Owner's Manual and Installation Guide
Part No. Model
Volts
37105A
Bass Pro Shops Charger
5 Amp 12
37210A
Bass Pro Shops Charger
10 Amp 12/24
37315A
Bass Pro Shops Charger
15 Amp 12/24/36 5/5/5
IMPORTANT NOTICE
Please save and read all safety, operating and installation instructions before installing or applying AC power to your Bass Pro Shops Charger.
Your Satisfaction is Important to Us!
Do not return this product to retailer or dealer for any service or warranty requirements.
Please call our Customer Care Department at 800-824-0524 from 8:30 am to 5pm Eastern Time for any warranty, service or
installation assistance. Thank you - ProMariner Customer Care
For use with 12 Volt flooded (lead-acid), GEL, AGM and LiFePO4 batteries.
Not for 6 Volt batteries. Not for 4D and 8D large capacity batteries.
Model Number:
Serial Number:
Amps Per Battery Total Amps No. Bat Cables Size (H x W x D) Weight AC In
5
5
1
6'
6.0" x 4.1" x 2.0" 3.3 lbs 110-120V AC 50/60 Hz
5/5
10
2
6'
8.9" x 6.1" x 2.0" 7.0 lbs 110-120V AC 50/60 Hz
15
3
6'
10.4" x 6.5" x 2.4" 10.3 lbs 110-120V AC 50/60 Hz
Date of Purchase:
Advertisement
Table of Contents
Summary of Contents for Bass Pro Shops 37105A
- Page 1 10.4" x 6.5" x 2.4" 10.3 lbs 110-120V AC 50/60 Hz IMPORTANT NOTICE Please save and read all safety, operating and installation instructions before installing or applying AC power to your Bass Pro Shops Charger. Your Satisfaction is Important to Us! Do not return this product to retailer or dealer for any service or warranty requirements.
-
Page 2: Table Of Contents
IMPORTANT NOTICE: FCC CLASS A PART 15 NOTIFICATION Bass Pro Shops Chargers have been designed and tested to comply with FCC Class A part 15. If in a residential setting, you are encountering interference with TV and radio reception, simply remove AC power from the Bass Pro Shops Charger to confirm if it is causing interference. -
Page 3: Important Safety Instructions
To reduce the risk of battery explosion, follow these instructions and those marked on the battery. Do not use the Bass Pro Shops Charger to supply power to an extra-low-voltage electrical system other than in a start-motor application, or to charge non-rechargeable batteries that are commonly used with home appliances. -
Page 4: Grounding And Ac Power Cord Connection Instructions
Monday through Friday, or via www.promariner.com. Unauthorized attempts to service, repair or modify may result in a risk of electrical shock, fire or explosion and will void warranty. 10. To reduce risk of electric shock, unplug charger from outlet before attempting any maintenance or cleaning. 11. -
Page 5: Preparing To Charge A Battery
If electrolyte is taken internally, drink large quantities of water or milk. DO NOT induce vomiting. Get prompt medical attention. LiFePO4 (Lithium) batteries contain hazardous materials that are stored safely during normal use. Do not crush, open or drop the battery housing. Do not touch or ingest any of the released materials or inhale released gasses when accidental leakage of a battery occurs. -
Page 6: Introduction
Pro Shops Charger is fully automatic with a digitally controlled 4-stage charging algorithm proven to extend battery life. Sequential modes of Analyzing, Charging, Conditioning and built-in Auto Maintain mode, safe for short- and long-term storage periods. The Bass Pro Shops Charger can be left on indefinitely without harming or overcharging your batteries. -
Page 7: Installation
7. Connect the DC output cables as illustrated in section "Typical wiring", starting on page 9. Choose the illustration that has the same number of charger output bank cables as your Bass Pro Shops Charger in hand and wire exactly as shown (choose the illustration that matches your application). Ensure the black wires are connected as illustrated to the negative side of the battery and the red wires are connected to the positive side of the battery. -
Page 8: Wiring Your Bass Pro Shops Charger Correctly
Incorrect wiring can result in reverse polarity, caused by putting the "red" + lead on a negative battery terminal and the "black" - lead on the positive terminal. In the event this happens, the Bass Pro Shops Charger has been designed to not fail as a result;... -
Page 9: Typical Wiring
Typical wiring 5 Amp single bank charger for one 12V battery Indicates Fuse 5 AMP 1 Bank Charger Cable 1 Note: for engine battery use cable 1 Top View of Battery Engine Crank Battery or 12 V Trolling Motor / House Battery Figure 1 Dedicated 12 V Trolling Motor, House or Engine Battery Configuration 5/5 Dual bank charger for two 12V batteries in series... -
Page 10: 5/5 Dual Bank Charger For Two 12V Batteries In Parallel
5/5 Dual bank charger for two 12V batteries in parallel Indicates Series Jumper Indicates Fuse 2 Bank Charger Note: for engine battery use cable 1 Cable 1 Cable 2 Black Black Black Jumper Top View of Battery Figure 3 Dedicated 12 VDC Parallel Trolling Motor or House Configuration 5/5 Dual bank charger for two 12V batteries with dedicated starter battery Indicates Fuse 2 Bank... -
Page 11: 5/5/5 Triple Bank Charger For Three 12V Batteries With 2 Engine Crank Batteries
5/5/5 Triple bank charger for three 12V batteries with 2 engine crank batteries Indicates Fuse 5/5/5 3 Bank Charger Note: for engine battery use cable 1 Cable 3 Cable 1 Cable 2 Top View Bat 2 Bat 1 Bat 3 of Battery Engine Engine... -
Page 12: 5/5/5 Triple Bank Charger For Three 12V Batteries In Series
5/5/5 Triple Bank Charger for three 12V Batteries in Series Indicates Series Jumper Indicates Fuse 5/5/5 3 Bank DANGER: RISK OF Charger ELECTRIC SHOCK Do not touch uninsulated portion of output connector or uninsulated Note: for engine battery terminal if 3 or more batteries battery use cable 1 are connected in series. -
Page 13: General Operation
General operation Overview The Bass Pro Shops Charger is available in 3 core models with 5A, 10A or 15A outputs and can be used in 12, 24 and 36-Volt systems (model specific). POWER LED BANK NUMBER STATUS LEDS STATE OF CHARGE OR TROUBLE STATUS... -
Page 14: 4-Stage Digital Charging - How It Works
Pro Shops Charger utilizes the non-Lithium or the Lithium charge profile. The following applies to each individual charging output. Stage 1 - Analyze mode: After AC Power is applied, the Bass Pro Shops Charger will analyze the battery for proper connection and state of charge. When completed, any errors will trigger a red trouble status LED, if no faults are present the charger will proceed to stage 2. -
Page 15: Troubleshooting
LEDs do not illuminate, contact ProMariner Factory Service at 1-800-824-0524 from 8:30 am to 5pm Eastern Time. If your Bass Pro Shops Charger is within the warranty period of 3 years from the date of purchase, you can go to www.promariner.com where you will find our customer care return form and instructions. -
Page 16: Owner's Periodic Maintenance Guide
When: Monthly / Before and after each long trip or extensive use of batteries Item: Bass Pro Shops Charger DC Output Wiring Process: Visually inspect all wiring for cuts and abrasions. Contact ProMariner if your charger needs to be serviced. -
Page 17: Liability
Possible errors in the included manual and the consequences of these. Use that is inconsistent with the purpose of the Bass Pro Shops Charger. Disclaimer: Our products are subject to continual development and improvement. Therefore, additions or modifications to the products may cause changes to the technical data and functional specifications. No rights can be derived from this document. -
Page 18: Warranty
We are committed to customer satisfaction and value your business. If at any time during the warranty period you experience a problem with your new Bass Pro Shops Charger, simply call us at 1-800-824-0524 between 8:30am- 5pm (EST) Monday through Friday, for technical support or email info@promariner.com WARRANTY CARD CAN BE REGISTERED AT WWW.PROMARINER.COM... - Page 19 Visit ProMariner online at www.promariner.com frequently, we are always adding new products for your boating enjoyment! ProMariner™ Customer Service TEL: 1-800-824-0524 Specifications subject to change without notice www.promariner.com Conforms to UL STD. 1236 Certified to CSA STD. C22.2 No. 107.2 FCC Class A, CEC and Made in China DOE listed Designed and Constructed to ABYC A-31...
