- Page 1 USER CUBE Scan for Specifications GUIDE Keep this manual for future reference © 2024 Coastal Source...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Features & Benefits Wiring Installation Cabling Rules Connecting the Plug+Play™ Connector Sound Tuning Subwoofer Placement Setup & Installation Guidelines Specifications Warranty Information INSTALLATION INSTRUCTIONS Connect the Plug+Play™ Connector Phase Inversion Top Installation Placement... -
Page 3: Features & Benefits
CUBE FEATURES & BENEFITS • Coastal quality powerful and extended bass from a compact, 17” cube. • Designer-friendly configuration that allows for customization with a selection of drop-in natural stone tops or the ability to have our contractor make a drop in that matches your decking or other desired finish. -
Page 4: Specifications
See Lifetime Care Program for additional options. Dispersion: Omni-Directional This product bears a five (5) year limited warranty.* Impedance: 8 ohms * All Coastal Source products bear a 2-year limited warranty for Mounting: Freestanding commercial/non-residential installations. Input Connector: (1) Uni-Connect 8C 16AWG Male... -
Page 5: Installation Instructions
INSTALLATION INSTRUCTIONS CUBE Subwoofer User Guide | coastalsource.com... -
Page 6: Connect The Plug+Play™ Connector
CONNECT THE PLUG+PLAY™ CONNECTOR Align key-way of cable to key-way of connector and fully insert cable into connector. Carefully rotate the covering nut until finger tight. CUBE Subwoofer User Guide | coastalsource.com... -
Page 7: Phase Inversion
If phase inversion is required (see above for details), unscrew the capswitch counterclockwise to remove. Replace the capswitch with arrow now pointing to 180º, and secure by screwing the cap on in a clockwise direction until tight. CUBE Subwoofer User Guide | coastalsource.com... -
Page 8: Top Installation
TOP INSTALLATION Install stone top (or custom fabricated top) directly into the top of CUBE by placing one side down into the recess and then carefully lowering the other side to sit flush. Link to custom fabrication template CUBE Subwoofer User Guide | coastalsource.com... -
Page 9: Placement
PLACEMENT Place subwoofer in desired final location. Hardscape Installation Landscape Installation CUBE Subwoofer User Guide | coastalsource.com...
