- Page 1 HV320-EIP-V2 Ethernet/IP Communication Card User Manual HNC Electric Limited...
- Page 2 1. Overview Thank you for using our HV320-V2 series inverter and Ethernet/IP expansion card (hereinafter referred to as HV320-EIP-V2 card). HV320-EIP-V2 card is an Ethernet/IP fieldbus adapter card that complies with the internationally accepted Ethernet/IP Ethernet standard. This card is installed on the HV320-V2 series inverter to improve communication efficiency and facilitate the inverter networking function, making the inverter a slave station of the fieldbus and accepting control from the fieldbus master station.
- Page 3 Figure 2-1 HV320-EIP-V2 card (hardware) Table 2-1 Hardware description of HV320-EIP-V2 card symbol Hardware Name Functional Description Pin connector For connecting to frequency converter J3, J4 network port Uses standard Ethernet RJ45 socket, no direction, uses J3 and J4 to connect to PN card or PLC for communication LD17 Ethernet/IP fault indicator (red)
- Page 4 2.3 Ethernet/IP RJ45 interface The HV320-EIP-V2 card uses standard Ethernet to connect to the Ethernet/IP master RJ45 socket. Its pin signal definition is the same as the standard Ethernet pin. They can be connected using a crossover cable or a straight-through cable.
- Page 5 Communication control related function codes ■ Function name Predetermined area Decimal address code U3-16 Frequency ‑Maximum frequency~Maximum frequency 29456 setting 0.01Hz 0001: Forward operation 0005: Free stop U3-17 control 0002: Reverse operation 0006: Deceleration and stop commands 0003: Forward jog 29457 0007: Fault reset 0004: Reverse jog...
- Page 6 U0-09 AI 1 voltage (V) 0.01V 28681 U0-10 AI 2 voltage (V) 0.01V 28682 U0-11 AI 3 voltage (V) 0.01V 28683 U0-12 Count value 28684 U0-13 Length value 28685 U0-14 Load speed display 100.00% 2868600.00% U0-15 PID Setting 28687 U0-16 PID Feedback 28688 U0-17...
- Page 7 U0-64 Current Back EMF 0.1V 28736 ‑ ‑ U0-65 reserve 100: CANopen 200: Profibus ‑ DP U0-66 Expansion card model 28738 300: CANlink 400: Profinet 500: EtherCAT U0-67 Expansion card version number 0.01 28739 U0-68 Inverter status 28740 U0-69 Operating frequency ( Hz ) 0.01 Hz 28741 U0-70...
- Page 8 Figure 3-3 Tree connection topology 3.3.3 Data transmission format Ethernet/IP Data Format The usage type is divided into five types : PPO type , PPO1, PPO2, PPO3, PPO4, PPO5 The functions that each data format can accomplish are as follows: Table 3-2: PPO type description Type of data Supported Features...
- Page 9 PPO Type Description The data block contained in the PPO type data format is divided into two areas, namely the PK W area (parameter area) and the PZ D area (process data area). The type data format is shown in the figure below： Figure 3-4: PPO type data format PKW Data Description PKW data mainly realizes the master station's read and write operations on a single parameter...
- Page 10 decimal numbers according to) Lower 4 bits: reserved Lower 8 bits: parameter address high bits High 8 bits: parameter address low High 8 bits: parameter address low bits bits Lower 8 bits: reserved Lower 8 bits: reserved High 16 bits: reserved When the request is successful: parameter value Lower 16 bits: not used for read When a request fails: Error code (same as...
- Page 11 Master sends data PZD area Inverter response data PZD area PZD1 PZD2 PZD3~PZD12 PZD1 PZD2 PZD3~PZD12 Control Word Frequency Real-time Status word Operating Real-time (U3–17) setting change of ( U0–68 ) frequency reading of (U3–16) inverter ( U0–69 ) inverter function function parameters...
- Page 12 4. Configure the slave station in LAEconfig software Install the configuration software on your computer After the installation is complete, click Open the software. Software interface introduction The software interface includes: toolbar, module information tree directory, parameter setting area, module information display area, etc. Modify the IP address of the inverter Click the button in the toolbar , click Global Scan, select the IP address to be...
- Page 13 Modify the inverter parameters 7) After modifying the parameters, download the inverter parameters Set the module parameters in the parameter setting area. After setting, click download the module parameters. At this point, the inverter parameter setting is completed. Next is the Ethernet/IP master station settings. Configure the relevant parameters according to the configuration software of different master stations.
- Page 14 Edition: V2.0 Thanks for choosing HNC product. Any technique support, please feel free to contact our support team Tel: 86(20)84898493 Fax: 86(20)61082610 URL: www.hncelectric.com Email:support@hncelectric.com...
