Summary of Contents for AEMC instruments PA32ER
- Page 1 User Manual ENGLISH PA32ER Power Adapter & Battery Charger POWER ADAPTER...
- Page 2 Copyright Chauvin Arnoux , Inc. d.b.a. AEMC Instruments. All rights reserved. © ® ® No part of this documentation may be reproduced in any form or by any means (including electronic storage and retrieval or translation into any other language) without prior agreement and written consent from Chauvin Arnoux , Inc., as governed by United States and International copyright laws.
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1. INTRODUCTION .............4 1.1 INTERNATIONAL ELECTRICAL SYMBOLS .......4 1.2 DEFINITION OF MEASUREMENT CATEGORIES (CAT) ..4 1.3 PRECAUTIONS FOR USE ...........5 1.4 RECEIVING YOUR SHIPMENT ...........6 1.5 ORDERING INFORMATION ..........6 1.5.1 Accessories and Replacement Parts ........6 2. PRODUCT FEATURES ...........7 2.1 DESCRIPTION ..............7 2.2 OVERALL VIEW ..............7 3. -
Page 4: Introduction
Example: hardwired equipment in fixed installation and circuit breakers. CAT II: Corresponds to measurements performed on circuits directly connected to the electrical distribution system. Example: measurements on household appliances and portable tools. PA32ER Power Adapter & Battery Charger... -
Page 5: Precautions For Use
■ Do not modify the instrument and use only original replacement parts. Repairs or adjustments must be performed by authorized personnel. ■ If hazardous voltages are present at the location of measurement, use suitable personal protective equipment. PA32ER Power Adapter & Battery Charger... -
Page 6: Receiving Your Shipment
Save the damaged packing container to substantiate your claim. 1.5 ORDERING INFORMATION Adapter - 1000 V PA32ER Power Adapter & Battery Charger for use with Model 8345, Oscilloscope 9000 Series and CA6116N & CA6117 Multi-Function Installation Testers ...........Cat. #5100.15... -
Page 7: Product Features
2. PRODUCT FEATURES 2.1 DESCRIPTION The PA32ER Power Adapter and Battery Charger is used to power the attached instrument for long-term applications and thereby optimize the instrument’s internal battery. It also serves to recharge the battery. The power source may come from the measurement source or from the wall plug. -
Page 8: Operating Instructions
■ A steady green when the power is on ■ A steady orange when the battery is charging ■ If it blinks, the battery is missing and the instrument is powered by the external power supply alone. PA32ER Power Adapter & Battery Charger... -
Page 9: Charge Directly From The Wall Plug
3.2 CHARGE DIRECTLY FROM THE WALL PLUG Connect the adapter banana plug to the PA32ER power adapter. Connect the plug adapter cord between the adapter and the power socket. Open the elastomer cap on the instrument and connect the 4-point connector of the power adapter to the instrument. -
Page 10: Specifications
Output voltage @ 30 W 15 V ± 8 % Maximum no-load output voltage 16.2 V Ripple of the output voltage 550 mVrms Maximum short-circuit duration Permanent Starting-up time at 110 V < 13 s PA32ER Power Adapter & Battery Charger... -
Page 11: Efficiency
Range of storage: from (-13 to 158) °F (-25 to +70) °C, from (10 to 90) % RH without condensation Electric field: < 1 V/m Magnetic field: < 40 A/m Indoor use Altitude : < 6500 ft (2000 m) Degree of pollution: 3 PA32ER Power Adapter & Battery Charger... -
Page 12: Mechanical Characteristics
BS EN 61010-031 for a voltage of 1000 V CAT IV, degree of pollution 3. The instruments are compliant with FCC Rules part 1 under number 83TD07571. 4.5.2 Electromagnetic compatibility (EMC) The instrument is compliant with standard IEC/EN 61326-1. PA32ER Power Adapter & Battery Charger... -
Page 13: Maintenance
15 Faraday Drive ▪ Dover, NH 03820 USA Phone: (800) 945-2362 (Ext. 360) / (603) 749-6434 (Ext. 360) Fax: (603) 742-2346 E-mail: repair@aemc.com (Or contact your authorized distributor.) NOTE: You must obtain a CSA# before returning any instrument. PA32ER Power Adapter & Battery Charger... -
Page 14: Technical Assistance
AEMC Instruments will repair or replace the faulty material ® at our discretion. REGISTER ONLINE AT: www.aemc.com/warranty.html PA32ER Power Adapter & Battery Charger... -
Page 15: Warranty Repairs
(603) 749-6434 (Ext. 360) Fax: (603) 742-2346 E-mail: repair@aemc.com Caution: To protect yourself against in-transit loss, we recommend that you insure your returned material. NOTE: You must obtain a CSA# before returning any instrument. PA32ER Power Adapter & Battery Charger... - Page 16 09/24 99-MAN 100569 v01 AEMC Instruments ® 15 Faraday Drive • Dover, NH 03820 USA Phone: +1 (603) 749-6434 • +1 (800) 343-1391 • Fax: +1 (603) 742-2346 www.aemc.com © 2021 Chauvin Arnoux , Inc. d.b.a. AEMC Instruments. All Rights Reserved. ®...
