LUXO Valo User Manual

2-person canadian hemlock carbon fibre home sauna cabin

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

User Manual

Valo 2-Person Canadian Hemlock

Carbon Fibre Home Sauna Cabin

Table of Contents

Need help?

Do you have a question about the Valo and is the answer not in the manual?

Questions and answers

Summary of Contents for LUXO Valo

Page 1 User Manual Valo 2-Person Canadian Hemlock Carbon Fibre Home Sauna Cabin...
Page 2 Discover the unique features of the Valo sauna, including its numerous health advantages, superior quality, and our team’s committed approach to customer service and support.
Page 3: Table Of Contents
Table of Contents. Conditions of Use Packaging and Individual Panel Information Installation Information Assembly Instructions Digital Control Operating Instructions Digital Colour Therapy Operating Instructions Instructions for Use Tips for Use Safety Instruction Disclaimer...
Page 4: Conditions Of Use
Conditions of Use. 1. Temperature: +5°C ~ +40°C (+41°F ~ +104°F) 2. Relative humidity: ≤85% 3. Depression: 700~1060 hpa 4. Main supply: AC 220-240V 5. Frequency: 50Hz±1 6. For domestic use only General Technical Characteristics. 1. Functions processed by microprocessors 2.
Page 5 The receptacle provided by the manufacturer must be WARNING!!! installed by a quali昀椀ed electrician only. 1. Roof cover 11. Door handle 21. Sauna control panel 2. Sauna roof 12. Left sauna wall 22. Back wall carbon heater 3. Colour therapy 13.
Page 6: Installation Information
Installation Information. 1. Do not plug any other appliances into the outlet with your sauna. 2. The sauna should always be placed on a fairly level surface. 3. The sauna must be placed indoors and in a dry area. 4. Do not spray the exterior with water. If the 昀氀oor is consistently damp, you will also need room behind the sauna to allow access to install a 昀氀oor separator to keep the sauna high and dry.
Page 7 STEP 3. CONNECTING BACK PANEL TO BOTTOM PANEL WITH BUCKLES Connect the back panel to the bottom panel by lining up the back panel on the groove of the bottom panel. Align buckles on both panels and fasten them if applicable. Keep in mind that the back panel will not have enough support from the buckles alone until the side panels have been installed in place.
Page 8 STEP 5. INSTALLING FLOOR PANEL (4 pcs*40mm screws needed) STEP 6. INSTALLING BENCH HEATER PANEL Slide down the Bench Heater Panel by lining up its sides with the Vertical Guides on each Side Panel. 1. Bench Heater Panel must be positioned so that the “TOP” sticker is facing up and the heater facing outward.
Page 9 STEP 8. INSTALLING BENCH PANEL Install the bench panel by sliding it over the horizontal guides on each side panel. Be careful not to scratch the side panels when doing so. Make sure to position the bench so that the “BACK” sticker is facing back, the smooth and 昀椀nished sides of the bench are facing up and forward.
Page 10 STEP 10. PLACING TOP PANEL 1. Plug the heater wires through the holes around the top panel. 2. Gently place the top panel onto the rest of the assembled panels. When all four corners are in place, gently push down the top panel until it is snugly 昀椀t over the rest of the panels. 3.
Page 11 STEP 12. USE SCREWS TO FASTEN THE ROOF ONTO THE CABIN (4 pcs*30mm screws needed) STEP 13. PUT THE ROOF DUSK COVER AND SCREW IT ONTO THE ROOF(12 pcs*20mm screws needed)
Page 12 STEP 14. INSTALL THE DOOR HANDLE (2 pcs*50mm screws needed) STEP 15. ASSEMBLE THE COLOUR THERAPY CONTROL PANEL (2 pcs*40mm screws needed)
Page 13 STEP 16. ASSEMBLE THE OXYGEN 1. Plug the power. 2. Hang the ionizer on a screw hook at a designated location on the wall.(2 pcs*20mm screws)
Page 14: Digital Control Operating Instructions
Digital Control Operating Instructions. Button and Indicator Function Press to power up the control panel Press to adjust the temperature Press to exchange between Centigrade and Fahrenheit Press to adjust time Press to control outside light and inside light Press ‘MODE’, when the screen shows USB, insert the USB to listen to music. When the screen shows LINE, plug in aux.
Page 15 1. START-UP a). Plug the unit in a separate well-grounded three-hole outlet, “Power” indicator lights up. b). Press “Power” button to turn on the equipment, left window displays temperature, the right one displays time. c). Advice another person when using the sauna. Please power off the unit when leaving the sauna. 2.
Page 16: Digital Colour Therapy Operating Instructions
Digital Color Therapy Operating Instructions. 1. Press the “Power” button to power on the Digital Color Therapy system. 2. When light displays the color you need, press the “Select” button to choose. Press the button “Set”, and press the button “+”,”-” to adjust the time, press the button “Set” again, Countdown starts. 3.
Page 17: Instructions For Use
Instructions for Use. Review all health and safety instructions. Please consult with your physician, prior to using the sauna for any health concerns. If you feel light-headed or heat-exhausted during a session, exit the sauna immediately. 1. Set the temperature to a comfortable level, normally, 40-50°C. 2.
Page 18: Tips For Use
Tips for use. 1. To regulate the temperature inside the sauna during your session, use the roof vent or the door window (by setting it at an angle). 2. If you feel the need for more cooling, simply leave the door open until the air around you feels comfortable enough.
Page 19: Safety Instruction
Safety Instruction. 1. Read and follow all instructions carefully. 2. When installing and using this electrical equipment, you should always follow basic safety precautions. 3. Do not use the sauna immediately following strenuous exercise. Wait at least 30 minutes to allow the body to cool down completely.
Page 20: Disclaimer
Disclaimer. Please read the following disclaimer carefully before purchasing or using our sauna product. By proceeding with the purchase or use of our sauna, you acknowledge that you have read, understood, and agreed to the terms and conditions outlined below: Health Considerations Our sauna is designed to provide relaxation and promote overall wellbeing.
Page 21 Again, we thank you for your purchase. You’ve made our day, and we hope you have a great one too! Enjoy your sauna! For any questions, please call us at 02 8999 1114 or contact our online customer service team through our website.
