Outdoor LED Installation Manual
- XHB Series -
Fascia Cabinet
LHX10**F2*0
2x3 / 2x2 Cabinet
Z-Case
&
Rev. V2
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XHB Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung XHB Series

Summary of Contents for Samsung XHB Series

  • Page 1 Outdoor LED Installation Manual - XHB Series - Fascia Cabinet LHX10**F2*0 2x3 / 2x2 Cabinet Z-Case & Rev. V2...

  • Page 2: Revision History

    Revision History Modified pag Date Contents Modified by 230814 Initial version release Jaewook.Jeon 3-5(P49, P50) 231023 Light Sensor Update : spec, cabling, multi S-BOX case JC Jeon 3-8(P53)

  • Page 3: Table Of Contents

    Table of Contents Contents Page Installation Precautions 1-1) Important Guidelines to Follow 1-2) Label and location 1-3) Tools and Accessory Product Information 2-1) XHB-F Product Information 2-2) XHB-F Product Size 2-3) XHB-F Cabinet 2-4) How to distinguish the top, bot, left, right side of the module 2-5) XHB-F Circuit Materials location 2-6)
  • Page 4 Table of Contents Contents Page 3-3) Z-CASE Installation 3-4) Z-CARD Setup 3-5) Cabling Connection 3-6) Control Room Setting 3-7) Screen System Configuration 3-8) Power Connection Maintenance 4-1) Buffer Materials 4-2) Top Service LSM Configuration Guide...

  • Page 5: Installation Precautions

    - If the maximum number of power sources is exceeded, the product may become damaged or the circuit breaker may trip due to over- current. Samsung is not responsible for any problem caused by exceeding the recommended number of power sources for connection.
  • Page 6 1. Installation Precautions 1) Important Guidelines to Follow ◆ Precautions prior to Installation - Ensure that all personnel at the site of installation wear personal protection equipment, such as safety helmets, safety glasses, safety gloves and other appropriate safety equipment. - Ensure that at least two persons work together to move or transport the product so as to ensure safety.
  • Page 7 1. Installation Precautions 1) Important Guidelines to Follow ◆ Precautions for prevention of damage to LED ① [Cation to prevent external shock and dropping of the product] After removing the protective brackets, be careful not to expose the product to external shocks or vibrations. Make sure that the product is not dropped from any height ②...

  • Page 8: Label And Location

    1. Installation Precautions 2) Label and location ◆Product/BOX [Label BOX : BOX] [Label Rating : Cabinet Rear]...

  • Page 9: Tools And Accessory

    1. Installation Precautions 3) Tools and Accessory ◆ Tools required to be prepared by SI Mechanical installation tool Installation material Electronic installation tool M12 L30 washer bolt grade10.9 Fy = 900MPa, Cordless Drill Ratchet with Combination Level Wire Crimpers RJ45 Crimping Tool Wire Cutters Wire Strippers Fu = 1000MPa...
  • Page 10 1. Installation Precautions 3) Tools and Accessory ◆ Tools and Accessory prepared by Samsung (Total) Category Sub. Cat code number part name Description Kit Model Code quantity 1) round : cabinet quantity/4, BN91-24740A Z-Clip-Wall Z-Clip BRACKET (Wall-side) - 4ea/box VG-XHFW4KIT...
  • Page 11 1. Installation Precautions 3) Tools and Accessory ◆ Tools and Accessory prepared by Samsung (Tools) Tool Kit (VG-XHTSSKIT) BN91-24345A A/S-T HANDLE A/S-T HANDLE BN81-23767A, 2EA BN81-23768A, 2EA SCREW-MACHINE(M2, L5.5) 6003-001910, 20EA A/S- SCREW TAPTYPE (M2, L18) BN81-24012A, 5EA A/S-CAP RUBBER...
  • Page 12 1. Installation Precautions 3) Tools and Accessory ◆ Tools and Accessory prepared by Samsung (Mechanical Accessory) Z-Clip-Wall (VG-XHFB4KIT) Z-Clip-Cab (VG-XHFW4KIT) BN91-24741A BN91-24740A BRACKET-CLIP, 1EA BRACKET-CLIP, 4EA (AL, 6.35T, BLACK) (AL, 6.35T, BLACK) BOLT-ETC, 20 EA (M8,L25,Zn-Ni(BLK),RH,+,SWRCH18A)
  • Page 13 1. Installation Precautions 3) Tools and Accessory ◆ Tools and Accessory prepared by Samsung (Mechanical Accessory) End-Trim-Kit-x2 (VG-XHF22KIT) End-Trim-Kit-x3 (VG-XHF32KIT) BN91-24742A BN91-24743A COVER-DECORATION RIGHT, 1EA COVER-DECORATION RIGHT, 1EA (AL, 2.0T, BLACK) (AL, 2.0T, BLACK) COVER-DECORATION LEFT, 1EA COVER-DECORATION LEFT, 1EA (AL, 2.0T, BLACK)
  • Page 14 1. Installation Precautions 3) Tools and Accessory ◆ Tools and Accessory prepared by Samsung (Cable) VG-XHSP1KIT VG-XHSD1KIT VG-XHSL1KIT BN91-24675A BN91-24676A BN91-24677A AC Power cable Data Cable - 2 Data Cable - 1 1.5m x 1ea, 9m x 2ea, 60m x 2ea 1.5m x 2ea,...
  • Page 15 1. Installation Precautions 3) Tools and Accessory ◆ Tools and Accessory prepared by Samsung (Z-CASE & C-CASE & S-BOX) VG-XHZF2KIT VG-XHFC1KIT SBB-CX4BPES BN91-24678A BN91-24354A BN91-24679A Fascia : Z-CASE Fascia : S-BOX Fascia : C-CASE (Z-Card x 2 탑재) (Circuit Breaker 탑재)
  • Page 16 1. Installation Precautions 3) Tools and Accessory ◆ Tools and Accessory prepared by Samsung (Buffer List) Marketing Category Sub. Cat Model Code Circuit Materials Short Desc Project BN94-17977A [Bridge, 3ea], BN94-17761F [PCB Main 1ea] XHB_kit VG-XHDB1TDF Sparing product to exchange D-BOX (F23, 8K nit)
  • Page 17 1. Installation Precautions – T-CON Board Replacement After recording the Cabinet RGB CC value through LSM before replacing the T-Con board, Enter the same value in the replaced T-Con board. Enter the CC value of the existing T-CON board.

  • Page 18: Product Information

    2. Product Information 1) XHB-F Product Information XHB-F MODULE SPECIFICATIONS OUTDOOR P10 2x3 OUTDOOR P10 2x2 INDOOR P10 2x3 INDOOR P10 2x2 Pitch Diode Xindeco-Gold Xindeco-Cu Brightness 8,000nit 2,000nit Contrast Ratio 8000 : 1 2000 : 1 Viewing Angle-Horizontal H : 160° ( ±80°) Viewing Angle-Vertical V : 117°...

  • Page 19: Xhb-F Product Size

    2. Product Information 2) XHB-F Product Size Category Spec Cabinet size (A1xA2) 689.5 mm x 1117.5 mm Module size (B1xB2) 344.56 mm x 344.56 mm Set depth (C) 233.0 mm Diagonal (D) 1243.77 mm (48.96 inch) Lid tilt angle (E) 15 º...

  • Page 20: Xhb-F Cabinet

    2. Product Information 3) XHB-F Cabinet ◆ Module Configuration : 2x3 / 2x2 Matrix × 6 × 4...
  • Page 21 2. Product Information 3) XHB-F Mechanical Design ◆ Fascia 2x3...
  • Page 22 2. Product Information 3) XHB-F Mechanical Design ◆ Fascia 2x2...
  • Page 23 2. Product Information 4) How to distinguish the top, bottom, left and right sides of the module (Check the back of the module) ◆ Module top and bottom classification: Check the imprinted letters on the back of the module or the top of the module (Module Top) where the BOSS interval is far.

  • Page 24: Xhb-F Circuit Materials Location

    2. Product Information 5) XHB-F Circuit Materials location ◆ Fascia 2x3 ⑤ ④ Category Spec ① Bridge Board ⑥ ② T-CON ③ SMPS ③ ④ AC-CONNECTOR(OUTLET) ② ⑤ AC-CONNECTOR(INLET) ⑥ DATA-CONNECTOR ①...
  • Page 25 2. Product Information 5) XHB-F Circuit Materials location ◆ Fascia 2x2 Category Spec ⑤ ④ ① Bridge Board ⑥ ② T-CON ② ③ SMPS ③ ④ AC-CONNECTOR(OUTLET) ① ⑤ AC-CONNECTOR(INLET) ⑥ DATA-CONNECTOR...

  • Page 26: Circuit Configuration

    2. Product Information 6) Circuit configuration ◆ Overview Control Power Control Power Control Power Power Power...
  • Page 27 2. Product Information 6) Circuit configuration ◆ Data BOX Board & Cabling AC INLET T-CON Board FPGA XC7A50T TCON Bridge Board Module(46P) Module(46P) SMPS...
  • Page 28 2. Product Information 6) Circuit configuration ◆ External Connector & Terminal Cabling...
  • Page 29 2. Product Information 6) Circuit configuration ◆ Z-CASE, S-BOX S-BOX Z-CASE [ XHB Compatible Model : SBB-CX4BPES/**] Signal Input : QSFP 4 PORT Signal Input : HDMI(2), DP(1), USB(2) Signal Output : Ethernet 5PORTx 2 Signal Output : QSFP+ x 4 Power Input : AC POWER 1 PORT Power Input : AC POWER 1 PORT...
  • Page 30 2. Product Information 6) Circuit configuration ◆ Circuit Breaker Case - Samsung even provides Circuit Breaker Case (Circuit Breaker is worked on site by SI company) - AC OUTLET 7 EA + Wall Power Input 1 EA [Installation on Cabinet Rear]...
  • Page 31 2. Product Information 6) Package (XHB Fascia 2x3 Cabinet) ◆ Outside Read the information in the atta ched label to check the Model Code. BOX UNIT(L1285*W532*H838)
  • Page 32 2. Product Information 6) Package (XHB Fascia 2x3 Cabinet) Cabinet Module PAD-EPE...
  • Page 33 2. Product Information 6) Package (XHB Fascia 2x2 Cabinet) ◆ Outside Read the information in the atta ched label to check the Model Code. BOX UNIT(L940*W532*H838)
  • Page 34 2. Product Information 6) Package (XHB Fascia 2x2 Cabinet) Cabinet Module...

  • Page 35: Installation

    3. Installation 1) Unboxing Cabinets 5) Cabling Connection 2) Handling Cabinets 6) Accessory Assembly 3) Mounting Cabinets 7) Control Room Setting 4) Z-CASE Installation 8) Software Set-up...

  • Page 36: Mounting Cabinets

    3. Installation 1) Mounting cabinets ◆ SEAM control information - GAP between Modules 0.2 ≤ A ≤ 0.8mm 0.2 ≤ B ≤ 0.8mm MISMATCH │C│ ≤ 0.4mm MISMATCH │D│ ≤ 0.8mm - GAP between Cabinets 0.1 ≤ A ≤ 0.8mm 0.1 ≤...

  • Page 37: Handling Cabinets

    3. Installation 2) Handling Cabinets ◆ Bracket-Clip (Wall) Installation - Fix the bracket-clip to the wall you want to install. - According to the environment of the wall where the product is fixed, the construction company determines the type of screw and proceeds with the installation.
  • Page 38 3. Installation 2) Handling Cabinets 19.75 20.0 ◆ Reference : CABINET gap 170.1 302.7 772.5 1117.5 236.7 290.8 <2x2> 290.8 406.0 <2x3> 51.0 39.75 689.5...
  • Page 39 3. Installation 2) Handling Cabinets ◆ Bracket-Clip (Cabinet) Installation - Select and install the following A-E locations according to the installation environment. - Install using the enclosed BOLT. (Torque : 13-15 kgf·cm ↓) BRACKET-CLIP BRACKET-CLIP <2X3> <2X2>...

  • Page 40: Cabinet Mounting

    3. Installation 2) Handling Cabinets ◆ Cabinet Mounting - Cabinet mounting by using installed bracket Slot Hole M8 Nut M8 Bolt M8 Bolt Side-by-side...
  • Page 41 3. Installation 2) Handling Cabinets ◆ End trim kit Installation (Cover-Decoration) - Install Cover-Decoration at the end of Fascia. - Remove the existing SCREW and install the Cover-Decoration. (Torque : 7-8 kgf·cm ↓) - Pay attention to the distinction between LEFT and RIGHT. - The enclosed SCREW is used as an extra.

  • Page 42: Z-Case Installation

    [Control PC] [S-Box] [Z-Case] [LED Screen] * 『QSFP+』 optical modules/cables should be provided by others. (Installer) * From Z-Case to Cabinet LAN cables (CAT6) will be provided by SAMSUNG. ※ Optical Module/Cable Information Optical Module Optical Module/Optical Cable Maximum Data...
  • Page 43 3. Installation 3) Z-CASE Installation ◆ Power Cable Connection & Disconnection - (Connect) To connect the AC power cable, remove the lid and press the connector in an arrow square. - (Disconnect) To remove the AC power cable, turn the connector in the direction of the arrow. Connect Disconnect...
  • Page 44 3. Installation 3) Z-CASE Installation ◆ Cable Connection - QSFP optical module / cable is connected to Z-CARD in S-BOX. - Data cable is connected from Z-CASE to Cabinet. - Illuminance sensor is connected to a separate Ethernet port (multi-unsupported) Data Cable Z-Case Open...
  • Page 45 3. Installation 3) Z-CASE Installation ◆ Install FDF (Fiber Distribution Frame) inside the Z-CASE to shape the cable. (117x136 x30)
  • Page 46 3. Installation ※ When installing Z-CASE, it is recommended to install it in 3) Z-CASE Installation a place where direct sunlight can be avoided. ( the ambient temperature does not exceed 50 degrees like the cabinet installation guide ) ◆ S-BOX / Z-CASE / Cabinet Installation [Optical Cable] [CAT6 Ethernet Cable] [S-Box QSFP Connect]...

  • Page 47: Z-Card Setup

    3. Installation 4) Z-CARD Setup ◆ LED's status by Pitch and Function , SW801 LED Indicator LED Indicator Pitch Function (OP702 / OP704) (OP703 / OP705) Test Pattern OFF Test Pattern ON ① Auto ID Auto ID + Test Pattern ON ②...
  • Page 48 3. Installation 4) Z-CARD Setup ◆ LED's status by Model, SW702 1st 2nd 3rd LED Indicator Function [Flat] Don't care ① [10K nit] Don't care [Fascia] Don't care ② Forbidden Don't care [AIO] ① XHB-B 6x3 OP701 OP1000 [AIO] ② XHB-B 6x4 [AIO] ③...
  • Page 49 3. Installation 5) Light Sensor Installation ◆ Z-CARD ↔ Light Sensor Connection - Connect Lan Jack of Z-CARD and Lan Port of Light sensor by Lan Cable. - Light Sensor Accessory Kit Code : BN94-00040Z...
  • Page 50 3. Installation 5) Light Sensor Installation ◆ LED Screen Installation - Light Sensor should be installed on upper part of LED Screen. - Detailed location should be determined at the site according to the installation situation...
  • Page 51 3. Installation 6) Cable Connection ◆ Overview Data Power In Power Out BOTTOM Data Data...

  • Page 52: Cable Connection

    3. Installation 6) Cable Connection ◆ AC Power Connect & Disconnect - (Connect) To connect the AC power cable, remove the lid and press the connector in an arrow square. - (Disconnect) To remove the AC power cable, turn the connector in the direction of the arrow. ◆...

  • Page 53: Control Room Setting

    3. Installation 7) Control Room Setting ◆ Z-CARD Mixed Redundancy using one S-BOX...
  • Page 54 3. Installation 7) Control Room Setting ◆ Z-CARD Full Redundancy using different S-BOX...
  • Page 55 3. Installation 7) Control Room Setting ◆ In case of Multi S-BOX, Brightness value share - Share Brightness between S-BOXes. . Host BOX (Light Sensor connected) : Based on measurement of Light Sensor, calculate optimal Brightness. . Members (w/o Light Sensor connected) : Calibrate cabinet to Brightness received from Host...

  • Page 56: Screen System Configuration

    3. Installation 8) Screen System Configuration ◆ S-BOX (BXU), FHDx4 OPTICAL OUTPUT ◆ Z-CARD COVERS 1 ZONE(FHD) = 5 BLOCKS ◆1 BLOCK = 1920x128 RESOLUTION [Zone / Block / Module Resolution by pitch] Zone Block Module Pitch Size (m) Resolution Size (m) Resolution # of cabinet...

  • Page 57: Power Connection

    3. Installation 9) Power Connection ◆ Max Power Daisy Chain (XHB Fascia 2x3) XHB-F Model Code LHX10THF230 LHX10CSF230 # Cabinet No. of AC Loop out cabinets (110 V) Power Consumption / 480W 200W Cabinet # Cabinet No. of AC Loop out cabinets (220 V) Power Consumption /...

  • Page 58: Maintenance

    4. Maintenance 1) Buffer Materials ◆ Samsung provides Service materials Fascia 8,000nit Module for 2X3 2X2 Fascia 2,000nit Module for 2X3 2X2 VG-XHMB2TDA VG-XHMS2CDA MODULE LEFT, 1EA MODULE RIGHT, 1EA MODULE LEFT, 1EA MODULE RIGHT, 1EA SCREW-TAPTYPE M4 L10 SCREW-TAPTYPE M4 L10...
  • Page 59 4. Maintenance 1) Buffer Materials ◆ Module handle assembly Module for 2X3 2X2 VG-XHMB2TDA Torque : 16~18kgf*cm RIGHT Torque : 16~18kgf*cm LEFT...
  • Page 60 4. Maintenance 1) Buffer Materials ◆ Samsung provides Service materials VG-XHDB1TDF VG-XHDB1TDG SCREW-MACHINE: 6EA SCREW-MACHINE: 6EA MODULE 1EA MODULE 1EA (6001-002621) (6001-002621)

  • Page 61: Top Service

    4. Maintenance 2) Top Service ◆ Component Replacement – Cover-FRONT 0. Unlock the lock using the internal key of After opening the TOP, slide the FRONT up from the cabinet to separate the module and cabinet the Z-CARD ※ When repairing the cable, Up and down from the back of the CLOSE OPEN...
  • Page 62 4. Maintenance VG-XHTSSKIT 2) Top Service (Rear) ◆ Component Replacement – Module 0. Turn the module-specific wing nut (2EA) 90 degrees counterclockwise. (Use VG-XHTSKIT trench) 2x3 – 12EA 2x2 – 8EA 90º Clockwise Unlocking Locking...
  • Page 63 4. Maintenance 2) Top Service (Rear) ◆ Component Replacement – Module 0. Module drop prevention wire disassembly (1) Safety ring fastened during module (2) After the safety link is released (3) After the work is completed disassembly Release safety loop from module handle Re-engage the safety link.
  • Page 64 4. Maintenance 2) Top Service (Rear) ◆ Component Replacement – D-BOX 0. Remove Screw 18EA 1. Data BOX Disassemble & replace...
  • Page 65 4. Maintenance 2) Top Service (Rear) ◆ Component Replacement – PCB Board 1. After pooling 4-6 COVER-REAR screws, open COVER-REAR...
  • Page 66 4. Maintenance 2) Top Service (Rear) ◆ Component Replacement – Cover Rear 1. Loosen Screw 4-6 points 2. Loosen Top Hinge part 1point Screw 3. Open Cover-rear & Disassemble to upper direction #2 Phillips screw driver...
  • Page 67 4. Maintenance 2) Top Service ◆ COVER REAR screw point difference per cabinet 2x3 – 6EA 2x2 – 4EA...
  • Page 68 4. Maintenance 2) TOP Service ◆ Component Replacement : Z-CARD (Z-CASE) - After loosen Upper Cover fixing Screw 6 points Separate Cover by Pushing it up - Loosen Z-Card fixing Screw 7 Points - Detach Ethernet Cable 5 Points Power Cable OPEN...
  • Page 69 4. Maintenance 2) TOP Service ◆ Component Replacement : SMPS (Z-CASE) - After loosen Upper Cover fixing Screw 6 points Separate Cover by Pushing it up - Loosen SMPS fixing Screw Points (Firstly, Removing 2 Point in order to disassemble the Insulator(BN63-20908A)) - Detach AC Inlet Cable 1 Point and DC Power Cable 1 Point OPEN...
  • Page 70 4. Maintenance ※ Precautions ◆ Precautions for Data Cable Detachment - When removing the data cable, hold the connector part and remove it (do not hold the end and pull it) - The data cable is removed when pulled by applying force to the connector. - Be careful not to fall out due to cable jams and external forces during installation/maintenance.
  • Page 71 4. Maintenance ※ Customer purchase list (1) Optical Module Optical Module Optical Module / Spec Maximum Data Package Style Wavelength Reach Interface Fiber Type Transfer Rate QSPF + LR4 CWDM 40.00 Gbps (2) Fiber Distribution Frame - Maker : Justlink - Model Name : MINI-FDF-SC-4C (3) LSM Control PC Spec - For more than Win10 OS application and detailed specifications, contact the manufacturer's technical support representative...

  • Page 72: Lsm Configuration Guide

    LSM Configuration Guide...
  • Page 73 5. LSM Configuration Guide  Securing and Installing Control PC for LSM Control The control PC must be installed after the customer secures the PC above the specifications provided by the manufacturer. Control PC must be purchased and S-BOX must be controlled after installation as follows. Control PC should always be connected by S-BOX and LAN cable.
  • Page 74 Settings and Usage Description  S-BOX Connection (Panel Configuration) S-Box Initial Picture Setting • S-Box Default Quality Setting is optimized for XHB Cabinet and shipped to the factory. • The installed LED display model and optimized image quality setting are automatically set after installation. •...
  • Page 75 Settings and Usage Description  S-BOX Connection (Panel Configuration) S-Box Setting After entering the remote control Home button, select the device ID and PC connection cable.
  • Page 76 Settings and Usage Description  S-BOX Connection (Panel Configuration) S-Box Setting (Grouping) After entering the remote control Home button, select Video Wall -> Change to “On” [Caution] Before executing S-Box Grouping in LSM (LED Signage Manager), make sure to set the resolution of the input source equipment to the resolution that supports S-Box Grouping.

  • Page 77: Clone Product

    Settings and Usage Description  S-BOX Connection (Panel Configuration) Clone Product Export settings on the product to an external storage device. You can also import settings from an external storage device. This option is useful when assigning the same settings to several products. When a duplicate file is not found on the external storage device 1.
  • Page 78 Settings and Usage Description  S-BOX Connection (Panel Configuration) In the case of S-BOX Grouping, Picture menu setting • To use S-BOX Grouping, Picture mode should set to Calibration mode. • Menu→ Picture → Picture Mode → Calibration...
  • Page 79 Settings and Usage Description  S-BOX Connection (Panel Configuration) Modification method of PC output frequency • Click the right button of PC mouse  Select screen resolution  Click Advanced settings • Click Monitor Tap  Change screen playback frequency to 60Hz in Monitor settings tab...
  • Page 80 Settings and Usage Description S-box Grouping support frequency (1/2) Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Pixel Clock (MHz) Sync Polarity (H/V) HDMI 1~2 S-Box 그 룹 화 지 원 S-Box Grouping Support IBM/VE S A, 640 x 480 31 .469 59.94 21 .1 75 N / N...
  • Page 81 Settings and Usage Description S-box Grouping support frequency (2/2) Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Pixel Clock (MHz) Sync Polarity (H/V) HDMI 1~2 S-Box 그 룹 화 지 원 S-Box Grouping Support VE S A, 2560 x 1 440 88.787 59.951 241 .5...
  • Page 82 Settings and Usage Description  S-BOX Connection (Service Port) The service port is a monitoring-only terminal to check the operation status of the source that uses and plays OSD during the initial installation of the S-Box. The resolution of the corresponding PORT is FHD (1920*1080@60Hz). Screen blinking and breaking may occur when entering the source of UHD resolution in S-BOX, but this is a phenomenon in which the port output is fixed down scaling without a specific scaling algorithm and has nothing to do with the actual LED cabinet screen output.
  • Page 83 LSM(LED Signage Manager) • LSM: Windows Application Software for remotely adjusting the layout of LED cabinets • LSM download path: Samsung Display Solutions • (https://displaysolutions.samsung.com) Solutions> LED Signage Solution> LED Signage Manager ※ Partner login is required for program download.
  • Page 84 Settings and Usage Description LSM connection between components PC and S-BOX should be connected via Ethernet connection. The S-BOX is connected to the first LED cabinet by QSFP (optical cable) – LAN. LED cabinets are connected in a daisy chain method through the LAN port. SBOX QSFP Z-CARD...
  • Page 85 ※ Same as LSM download path Connect S-Box and PC in serial (UART, RS232) manner. Click Start > All Programs > Samsung > LED Signage Manager > Network Configuration to execute. Set the serial port and device ID. After completing the setting, click Open.
  • Page 86 Settings and Usage Description(IP setting by REMOTE CONTROL) ◎ IP setting by REMOTE CONTROL Choose 「Network status」 Menu IP SETTING > SETTING METHOD > MANUAL...
  • Page 87 Settings and Usage Description ◎ LSM Program Start When LSM is executed for the first time, a page that sets the password appears. To set the password, the user must enter the same password twice and click the Start button. If you don't want to use password, check Don't use password option.
  • Page 88 Settings and Usage Description ◎ To add connection information, you can enter Search or IP address directly. When you click the Search button, the IP address of the connectable S-BOX on the same network appears. If you know the IP address of S- BOX, you can also enter it directly.
  • Page 89 [★ Caution!] Fixed IP setting is recommended when setting up LED cabinet network. Settings and Usage Description If IP is changed when using DHCP, LSM connection may be disconnected. 192.168.10. the x band is used for internal communication of LED cabinet. Please use IP except for the band.
  • Page 90 Settings and Usage Description [★ Caution!] For internal communication between S-BOX and LED Cabinet, use ports 1515, 48484, 48485, and 58585. During firewall/security network use, the port must be enabled between S-BOX and LED. ◎ Dash Board Home : Shows the information, input source, cabinet configuration, and error device of the connected device.
  • Page 91 Settings and Usage Description ◎ 1. Connection Layout : Shows the location and layout of each LED cabinet. 2. View Mode : Select whether to show Layout information in Screen state or Diagnostics state. 3. Diagnosis Result(Diagnostics Status Mode) : Displays the Diagnosis status of each cabinet as a list.
  • Page 92 Settings and Usage Description ◎ Device setting function 1. Basic : . On/Off, Input/Source change, Screen Mute / Freeze, Menu Size 2. Picture . Picture Mode change, Brightness / Contrast / Sharpness, Color, Tint(G/R), Color Temp(K), Gamma, White Balance control 3.
  • Page 93 Settings and Usage Description ◎ Device setting function 6. Dimming . Off The brightness of the screen acts as a default value. . Manual The brightness of the screen changes according to the schedule specified by the user. Up to four schedules can be specified and at least one must be maintained. .
  • Page 94 Settings and Usage Description ◎ Device setting function 7. Cabinet Settings . LOD Recheck . Pixel RGB Data Reload / Request . Software Update . Module Information 8. Cabinet Calibration . Cabinet RGB CC Configuration . Module RGB CC Configuration...
  • Page 95 Settings and Usage Description ◎ Main Window-Connection Window - Sub Information View Monitor Window: MDC communication log and connection device information can be extracted as a verifiable file LED Signage Cabinet: IC information and power information of LED cabinet LED Signage Box: IP address, MAC address, ID range of LED cabinet, number of LED cabinets (full/connected/unconnected), serial number,...
  • Page 96 Settings and Usage Description ◎ LSM Program Setting Options Command Retry Count : Command Retry Count Error Status Error Status Interval (min.) : Error status check interval Temperature Alert : Warning Temperature (S-Box, Cabinet Group, Cabinet) Support Advanced Log Management : Log Data Manage Use Password : Password Manage Fault Device Alert : Inform Device error by Mail About Software...

  • Page 97: Diagnostic Function

    Settings and Usage Description ◎ Diagnostic function • Providing diagnostic items through Home > Summary • For diagnostic items recognized as problems, mark problem contents with ID in Home> Summary area • Diagnostic Item Type - Temperature [S-Box, Cabinet Group (Zone-Card), Cabinet (T-Con)] - Signal input status [S-Box, Cabinet Group (Zone-Card), Cabinet (T-Con)] - Module Power status [Cabinet (T-Con)] - Fan status [S-Box]...
  • Page 98 Settings and Usage Description ◎ Test Pattern • After selecting S-Box, click the “Test Pattern“ button on the right • S-Box output pattern can be used...

  • Page 99: Video Path

    Settings and Usage Description ◎ Video Path • Forced change of signal connection direction of connected cabinet • Forced change of signal connection direction of all cabinets in cabinet group through “Forward” or “Backward” button ※ This function is valid only when Redundancy Setting is done. •...
  • Page 100 Settings and Usage Description ◎ Redundancy Configuration > S-Box Redundancy • When connecting to LSM, set the path type for each purpose and try to connect. For the “Forward” purpose, enter the Cabinet Group IP address and the actual number of Cabinets, and check the “Assign IDs and Positions Automatically”...
  • Page 101 Settings and Usage Description ◎ Redundancy Configuration > S-Box Redundancy • When connecting to LSM, set the path type for each purpose and try to connect. If “Zone-Card” redundancy is used, the path type is set to “Hybrid”. • You can set “Forward” or “Reverse” per cabinet group. However, Group 1 and Group 4 are fixed with Forward and Reverse, respectively.
  • Page 102 Settings and Usage Description ◎ Software Update (S-Box) 1. Please prepare the update SW File. (Files selected when updating files marked in red) S- Box FPGA S- Box Main 2. After connecting LSM and SNOWCX4B, click the Software update e button under the S-Box Settings> System menu. 3.
  • Page 103 Settings and Usage Description ◎ Software Update (Cabinet) 1. Please prepare the update SW File. (Files selected when updating files marked in red) Z-card FPGA Z-card Main (AM3352) Cabinet(T-Con) FPGA 2. After connecting, click the Software update e button under the Cabinet Settings menu. 3.

  • Page 104: Usb Download

    ① Pontus-M Main Micom Software Upgrade • USB download Firmware upgrade downloaded from "www.samsung.com" website Connect the USB drive where the file is stored to the set. (Please be careful not to disconnect the power or USB drive during upgrade. ) 2.
  • Page 105 Settings and Usage Description Software Update - Update using USB Main SW Update Save the “SB-PTMWWC” folder to the USB root. Connect the USB. Click the “MENU” key on the remote control. Select the “Customer Support” menu. Select the “Update Software” menu. Select the “Update Now”...
  • Page 106 Settings and Usage Description Software Update - Update using USB Sub Micom Upgrade (Sub Micom can be upgraded in Factory Mode. It takes about 1-2 minutes. ) 1. “OSPMICOM_LXTV_SS.bin” file saves in USB root. 2. Connect the USB. 3. Enter Factory mode. 4.
  • Page 107 – THE END –...
