APstorage (NA)
ELS-5K/3K&BATTERY
ACCESSORIES
REV1.0 2025-01-20
LIST OF BATTERY ACCESSOEIES

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ELS-5K-EU and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for APstorage ELS-5K-EU

Summary of Contents for APstorage ELS-5K-EU

  • Page 1 APstorage (NA) ELS-5K/3K&BATTERY ACCESSORIES REV1.0 2025-01-20 LIST OF BATTERY ACCESSOEIES...

  • Page 2: Table Of Contents

    Table of Contents Table of Contents ........................2 1. ELS Connects to Grid/Backup ....................1 2. ELS Connects to Battery ....................... 3 APstorage Battery Series Accessories (APbattery-48V-5.76KWh) ............3 UZ Battery Series Accessories(UZ Power Lite Series L051100-B UZ PLPA-L1-10K2) ..... 5 Soluna Battery Series Accessories(Soluna EOS 5K Pack/10K Pack LV) ..........

  • Page 3: Els Connects To Grid/Backup

    1. ELS Connects to Grid/Backup 1.1 Wiring Diagram with Grid/Backup ELS-3K/5K Standard Configuration： Expansion Quick Wall-mounted Fixing screw CT(current screw Installation Bracket (M6×14) transformer) (M8*70) Guide Optional Configuration： AC Cable（L2） Terminal（1） AC Cable（L1） AC Cable（N） AC Cable（PE） Category Part No. 2385140008_Ter AC Cable(105℃...

  • Page 4: Table Of Contents

    ELS-5K Optical Storage - On-Grid + Off-grid ELS-5K/3K&BATTERY ACCESSOEIES...

  • Page 5: Els Connects To Battery

    2. ELS Connects to Battery APstorage Battery Series Accessories (APbattery-48V-5.76KWh) 2.1.1 Wiring Diagram with Apstorage Battery (Single unit), outdoor usage（IP65） 2.1.2 Wiring Diagram with Apstorage Battery (Parallel Connection), outdoor usage（IP65） ELS-5K/3K&BATTERY ACCESSOEIES...
  • Page 6 Batteries are connected in PCS-provides parallel NOTE： [1] IF APstorage Battery -U-48V-5.76KWh battery is used, a circuit breaker must be used; [2] Delivered in rolls and cut to the desired length according to the customer; Communication cable [3] THE APstorage Battery only pins 7 and 8 are to be used ELS-5K/3K&BATTERY ACCESSOEIES...

  • Page 7: Uz Battery Series Accessories(Uz Power Lite Series L051100-B Uz Plpa-L1-10K2)

    UZ Battery Series Accessories(UZ Power Lite Series L051100-B UZ PLPA-L1-10K2) 2.2.1 Wiring Diagram with C300 (Single unit), indoor usage（IP20） 2.2.2 Wiring Diagram with C300(Parallel Connection), indoor usage（IP20） ELS-5K/3K&BATTERY ACCESSOEIES...
  • Page 8 Product optional configuration Items Quantity(Single unit) Specifications Pictures Provider Connect PCS to Breakers; 2031515016- DC UL3820,AWG3；Orange and APSTORAGE Cable Black; 2381230008 Connect Cables with Empty 10 pcs APSTORAGE -Round terminals openings(TL35-8) Battery Breaker: 125A DC DC Breakers...

  • Page 9: Soluna Battery Series Accessories(Soluna Eos 5K Pack/10K Pack Lv)

    Soluna Battery Series Accessories(Soluna EOS 5K Pack/10K Pack LV) 2.3.1 Wiring Diagram with Soluna Battery (Single unit), outdoor usage（IP54） 2.3.2 Wiring Diagram with Soluna Battery (Parallel Connection), outdoor usage（IP54） ELS-5K/3K&BATTERY ACCESSOEIES...
  • Page 10 0.5M; Product optional configuration Items Quantity(Single unit) Specifications Pictures Provider Connect PCS to Breakers; 2031515016- DC UL3820,AWG3；Orange APSTORAGE Cable and Black; Battery Breaker: 125A DC DC Breakers 1 pcs Self - Contained Breaker 2381230008 Connect Cables with 10 pcs...

  • Page 11: Fortress Battery Series Accessories(Eflex 5.4)

    FORTRESS Battery Series Accessories(EFLEX 5.4) 2.4.1 Wiring Diagram with FORTRESS Battery (Single unit), outdoor usage（IP54） 2.4.2 Wiring Diagram with FORTRESS Battery (Parallel Connection), outdoor usage（IP54） ELS-5K/3K&BATTERY ACCESSOEIES...
  • Page 12 Power Cable 1 set Self - Contained Omegor,UL3820,AWG3, Tinned copper wire, Black and red Connect PCS to Breakers; 2031515016- DC APSTORAGE UL3820,AWG3；Orange Cable and Black; Battery Breaker: 125A DC DC Breakers 1 pcs Breaker(When the cable Self - Contained is more than two meters)

  • Page 13: Pytes Battery Series Accessories(E-Box-48100R)

    PYTES Battery Series Accessories(E-BOX-48100R) 2.5.1 Wiring Diagram with PYHES Battery (Single unit), outdoor usage（IP54） 2.5.2 Wiring Diagram with PYHES Battery (Parallel Connection), outdoor usage（IP54） ELS-5K/3K&BATTERY ACCESSOEIES...
  • Page 14 OT M6 Product optional configuration Items Quantity(Single unit) Specifications Pictures Provider Connect PCS to Breakers; 2031515016- DC APSTORAGE UL3820,AWG3； Cable Orange and Black; Battery Breaker: DC Breakers 1 pcs Self - Contained 125A DC Breaker Connect Cables with 2381230008...

  • Page 15: Homegrid Battery Series Accessories(Pf5-Lfp04800/ Lfp09600/ Lfp14400/Lfp19200/ Lfp24000 / Lfp28800/ Lfp33600/ Lfp38400-2A01)

    HOMEGRID Battery Series Accessories(PF5-LFP04800/ LFP09600/ LFP14400/ LFP19200/ LFP24000/ LFP28800/ LFP33600/ LFP38400-2A01) 2.6.1 Wiring Diagram with HOMEGRID Battery (Single unit), outdoor usage（IP54） ELS-5K/3K&BATTERY ACCESSOEIES...
  • Page 16 Product optional configuration Items Quantity(Single unit) Specifications Pictures Provider Connect PCS to Breakers; 2031515016- UL3820,AWG3； Orange and APSTORAGE DC Cable Black; Battery Breaker: 125A DC DC Breakers 1 pcs Breaker(When the cable is Self - Contained more than two meters)

  • Page 17: Goldenmate Battery Series Accessories

    GOLDENMATE Battery Series Accessories (APOLLO–6–LV/APOLLO–9–LV/APOLL- 12 - LV/APOLLO -15 -LV) 2.7.1 Wiring Diagram with GOLDENMATE Battery (Single unit), outdoor usage（IP54） ELS-5K/3K&BATTERY ACCESSOEIES...
  • Page 18 Product optional configuration Items Quantity(Single unit) Specifications Pictures Provider Connect PCS to Breakers; 2031515016- DC UL3820,AWG3；Orange APSTORAGE Cable and Black; Battery Breaker: 125A DC DC Breakers 1 pcs Breaker(When the cable is Self - Contained more than two meters) 2381230008...

  • Page 19: Gsl Battery Series Accessories(Gsl-051280A-B-Gbp2)

    GSL Battery Series Accessories(GSL-051280A-B-GBP2) 2.8.1 Wiring Diagram with GSL Battery (Single unit), outdoor usage（IP54） 2.8.2 Wiring Diagram with GSL Battery (Parallel Connection), outdoor usage（IP54） ELS-5K/3K&BATTERY ACCESSOEIES...
  • Page 20 OT M6 Product optional configuration Items Quantity(Single unit) Specifications Pictures Provider Connect PCS to Breakers; 2031515016- DC 25mm²; Orange and APSTORAGE Cable Black; Battery Breaker: 125A DC DC Breakers 1 pcs Self - Contained Breaker 2381230008 Connect Cables with 10 pcs...
  • Page 21 Summarize: ① This quantity is the required quantity of a single machine, and the required quantity for parallel connection needs to be increased according to the number of parallel batteries. ② Whether the battery needs a DC Box depends on whether the output port of the battery has double the positive and negative terminals.
  • Page 22 APsystems USA 8627 N. Mopac Expy, Ste 150 Austin, TX 78759 United States of America Phone: 1-844-279-8600 Email: info.usa@APsystems.com Web: usa.APsystems.com APsystems Mexico Av. Lázaro Cárdenas #3422 int 604,Col. Chapalita. Zapopan, Jalisco. C.P. 45040. México Phone: 01(33) 3188 4604 Email: info.latam@APsystems.com Web: latam.APsystems.com ELS-5K/3K&BATTERY ACCESSOEIES...
