- Page 1 USE & CARE August 20, 2024 E6010.00 TWO SPEED RECIPROCATING SHAKER 180, 280 ± 2 OPM, 115 V, 60 HZ, 3.4A, SINGLE PHASE 5900 Schooner Dr, Belleville MI 48111 – USA TEL (800) 422-2558 – FAX (734) 665-9099 www.EberbachLabtools.com...
-
Page 2: Table Of Contents
Installation ....................8 IIIb. Lubrication:....................9 IIIc. Belt inspection: ....................9 IIId. Belt replacement and Adjustment: ............... 9 IV. Replacement Parts .................... 10 IVa. Replacement Parts for E6010.00 ..............11 IVb. Replacement Parts for Accessories .............. 12 V. Drawings ......................13... -
Page 3: Introduction
Introduction Page 3 of 20... -
Page 4: Ia. Preliminary
Preliminary The E6010.00 is a reciprocating shaker that a utility box is placed on top of to hold a wide variety of containers. Custom utility boxes can be designed. Please contact Eberbach if a custom utility box is needed. Unpacking Save the packaging in case the unit needs to be returned. -
Page 5: Original Instructions
Original Instructions Page 5 of 20... -
Page 6: Iia. Operation
Operation IIa. 1. Load shaker with container a. Ensure that the shaker is not overloaded to prevent walking. 2. Clamp containers using the bar clamps supplied with utility box. 3. Flip switch to desired speed setting a. Up is high (280 OPM) b. -
Page 7: Maintenance
MAINTENANCE III. QUALIFIED SERVICE PERSONNEL ONLY A qualified service personnel is trained in the assembly and disassembly of the machine to ensure that when the machine is maintained that it goes back to the NORMAL USE condition. Changes or maintenance of the machine are to NOT be performed by the operator. -
Page 8: Iiia. Installation
Installation IIIa. 1. Clean off area where shaker will be placed. a. Surface must be clear of cracks or voids. b. Shaker must be placed on a rigid bench or table 2. Placed shaker in cleaned area. 3. Plug shaker into a 115 V power outlet. 4. -
Page 9: Iiib. Lubrication
Lubrication: IIIb. See exploded view of shaker power unit for points of lubrication. Use a good grade of SAE #30 oil. Lubrication when shaker is used in continuous duty applications of 100 hours or more: A. Oil the crank bearing through the hole in the center of the bearing bracket every 3 months. B. -
Page 10: Replacement Parts
Replacement Parts Page 10 of 20... -
Page 11: Iva. Replacement Parts For E6010.00
Replacement Parts for E6010.00 IVa. Part # Description Qty. 4280.1 GATES 3L280 BELT 4351 COLLAR 4487 8" PULLEY X 1/2" BORE, 7.66" PITCH 5528 3.75" SUCTION CUP W/ 5/16-18 THREADED POST 6063.1 CABLE TIE MOUNT 6063.2 ZIP TIE 6129 FUSE, 5AMP TIME DELAY 6131.1... -
Page 12: Ivb
500 ML SEPARATORY FUNNEL HOLDER E6095.50 E6095.60 1000 ML SEPARATORY FUNNEL HOLDER E6095.60 E6095.70 2000 ML SEPARATORY FUNNEL HOLDER E6095.70 If you have any doubts or inquiries concerning parts, contact your supplier or Eberbach Corporation technical service @ (800) 422-2558. Page 12 of 20... -
Page 13: Drawings
Drawings Page 13 of 20... - Page 14 Page 14 of 20...
- Page 15 Page 15 of 20...
- Page 16 Page 16 of 20...
- Page 17 Page 17 of 20...
- Page 18 Page 18 of 20...
- Page 19 Page 19 of 20...
- Page 20 Page 20 of 20...
