PCWork PCW09B User Manual

Copyright Statement
In accordance with international copyright law, you are not allowed to copy the contents of this manual in any form (including
translations) without given permission in written form by the distributor.
General Notes
•
It is not permitted to change the manual in any way or add additional content, without given permission in written form by the
distributor / importer.
•
The operator of this soldering iron is obliged to ensure that every other person using this device has read and understood the
manual, especially the safety instructions.
•
The operator is obliged to ensure proper usage, a functioning device prior usage, the provision of the manual, and that only
qualified users operate the device.
•
Any change related to the design or construction of the device is not permitted.
•
Warranty and any liability in regards to material damage or personal injury are suspended in the following cases:
§ Improper usage and operation of the device; Not following the instructions and safety regulations provided by the
manual; Operation and usage without wearing proper personal protection equipment; Usage and installation of non-
approved spare parts; Improper maintenance and changes related to the design or construction of the device; removal
of the type plate
Safety Instructions
•
The soldering iron is intended for soldering work in the electronics sector within the power and temperature range specified in
these operating instructions.
•
Sufficient ventilation or soldering fume extraction must be provided at the workplace.
•
The equipment is not allowed to be used in potentially explosive environments.
•
Failure to follow the manual and the safety instructions may result in accidents and damage.
•
Any use other than that described in the manual is not permitted and will result in loss of warranty and guarantee as well as
exclusion of liability. This also applies to modifications and conversions of any sort on the device.
•
The soldering iron may only be used:
§ for soldering/desoldering electrical and electronic components in printed circuits and modules; for tinning conductive
tracks and cable ends; for making cable connections.
•
The soldering iron must not be used under any circumstances:
§ for heating liquids or plastic parts
•
The soldering iron may only be used if safe operation is guaranteed. Safe operation of the soldering station is not to be
expected in the following cases:
visible damage to the device; no function of the device; long storage under improper conditions; improper transport
§
•
A defective soldering iron cannot be operated anymore and has to be immediately disconnected from power and secured
against unintentional use.
•
The soldering iron may only be opened and repaired by specialists who are authorized to do so due to their training. Any
intervention by the user may result in a risk of electric shock and will also invalidate the warranty.
•
The soldering iron may only be operated on the 230V (220-240V)/50 Hz AC mains.
•
The switched-on soldering iron must not be left unattended.
•
The soldering iron must not be operated or stored within the reach of children.
•
When used in school, the device must be supervised by an experienced teacher.
•
When using the soldering iron commercially, the relevant accident prevention regulations must be observed.
•
Touching the metallic parts of the heated soldering iron can cause severe burn injuries to humans and animals!
•
The soldering iron must never be immersed in water to cool down.
•
The device must not be subjected to strong mechanical pressure
•
The soldering iron heats up considerably during operation and must only be placed on a stable, solid, non-flammable surface.
•
The soldering iron heats up considerably during operation and must only be placed on a stable, solid, non-flammable surface.
•
When soldering cables and contacts, make sure that conductive, bare metal parts are protected against contact by suitable
measures (cover, insulation with non-flammable material).
•
Use only a dust brush and a soft, slightly moistened cloth to clean the outer housing parts of the soldering iron that has been
switched off, disconnected from the mains and cooled down (do not use harsh cleaners, spray cleaners or solvents). Make sure
that no liquid gets into the interior of the unit through the housing openings during cleaning.
User Manual PCW09B
Digital Soldering Iron
