Cool Collection Nubes AP844060 User Manual

AP844060 Nubes Humididfier
Ensure to use the product comfortable and safety. Please read the instructions carefully so
that you can use them correctly.
HOW TO USE
1. Open the upper cover: lift up the upper cover,please add tap water and do not tilt the machine.
2. Add water: Please do not over the Max line when you add the water to the tank.
3. Add essential oil: Drop essential oil in the water tank, 2-3 drops at most (about 0.1
4. Connect USB line: Please insert the usb plug into product's DC hole, then flat the machine.
5. Connect the power supply: plug the USB cable into the power adapter.or connect to computer as well as changing
treasure can be used,but every power must be 5V
6. Press the left switch first time.the warm light turn on, second press turn off the light.
7. Press the right switch first time, spraying the mist all the time. Auto turn off when the water running out or less
a. Right switch: color light (light} left switch: mist (mist)
b. The mist volume depend on indoor environment and the water volume in the tank.
c. D ue to the w ater temperature and quality e x ternal factor , m i st volume w ill be less w hen you just turn on the
machine,and it will be steady after few minutes.
d. Due to air temperature, humidity, airflow and so on, if there seems no mist, It's normal phenomenon.
e. This machine has auto off function. It will be auto off when water run out of or the water line is too low.
Meanwhile power will be auto cut off.
ANNOUNCEMENTS
Please pay special attention for failure to comply with the following precautions or other damages.
•Do not disassemble the machine in operation of the machine, or the water will spout.
•It is recommended to use the normal temperature water, or use pure water, mineral water, purified water, etc, do not
use unknow liquid or high concentration liquid. In order to avoid failure.
•The water volume must not exceed the max line of the water tank, otherwise the spray is not nomal or no mist.
•Please make sure the machine is not tiptilted when you are adding the water. In order to avoid water leaking
and water flow into the machine by air outlet cause mechanical failure.
•Do not touch the atomizer in the tank by hand directly.
•Please keep the air outlet upwards when draining the water, in order to avoid the water infitrate the air outlet to
cause malfunction.
•When the indoor temperature is too high, the mist will change into water droplets in front of
happens, Please place the towel in front of the nozzle.
•When the machine used in low temperature or high humidity status,it will cause fogging appeareal on the mist
spary mouth. It's the normal appearance that the upper cover has water drops around.please use towel to clean it.
•Use soft cloth to clean internal of water tank, the dirty on atomization piece, in order to avoid
failure,please clean the machine every 5-6 times using.
•When the machine maintenance, make sure to pull off the power adapter from the socket and the power supply is
cut off.
•If you do not use the machine for a long time, please drain away water from the water tank and clean it, then keep it
safe after it is dry.
User manual
0.2ml).
800.
the nozzle, When it
SIMPLE TROUBLESHOOTING
When the machine fault,please make sure the following matters before repairing.
1. The power cant live: Make sure if the power connection status is right.also make sure the connetion between
power and machine as well as the socket. But just in case,pull out of the DC plug from machine then insert back
again,after that make sure the connection status.
2. Power off when power electricity: The machine will automatic turn off after you push mist switch, if there is no
water in machine, please make sure if there have water in tank or water is not enough, please add water.
3. No mist spray or mist spray state is not well: 1 . Check the atomization piece for dirt; 2. Make sure that water in
water tank is enough or over max water line,the machine cannot spray mist normally if water too much, you should
reduce or increase water in the tank until it spray mist normally. 3. Make sure the upper cover and inner are installed
correctly, then assemble the machine, upper cover and inner firmly, if they are not assembed correctly. The mist can
not rightly reach to the exit indeedly. 4 . Please make sure if there is dirty in the bottom air outlet. If there is dirty in the
bottom air outlet and so on, that will reduse the volume of air flow, then it casues the machine cant spary mist. 5.
Due to temperature, humidity and the environmental impact that lead you cannot see the mist, or cant see the
mist, but the machine spray normally and the supply air fan is working in order( you can hear motor running), it
means the machine is trouble-free. 6. Please, check if the power adapter matches.
4. Water leakge: 1. Make sure the upper cover is installed correctly, and the inner whether offset falls off, then
assemble the machine, upper cover and inner firmly. 2. When the upper cover and inner is offset, the mist cannot reach
the exit, and it cause the dew apprearance. 3. Make sure
temperatures.due to low temperatures or humidity, it cause the dewing.
CUSTOMER SERVICE
Please consult the product distributor when there is any doubt or any failure in use. As shown in comply with the
following content, anger does not provide free maintenance
1. Fall in the water or use in water and so on,those wrong and undeserved method of application cuase the
malfunction
2. The damage caused by the use and the appearance of dirty.
3. The failure caused by self-dismantling, reforming and improper repair methods
4. Consumption of LED lamps and other consumables and accessories.
5. It is used only for indoor domestic use, for other places or other USES such as outdoor.
This item is in conformity with the following standards:
SPECIFICATIONS
RoHS Directive 2011/65/EU and its subsequent amendments Directive
Voltage : DC 5V 800Ma
(EU) 2015/863
Electromagnetic Compatibility (EMC) - Directive 2014/30/EU
Power: Standard edition 4W
UK Electrical Equipment (Safety) Regulations (SI 2016/1101)
Tank volume: 120ml
UK Electromagnetic Compatibility Regulations (SI 2016/1091)
Electric wire: 1 m
Power adadpter: DC5V = 1A (alterable)
Application indoor area: about 10 13m2
the machine set in at low temperatures or high
This symbol both in the product and its user manual indicates that at the end of the
devices electrical life, it should be recycled separately from your household waste.
There are adequate means to dispose of this material - for proper recycling. For
more information, contact your local authorities.
Distributor: Cool Collection 1476 Budapest,POB:176., Hungary
Registration nr. 01-09-276783
Made in China
