DESIGNER 12 & DESIGNER 14 WET/DRY VACUUM
WARNING:
FAILURE TO OBSERVE RECOMMENDED M AINTENANCE OF CORO ANO PLU
PROPER GROUNDING, PROPER REPLACEMENT OF CORDS ANO PLUGS, USE OF
PROPER EXTENSION CORD AS INSTRUCTED, CAN RESULT IN SHOCK TO OPERATOR
AND POSSIBLE ELECTROCUTION.
IMPORTANT:
SEE ASSEMBLY, OPERATION. MAINTENANCE AND REPAIR INSTRUCTIONS
THE SAFETY PROCEDURES FOR GROUNDING. SERVICE. AND OPERATION MUST BE FOLLOWED TO PREVENT DAMAGE
TO MACHINE AND PROPERTY AND INJURY TO OPERATOR OR BYSTANDERS.
GROUNDING INSTRUCTIONS must be followed to avoid damage to machine and prevent injury to operator. Read instructions and
look at illustration carefully!
Check nameplate on machine to be sure voltage and cycle stated on nameplate is the same as voltage and cycle of electrical outlet.
DO NOT attempt to plug a 115 volt machine into a 230 volt outlet or a 230 volt machine into a 115 volt outlet.
The grounding blade on the plug must remain intact if the machine is to be properly grounded when plugged in and operated. An
ungrounded machine can cause shock to the operator. See Figure A.
If connecting to an outlet that accepts only two blades use an adapter as in Figure B. NEVER REMOVE THE GROUNDING BLADE.
JI it is necessary to use the adapter shown in Figure 8, the machine is only properly grounded if the adapter's green-colored clip is
tied under screw that holds electrical outlet cover to the wall.
Figure C. Machine used on 230 volt may or may not have the grounding (earthed) plug attached to the cord. For U.S.A. 230 volt 60 HZ,
the plug is already supplied with cord. For use outside the U.S.A., it may be up to the purchaser to have a proper grounding (earthed)
plug attached.
nsv,so HZ
FIGURE A
FIGURE A
SAFETY PROCEDURES: Failure To Observe Can Cause Injury To OPERATOR!
• NEVER attempt to service or perform maintenance functions while machine is plugged into electrical outlet.
• NEVER operate the machine with a broken ground blade on the plug. See Figures A & C above.
• NEVER operate machine with a cut or abraded cord. Always replace cord when cut or abraded. FAILURE TO DO SO MAY CAUSE
INJURY TO THE OPERATOR FROM ELECTRICAL SHOCK.
• When grounding blade on plug is broken, it is preferable to
use only U.L. listed/CSA approved plug with rating of 125V, 15 amps (for 230V. use a 3 wire plug with a rating consistent with
voltage and amps required.) Be sure that the green wire of the cord is connected to the green screw of the replacement 3-wire
plug, the white wire to the silver screw, and the black wire to the gold screw of the replacement plug.
FAILURE TO CORRECTLY ATTACH THE REPLACEMENT PLUG TO THE CORD CAN RESULT IN ELECTRICAL SHOCK OR
-
POSSIBLE ELECTROCUTION WHEN MACHINE IS TOUCHED.
ALWAYS reconnect green/yellow grounding wire of replacement cord to the terminal strip marked
=
grounding procedure, p � 2. At the same time, be sure green/yellow grounding wire from motor ls connected to the same
terminal strip marked
• NEVER disconnect plug by pulling on cord. To disconnect from outlet, grasp the plug not the cord.
• NEVER operate the Designer 12/14 with any air opening blocked. Keep openings free of dust, lint, hair, etc.
• NEVER drop or insert any object into any opening.
• To disconnect power source, turn switch to the off position, then remove plug from outlet.
• DO NOT operate machine with filter bag removed. Unplug cord from electrical outlet before removing filter.
• The Designer 12/14 should not be left unattended when plugged in. Unplug when not in use.
• Keep cord away from heated surfaces.
• NEVER operate machine if it is not working properly, it it has been dropped, damaged, exposed to weather or dropped into water.
Return the machine to a service center for examination and repair.
• NEVER handle plug, cord or vacuum cleaner with wet hands.
SAFETY PROCEDURES: Failure To Observe Can Cause Damage To MACHINE!
• ALWAYS store machine inside. Protect from rain or snow.
• NEVER spray top of machine with water or other liquids.
• ALWAYS remove hose and coupling from machine after each use or hose may become damaged.
• NEVER bounce machine down stair steps, or damage may result to base assembly.
• ALWAYS use a properly grounded 3-wire extension cord which has male and female plugs. Use only 16-3 ST or SO type
extension cords for total cord length up to 75'.
of
• Empty tank all recovered materials to prevent damage to container and lid assembly.
� v
THE NATIONAL SUPER SERVICE COMPANY
3115 FRENCHMEN$ ROAD, TOLEDO, OH/O43607-2958 ( 4 19) 531-2121
READ THOROUGHLY
ADAPTER
�
GAOUNOING
CLI�
NOTE:
Adapter NOT for use m Canada
replac·
REPLACING CORO
