPPER JUMPER 0.6MM DIA.
Page 31
ELECTRICAL PARTS LIST FOR REFERENCE ONLY Circuit No Part No Description W613 YZ5900G4010600 COPPER JUMPER 0.6MM DIA. L=40mm W616 YZ5900G4010600 COPPER JUMPER 0.6MM DIA. L=40mm W621 YZ5900G4010600 COPPER JUMPER 0.6MM DIA. L=40mm W622 YZ5900G4010600 COPPER JUMPER 0.6MM DIA. L=40mm W624 YZ5900G4010600 COPPER JUMPER 0.6MM DIA.
Page 32
ELECTRICAL PARTS LIST FOR REFERENCE ONLY Circuit No Part No Description VR641 YZ420021030000 SEMI-FIXED RESISTOR 10KB (H) KVSF637ASB KOAOHM C643 YZ4300AR471DT0 CERAMIC CAPACITOR 470PF 1KV +/-10% (TAPETYPE) C644 YZ4300AR471DT0 CERAMIC CAPACITOR 470PF 1KV +/-10% (TAPETYPE) C645 YZ4300AR471DT0 CERAMIC CAPACITOR 470PF 1KV +/-10% (TAPETYPE) C603 YZ4300AT102D00H CERAMIC CAPACITOR 0.001uF 2KV +/-10%...
Page 33
ELECTRICAL PARTS LIST FOR REFERENCE ONLY Circuit No Part No Description T450 YZ510604100000 HORIZONTAL DRIVE TRANSFORMER FOR LOW VOLT AGE A301 YZ5221389W1400 B/G WORLD STANDARD VS TUNER 5V 38.9MHz W/O AGC 4V FOR 5P60 CN601 YZ540091000002 WAFER 10mm 2.35mm TJC1-2A 2 PIN CN602 YZ540091000002 WAFER 10mm 2.35mm TJC1-2A 2 PIN...
Page 34
ELECTRICAL PARTS LIST FOR REFERENCE ONLY Circuit No Part No Description SW004 YZ550011012000 TACT SWITCH VERTICAL TYPE KNOB 6mm H=12mm SW005 YZ550011012000 TACT SWITCH VERTICAL TYPE KNOB 6mm H=12mm SW006 YZ550011012000 TACT SWITCH VERTICAL TYPE KNOB 6mm H=12mm LED001 YZ570015012000 LED LIGHT EMISSION 3.1mm RED LONG LEAD YZ5800D1T0BP31 CONTROL P.C.BOARD 160 X 40 X 1.6mm FO R 3P31 CHASSIS...
Page 35
ELECTRICAL PARTS LIST FOR REFERENCE ONLY Circuit No Part No Description H502 YZ540102040205 PIN 05 + HOUSING 05 (TJC3) + 400mm FLATCABLE UL2468 AWG24 H501 YZ540102042204 PIN 04 + HOUSING 04 (TJC3) + 420mm FLATCABLE UL2468 AWG24 W/UL TUBE SW601A YZ550002021100 MAIN POWER SWITCH KDC-A11 W/SCREW HOLE YZ560010808401...
MECHANICAL PARTS LIST FOR REFERENCE ONLY Part No Description AP0021T0B000 ALL MECHANICAL PARTS YZ030121T0B001 POLYFOAM END CAP. R & L (TOP & BOTTOM) YZ40400005400 POLYBAG (PEARL SPONGE) (PO) W/PE W100 XH95cm YZ40409014003 POLYBAG 9" X 14" X 0.04 MM (PO) W/PE YZ100521990001 JACK PLATE BRACKET - BLACK (HIPS) YZ100729T0B001...
Page 37
BA 3 X 8 YZ26KA026080B0 KA 2.6 X 8 (BLACK) PP0021T0B000 PRINTING PARTS YZ010021T0B002 CARTON BOX 695 X 570 X 570 "HITACHI" ENG YZ060121T0B00C BACK LABEL 119.5 X 59.5 (-0.5, +0) "HITACHI" ENG YZ60220021800 QC PASSED LABEL (WHITE) YZ60220121800 QC PASSED LABEL (GOLD) YZ60402021900 SERIAL NO.LABEL...
Page 40
Before servicing this chassis, it is important that the " " service technician read the Important Safety Note in this Service Manual. SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT COLOUR TELEVISION OCT 2003 Digital Media System Group, Hitachi Asia Ltd. tammutech@yahoo.com...
Page 45
IC BLOCK DIAGRAM IC 121 (Universal HI-FI Audio Processor) TDA9859 IC 161 (BTL Audio Amplifier) TDA8944J tammutech@yahoo.com...
Page 46
IC BLOCK DIAGRAM IC 401 (Vertical Deflection Booster) STV9302A...
Page 47
IC BLOCK DIAGRAM IC 501(Video Output Amplifier) TDA6107Q IC 601 (Power Switch) KA5Q0765RTH...
Page 48
IC BLOCK DIAGRAM IC 602 (Photo Transistor ) TLP621 TLP621 1:ANODE 2:CATHODE 3:EMITTER 4:COLLECTOR IC 653 & IC 181& IC 652 (Regulators) L7800 Series REFERENCE VOLTAGE INPUT SERIES OUTPUT PASS ELEMENT CURRENT GENERATOR PROTECTION ERROR REFERENCE STARTING AMPLIFIER VOLTAGE CIRCUIT THERRMAL PROTECTION...
Page 49
IC BLOCK DIAGRAM IC 701 ( TV Signal Processor-Teletext ) TDA93XXPS/N2/5I -10-...
Page 50
IC BLOCK DIAGRAM IC 861 ( Digital TV Sound Demodulator/Decoder) TDA9874AH -11-...
SERVICE ADJUSTMENTS ALIGNMENT INSTRUCTION (3P31) Before Servicing The TV Set The main power is 100~240V 50/60HZ . Please be careful when you are servicing. Don t short any two soldering points, which should not be shorted and don t touch any components, which should not be touched.
Page 56
SERVICE ADJUSTMENTS General Adjustment Enter factory mode CH I/II SOUND MODE RECALL Press keys on remote control unit to enter factory mode. Press 0-9 numeric keys to enter factory menu. Select the item using the keys and adjust using the keys.
Page 57
SERVICE ADJUSTMENTS Receive 60HZ cross hatch pattern. Press PIC. MODE key to set picture in STANDARD mode. Adjust VSLOPE to obtain half of the crosshatch. Adjust VSCOR to obtain picture s best vertical pin cushion. Adjust VSHIFT to obtain picture s vertical center at the center of CRT screen in factory mode.
Page 58
SERVICE ADJUSTMENTS Service items This appendix shows information about service items that are available. The table lists all possible available service items. CH I/II 1.Press SOUND MODE RECALL keys on remote control unit to enter factory mode. 2.Press the Direct key buttons on the remote control unit specified in the table to access directly into the respective items when in factory mode.
