Summary of Contents for Norden NFA-T01SD
- Page 1 INTELLIGENT ADDRESSABLE OPTICAL SMOKE DETECTOR INSTALLATION AND OPERATION MANUAL www.nordencommunication.com www.nordencommunication.com 1405010819-Rev1.0-0125 Norden Communication UK Ltd.
-
Page 2: Product Safety
For more information, please visit the website at www.recyclethis.info EN54 Part 7 Compliance NFA-T01SD Intelligent Addressable Optical Smoke Detector complies with the requirements of EN 54-7:2018. EN54 Standard Conformity Information... -
Page 3: Table Of Contents
Technical Specification..................4 Installation ..........................5 Installation Preparation..................5 Installation and Wiring..................5 Detector Configuration......................6 Preparation......................6 Write: Addressing....................6 Set: LED On/Off.....................7 Read Configuration....................8 General Maintenance......................8 Cleaning.........................8 Troubleshooting Guide......................9 Appendix 1............................10 Limitation of Intelligent Addressable Optical Smoke Detector..........10 www.nordencommunication.com 1405010819-Rev1.0-0125 Norden Communication UK Ltd. -
Page 4: Introduction
1.Introduction 1.1.Overview The NFA-T01SD Intelligent Addressable Optical Smoke Detector is well-suited for a wide range of ap- plications, thanks to its excellent linear response to various smoke patterns. Manufactured to meet the sensitivity requirements of the European Standard EN 54 part 7, this unit features an aesthetically pleasing and unobtrusive design that complements modern building aesthetics. -
Page 5: Installation
Do not remove the red plastic dust cover until the final handover is done. The connecting line of remote indicator should be less than 30 meters. Normal Base Figure 1 www.nordencommunication.com 1405010819-Rev1.0-0125 Norden Communication UK Ltd. -
Page 6: Detector Configuration
1 to 254, and then press “Write” to save the new address (Figure 5). Note: If display “Success”, means the entered address is confirmed. If dis- Figure 3 play “Fail”, means failure to program the address (Figure 6). www.nordencommunication.com 1405010819 -Rev1.0-0125 Norden Communication UK Ltd. -
Page 7: Set: Led On/Off
3.R/ W Config 7 0- LED On (Default) 4.Set 1- LED Off Success Figure 7 Figure 8 Press “Exit” key to go back to the Main Menu. Press “Power” to switch off the programming tool. www.nordencommunication.com 1405010819-Rev1.0-0125 Norden Communication UK Ltd. -
Page 8: Read Configuration
Position the chamber and screen by aligning three tiny holes over the sensing component. (Fig- ure 12). Align the LED tube and tabs and gently push the cover until it locks into place. (Figure 12). Re-install and test the detector. www.nordencommunication.com 1405010819 -Rev1.0-0125 Norden Communication UK Ltd. -
Page 9: Troubleshooting Guide
Conduct maintenance The address is duplicate Re-Commission the device Unable to commission The damage is in the Replace the detector electronic circuit Keep Indicating Fire signal The detector chamber Clean the detector is dirty www.nordencommunication.com 1405010819-Rev1.0-0125 Norden Communication UK Ltd. -
Page 10: Limitation Of Intelligent Addressable Optical Smoke Detector
Therefore, test your smoke detector at least every half-year according to national codes or laws. Any smoke detectors, fire alarm devices or any other components of the system must be repaired and/or replaced immediately if they fail. www.nordencommunication.com 1405010819 -Rev1.0-0125 Norden Communication UK Ltd. - Page 11 Norden Communication UK Ltd. Unit 10 Baker Close, Oakwood Business Park Clacton-On- Sea, Essex POST CODE:CO15 4BD Tel : +44 (0) 2045405070 | E-mail : salesuk@norden.co.uk www.nordencommunication.com www.nordencommunication.com 1405010819-Rev1.0-0125 Norden Communication UK Ltd.
