TEHILA 7722 Series Installation Instructions

VANITY WITH COIL PULL-DOWN FAUCET INSTALLATION INSTRUCTIONS
(7722 Series)
ATTENTION
1. PRIOR TO INSTALLATION: Check all parts carefully to ensure no damage occurred in transit and
no pieces are missing. DO NOT dispose of any packaging until you are satisfied with this product.
2. SAFETY PRECAUTIONS: Your installation must comply with all local plumbing codes. Have a
qualified tradesman install or approve your plumbing installation. Always wear safety goggles and
gloves during installation to avoid personal injury.
3. NEED HELP? Please contact us at (773) 265-2371 or via email at support@tehilalaundry.com with
any questions. Our normal business hours are Monday to Friday from 8 a.m. to 5 p.m. CST.
DO NOT RETURN THE UNIT TO THE PLACE OF PURCHASE BEFORE CONTACTING US AT
1 (773) 265-2371 OR VIA EMAIL AT SUPPORT@TEHILALAUNDRY.COM.
CARE & MAINTENANCE
FOR LAUNDRY TUB:
1. Only soap and water should be used for cleaning the ABS plastic sink. Using other chemicals such
as chlorides, acetone (nail polish remover), nail polish, lacquer thinners, dry cleaning solution,
gasoline, pine oil, ketones and degreasers will cause the sink to discolor. Rinse well and dry with
soft cloth to prevent scratches.
2. Clean grease, oil, paint and ink stains with isopropyl (rubbing alcohol), immediately rinse with
water after stain removal.
3. Avoid using razor blades or other sharp instruments that may fall and scratch the surface.
FOR FAUCET:
1. Clean the area of the mounting holes before installing the faucet.
2. To maintain the appearance of your faucet, always blot dry any water from the faucet' s surface.
Clean with a damp, non-abrasive sponge and wipe with a clean soft cloth. To remove water spots,
apply warm water with a damp soft cloth. Always rinse thoroughly after using a cleaning agent.
3. Although the finish is extremely durable, it can be damaged by some cleaners. DO NOT use
detergent powder, polishing powder, granular detergent, or a nylon brush to clean.
4. DO NOT use abrasive detergents. If used, rinse thoroughly and wipe dry with a soft cloth.
5. DO NOT install in working environments less than 32 degrees F (0 degrees C).
6. Shut off the water supply valves when the faucet will not be in use for an extended period of time.
7. DO NOT install the faucet in a rusty or corrosive environment.
8. DO NOT TIGHTEN the faucet too hard to avoid deformation or fracture.
MATERIALS & TOOLS NEEDED
Phillips Screwdriver, Flat Screwdriver, Silicone, Carpenters Level, Pliers, Pipe Wrench, Hacksaw,
Utility Knife.
INSTRUCTION: 117035 | PIIJS7722
TEHILALAUNDRY.COM | support@tehilalaundry.com
SKU #: 114888-040JS7722BLK, 114889-040JS7722SS
WHAT'S INCLUDED IN THE BOX
White
Cabinet
Vanity
Dispenser
STEP 1: Installing the cabinet
1. Unpack the unit and place the cabinet on a blanket or carboard to protect the surface.
2. Turn the Cabinet upside down onto the protec�ve surface (see Fig. A).
3. Install Metal Legs in each corner of the cabinet (see Fig. A).
4. Gently turn the cabinet back to correct posi�on a�er metal legs are installed.
5. Installing door knobs (see Fig. B):
• Remove the door knobs by unscrewing the screws.
• Place the door knobs in front of the doors and �ghten the screws with screwdriver.
Fig. A
We reserve the right to make revisions in the design and information without notice | Image is for reference only, styles varies by models.
ABS Plastic Sink
Drainage Kit
(see step 7 for
break down)
Metal
Strainer Legs


Basket

Screws
(x16)
Fig. B
1. Removing both
2. Install both
door knobs in
4 screws for
front of the doors
each metal leg
Coil Pull-Down Faucet
1. Assembled
Spout & Spray
 2. Deck Plate
3. Rubber Washer

4. Metal Washer
5. C-shaped Clip
with Screws

6. Weight
door knobs first
ID: 33395
Rev. 12/06/2023
pg. 1
