Summary of Contents for Innovative EASELIFT
- Page 1 Assembly and Care Instructions EASELIFT Powered Toilet Lift Contact www.innovahometech.com info@innovahometech.com (267) 909-4606...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When using an electrical furnishing, basic precautions should always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING ELECTRIC TOILET LIFT SAVE THESE INSTRUCTIONS Danger To reduce the risk of electric shock: ▪ Always unplug this furnishing from the electrical outlet before cleaning or servicing. Warning To reduce the risk of burns, fire, electric shock, or injury to persons: ▪... - Page 3 DIMENSIONS...
-
Page 4: Key Features
KEY FEATURES Ergonomic Angled Handles with Rubber Grips Wide Armrests UP/DOWN Button Battery Indicator 440lbs Weight Height Adjustable Capacity Legs... -
Page 5: Components Included
COMPONENTS INCLUDED A. 1X EaseLift Base Assembly Proceed to Step 2 Proceed to Step 9 B. 1x Right Hadle (with Controls) C. 1x Left Handle D. 2x Armrests E. 1x Battery Charger / Power Supply F. 4x Legs G. Hardware Kit... - Page 6 Right Handle (B): Align the electrical connectors and match the white dots on the wires. ▪ Twist the threaded collar to secure the connection. Test the connection by pressing the buttons to ensure the lift operates properly. Left Handle (C): Insert the handle into the remaining post on the EaseLift Base (A). ▪...
- Page 7 Step 4: Align and Secure the Handles ▪ Ensure both handles fit securely onto the posts. ▪ Align the screw holes on the handles with the holes on the base. Step 5: Tighten the Screws Insert the provided M5x12mm screws (2 per handle) with plastic washers into the aligned holes. ▪...
- Page 8 Step 8: Install the Adjustable Feet Screw the Feet: Attach the adjustable feet to the bottom of the lift. ▪ Adjust Height: Turn the feet to raise or lower the lift. ▪ Ensure the rear support of the lift is slightly higher than the toilet rim (approximately ⅛” to ¼”). Secure the Feet: Tighten the nut at the top of each leg to lock the feet in place.
- Page 9 Assembly of the Toilet Base (Only if You Received it Unassembled) 9.1 Thread the Wire Through the Crossbar Feed the electrical wire through the rear crossbar. ▪ 9.2 Attach the Crossbar to the B-Marked Side Frame ▪ Insert the B-marked end of the crossbar fully into the B-marked side frame. ▪...
- Page 10 9.4 Connect the Crossbar to the A-Marked Base Frame Align the notches on the electrical connectors from the crossbar and A-marked base frame. ▪ Match the white dots on the wires, then twist the threaded collar to secure the connection ▪...
- Page 11 9.7 Attach the Base Seat Place the base seat over the posts on the base frame. ▪ 9.8 Secure the Handles Align the handles with the posts and insert M5x12mm screws (4 per side) into the aligned holes. ▪ Use the provided 3mm Allen wrench to tighten the screws securely. ▪...
- Page 12 Step-by-Step Installation Instructions Step 1: Remove the Existing Toilet Seat Carefully remove the original toilet seat and lid, leaving only the bare ceramic bowl exposed. ▪ Step 2: Prepare for Installation Use the lift's control to raise it, providing better access to the installation area. ▪...
- Page 13 Step 5: Final Alignment and Securing ▪ Ensure the brackets are properly aligned. ▪ Tighten the bolts securely to stabilize the lift. Slide the rear support cover back onto the crossbar to complete the installation. ▪...
-
Page 14: Charging Methods
Avoid Full Discharge: ▪ Do not let the battery completely discharge, as this can shorten its lifespan and may require replacement. By following these steps, you’ll keep your EaseLift Toilet Lift running smoothly and extend the life of your battery. -
Page 15: Care And Cleaning Instructions
▪ ▪ If any issues or defects are found, contact Innovative Home Technologies, LLC for warranty service or repairs. By following these care and cleaning guidelines, you’ll ensure your EaseLift Toilet Lift remains safe, clean, and in excellent working condition. -
Page 16: Troubleshooting Chart
Troubleshooting If you experience any issues with your EaseLift Toilet Lift, please contact our customer service team for assistance. The serial number and date of manufacture can be found on the device label. Troubleshooting Chart Problem Possible Cause Solution The EaseLift Toilet Lift is not lifting or... -
Page 17: Limited Warranty
Welds: A Lifetime Warranty on all welds, ensuring long-lasting durability and safety. If a defect arises, Innovative Home Technologies, LLC will repair or replace the affected product or part at no cost to you, using either new or refurbished parts. Our goal is to ensure your satisfaction and keep your equipment operating like new. - Page 18 COMFORT WHERE INNOVATION MEETS www.innovahometech.com info@innovahometech.com (267) 909-4606 Purchase Date: Order#: Installation Date: THANK YOU...
