Summary of Contents for NAVAC NSV1
- Page 1 NSV1 Smart Refrigerant Valve User Manual Failure to follow warnings could result in death or serious injury. SAVE THIS MANUAL FOR FUTURE REFERENCE...
- Page 2 I. Safety Information Please read this manual carefully before operating, overhauling, or maintaining the product in order to fully understand the safety issues and precautions I. Safety Instructions necessary for its proper use and operation to ensure long-term, stable II. Technical Parameters operation.
- Page 3 Warning II. Technical Specfication This equipment must be operated by qualified personnel who are familiar with air conditioning and refrigeration systems! Operating temperature: -10 ~ 50 °C / 14 ~122 °F All components (system, refrigerant meter valve group, refrigerant cylinder, Environmental Storage temperature: -10 ~ 50 °C / 14 ~122 °F Conditions...
- Page 4 4. Bluetooth indicator: Shows the Bluetooth status of the device. III. Product Overview • Flashing yellow: Bluetooth not connected (standby mode). • Flashing blue: Bluetooth connected. • Flashing red: Bluetooth module error. 5. Valve indicator: Indicates the device's valve status. •...
- Page 5 Spare Parts List IV. Structural Breakdown Diagram Item Cross Recessed Pan Head Tapping Screws Electromagnetic Cover Lithium Battery Pack Cross Recessed Countersunk Head Tapping Screws Hook Pressure Plate O-Ring Hook O-Ring Lower Housing Cross Recessed Pan Head Tapping Screws O-Ring Copper Cap Assembly Strainer Press Studs Strainer...
- Page 6 V. System Connection Diagram Solution 1 Solution 2...
