Summary of Contents for INVT EC Series

  • Page 2 EC series 4G expansion card Change history Change description Version Release date First release. V1.0 December 2021  Added safety precautions.  Added three function descriptions (antenna gain, power consumption and heat dissipation method) in section 1.2 Product specifications. ...

  • Page 3: Table Of Contents

    EC series 4G expansion card Contents Contents Safety precautions ........................1 1 Product overview........................2 1.1 Product features ......................2 1.2 Product specifications ....................2 1.3 Model instruction ......................3 1.4 Port instruction ......................4 1.5 Indicator instruction ...................... 4 2 Installation ..........................

  • Page 4: Safety Precautions

     The account and password are the authentication credentials of INVT industrial Internet platform and can be used for device management after login. You shall keep you account and password properly and take sufficient precautions to prevent others from stealing them.

  • Page 5: Product Overview

    Product overview 1 Product overview INVT EC series 4G expansion card is an IoT 4G wireless data terminal designed for wireless monitoring with the function of data uploading to the cloud by utilizing the mobile operator network. It is applicable to GD350 and its special machine series, GD270 series VFD and used as a plug-in communication expansion card.

  • Page 6: Model Instruction

    Without shell, protection level IP00 Installation Bolted method Heat dissipation Natural heat dissipation method 1.3 Model instruction Model name illustration of INVT EC series 4G extension card: EC–IC 5 02 - 2 1 G - CN ① ② ③ ④ ⑧ ⑤...

  • Page 7: Port Instruction

    EC series 4G expansion card Product overview Symbol Description Content IO: IO expansion card IC: IoT card Indicates the generation of a technical version by using odd numbers, for example, 1, 3, 5, and 7 ③ Technology version indicate the 1st, 2nd, 3rd and 4th generations of the technical version.
  • Page 8 EC series 4G expansion card Product overview Indicator identifier Description Run indicator Flash slowly (ON: 1s; OFF: 1s): System runs properly ON or OFF: System exceptions Handshake indicator Flash slowly (ON: 1s; OFF: 1s): Handshake between the expansion card and the VFD control board succeed...

  • Page 9: Installation

    Installation 2 Installation 2.1 Overview EC series 4G expansion cards must be installed properly to achieve the designed function. Generally, the installation must be done under the guidance of our certified and qualified engineers. Note: Do not conduct installation with the power on.

  • Page 10: Operation Guide

    EC series 4G expansion card Operation guide 3 Operation guide 3.1 Operation description Equipment required: Networked computer, EC series 4G expansion card, IoT SIM card. Procedure: Step 1 Insert the SIM card into the corresponding card sockets. Step 2 Record the device ID and 6-digit key from the label and add them to the IoT monitoring system.
  • Page 11 EC series 4G expansion card Operation guide 2. Enter the account and password to log in and enter the network configuration interface. Note: For account information, refer to section 3.3 Monitoring platform account.
  • Page 12 EC series 4G expansion card Operation guide 3. If it is your first time using the software, you need to add a device type. Click New > New device type in the lower left corner. If it is not your first time adding a device type, proceed to step 5.
  • Page 13 EC series 4G expansion card Operation guide 5. Click New > New device in the lower left corner. 6. Enter Adapter ID, Adapter key, Device name, select Device type, and click OK to complete the process. Note: Adapter ID is the S/N code of the IoT terminal, and Adapter key is the six-digit number under the QR code next to the S/N code.
  • Page 14 EC series 4G expansion card Operation guide 7. After adding the device, you need to add parameters for the first time. Click the device and then click New. 8. Enter Parameter name, select Communication type, select Parameter type, enter Parameter address (Modbus address of the register), fill in other information as needed, and click OK.
  • Page 15 EC series 4G expansion card Operation guide Communication type: Click to view, modify or create new settings. The default is 485 communication, with a slave address of 1, a baud rate of 19200, 8 data bits, 1 stop bit, and even parity.
  • Page 16 EC series 4G expansion card Operation guide 9. After creating the parameters, click Distribute. 10. Once successfully distributed, you can proceed with online monitoring. -13-...

  • Page 17: Web Monitoring Device

    EC series 4G expansion card Operation guide 3.2.2 Web monitoring device 1. Enter: iot.invt.com in the address bar of Google Browser and press Enter to visit the login page of the industrial IoT application platform. As shown in the following figure, enter the account number and password to complete the login.
  • Page 18 EC series 4G expansion card Operation guide 3. Enter the adapter code that has been added into the search box on the homepage, click the barcode to enter the monitoring page of the device and check the monitoring state of the device.

  • Page 19: Monitoring The Device Via App

    Play (for iOS system, you can search for INVT IOT in the APP Store). 2. Open the INVT Cloud APP, enter the account and password to log in. On the homepage, click the + icon in the upper-right corner, enter Adapter code, Secret key and Device name, select Device type, and click Submit to complete the device addition.

  • Page 20: Monitoring Platform Account

    3.3.1 Web registration Step 1 Enter: iot.invt.com in the address bar of Google Browser and press Enter to visit the login page of the industrial IoT application platform. Step 2 Click Registered.

  • Page 21: App Registration

    Step 1 Download and install the INVT Cloud APP on your mobile device. Note: You can download it by searching for INVT IOT in Tencent MyApp Store or Google Play (for iOS system, you can search for INVT IOT in the APP Store).

  • Page 22: Faqs

    SMS, and enter the invitation code. Invitation code: You can obtain it through the higher-level user account. If there is no higher-level one, you can fill in dbf20a (INVT administrator invitation code), review and check the User Privacy Agreement, click Register, and wait for review. You will receive a notification via SMS once approved.
  • Page 23 EC series 4G expansion card Operation guide ensuring good connection. Move the 4G antenna to a place with good signal. Ensure that the SIM card is activated and has remaining balance. Contact the manufacturer to check whether the device ID is registered.
  • Page 24 6 6 0 0 1 - 0 0 9 2 9...
