AiPi-CAM-D200 Firmware User Guide
1. Firmware burning
(1) Serial port wiring
TTL Tool
AiPi-CAM-D200
3.3V
VCC
TXD
RX
RXD
TX
GND
GND
(2)AiPi-Cam-Floor installation diagram
After the installation is complete, burning and debugging only requires a Type-C to connect to the USB.
(3)Burning
Tool for burning
：click to download the tool for burning
Firmware
address：Click to download the firmware
After the burning tool starts burning,
first press and hold the "download button (S1)" and then press and
release the "reset button (S2)"
to enter the burning mode. The operation steps of the burning tool are as
follows:
