Smith RC36 Instruction Manual

Single row seeder
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MODEL #: 190813
INSTRUCTION MANUAL
SMITH
®
RC36 Single Row Seeder
(190813)
Do not return this product to the store.
For help, information, or parts contact:
WARNING
Read and fully understand manual
www.thefountainheadgroup.com
before using this product.
(800) 311-9903 | info@thefgi.com
Failure to follow instructions could
result in death or serious injury.
23 Garden St. New York Mills, NY, 13417

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RC36 and is the answer not in the manual?

Questions and answers

Summary of Contents for Smith RC36

  • Page 1 MODEL #: 190813 INSTRUCTION MANUAL SMITH ® RC36 Single Row Seeder (190813) Do not return this product to the store. For help, information, or parts contact: WARNING Read and fully understand manual www.thefountainheadgroup.com before using this product. (800) 311-9903 | info@thefgi.com Failure to follow instructions could result in death or serious injury.

  • Page 2: Table Of Contents

    PARTS AND TOOLS NEEDED FOR ASSEMBLY ....................................3 ASSEMBLING YOUR SMITH® RC36 SINGLE ROW SEEDER ................................3 SEED PLATE EXPLANATION ..........................................5 HOW TO USE THE SMITH® RC36 SINGLE ROW SEEDER ...................................6 SPARE PARTS ..............................................8 1-YEAR LIMITED WARRANTY ........................................9 IMPORTANT SAFETY INSTRUCTIONS •...

  • Page 3: Parts And Tools Needed For Assembly

    Align the center hole of Rear wheel (B) to the back hole of main body frame (D). Tighten nut to secure rear wheel (B). Open the SMITH® RC36 Single Row Seeder box and layout all the contents on the floor. Count all items and make sure they are there.
  • Page 4 (D). Take row marker arm (E) and remove the nut located at the bottom end. Your SMITH® RC36 Single Row Seeder is now complete and you are ready to insert a seed plate. Place the bolt protruding from row marker (E) into the hole shown on main body frame (D).

  • Page 5: Seed Plate Explanation

    Important Seed Plate Information: • The SMITH® RC36 Single Row Seeder will travel 36 inches (91.4cm) for one revolution of the seed plate. • Please see the custom seed fitting if you have a seed that does not fit any of the plates provided.

  • Page 6: How To Use The Smith® Rc36 Single Row Seeder

    5. Adjust the row marker to the correct distance as 2. Insert the seed plate into the RC36 hopper shown. by placing it over the center of the mounting and turning the plate clockwise to lock it into position.

  • Page 7: After Use

    It is advisable to clean the inside of the hopper ready for the next use. Store the SMITH® RC36 and the seed plates bag in a safe dry place ready for future use.

  • Page 8: Spare Parts

    SMITH® RC36 SPARE PARTS - Item Description 186296 Handle, CWSRS101, RC-36 186297 Row Marker Holder, CWSRS102, RC-36 186298 Complete Lower Frame, CWSRS103, RC-36 186299 Rear Wheel with Bolt and Nut, CWSRS104, RC-36 186300 Front Stand with Bolt and Nut, CWSRS105, RC-36...

  • Page 9: Warranty Statement

    WARRANTY STATEMENT 1-Year Limited Warranty This limited warranty gives you, the original product purchaser, specific legal rights. You may also have other rights, which vary from state to state. The Fountainhead Group, Inc. (FGI) warrants to the original product purchaser, that each product will be free from defects in material and workmanship, under normal use and conditions, for a period of one (1) year from the date of purchase.
  • Page 10 www.thefountainheadgroup.com 186225 Rev. A 01/22/2025...
