Astor AS56PCC Series User Manual

Intel core 6th /7th/8th generation i7/i5/i3/pentium/celeron, intel core 10th/11th generation i5/i3 high performance processor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AS56PCC
Series User Manual
PANEL PC
Intel
Core™ 6th /7th/8th generation i7/i5/i3/pentium/Celeron
®
Intel
Core™ 10
®
/11
generation i5/i3 high performance processor
th
th
page: 0 / 97

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AS56PCC Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Astor AS56PCC Series

  • Page 1 AS56PCC Series User Manual PANEL PC Intel Core™ 6th /7th/8th generation i7/i5/i3/pentium/Celeron ® Intel Core™ 10 generation i5/i3 high performance processor ® page: 0 / 97...

  • Page 2: Safety Instructions

    Safety instructions 1. Please read the manual and related manual mentioned in this user manual before installing, wiring, operating, checking this Panel PC. All the oprations should be based on the premise of full safety attention. 2. Please kindly keep this user manual for further reference. 3.
  • Page 3 Content: Chapter 1 Overview ....................6 1.1 Reference file ....................7 1.2 Product naming format ................... 7 1.3 Safety Introduction ..................7 Chapter 2 AS56BOX-01 Series ...................9 2.1 AS56BOX-01......................11 2.1.1 Product Features ..................11 2.1.2 Product Specifications ................12 2.1.2 Dimension ....................25 2.1.3 I/O Definition ..................31 Chapter 3 BIOS Setting ...................
  • Page 4 8.1.3 Disposing the Equipment ................94 8.1.4 Maintance and Cleaning Procaution ..............94 8.1.4.1Maintance and Clean ................94 8.1.4.2 Clean Tools ..................... 94 Chapter 5 FAQ ......................96 7.1 Technical Support and Service .................96 Page: 5 / 97...

  • Page 5: Chapter 1 Overview

    Chapter 1 Overview In this chapter, it offers the descriptions of products files, functions and specifications etc. Page: 6 / 97...

  • Page 6: Reference File

    1.1 Reference file Related file are shown as below table, please read before use the device. File Name File Aim File Content Descrption Please do read before User manual product’s function and relative setting 1.2 Product naming format This product sries contains two types, one is standard industrial computer type, which uses standard carry board interfaces.Customers can choose the corresponding CPU, memory and SSD according to heir repuirements.
  • Page 7 SIGN DESCRIPTION Warning： Indicates a potential situation which could result in death, serious injury or significant property damage if do not deal with properly. Danger：Indicate a urgent danger which could result in death, serious injury or significant property damageif do not deal with properly. Reminder：Indicates important information.
  • Page 8 Chapter 2 AS56PCC Series The product is a high-performance industrial computer for automation, machine vision and other industries, supporting Intel ® Core ™ 6, 7, 8 generation i3, i5, i7 CPU and Pentium CPU. The product adopts solid aluminum alloy profile structure, aluminum profile...
  • Page 9 2.1 AS56PCC 2.1.1 Product Features  Supports high-performance CPU  Intel® Core™ 6 i7 / i5 / i3 and Intel LGA 1151 pin Pentium /Celeron , TDP65W .  Intel® Core™ 10 / 11 i5 / i3 and Intel LGA 1200 pin ,limit to below 6C12T , TPD65W ...

  • Page 10: Product Specifications

    2.1.2 Product Specifications AS56PCC-10 Product Name AS56PCC-10 Intel® Core™ GEN6-9 Intel® Core™ gen 6th/7th/8th i7/i5/i3/Pentium/Celeron LGA1151 type CPU. Max.65W TDP Intel® Core™ gen 6th/7th/8th i7/i5/i3/Pentium/Celeron LGA1151 . Max.35W TDP (FANLESS) Intel® Core™ GEN10-11 Intel® Core™ gen 10 i5/i3 LGA1200 type CPU . Max.65W TDP Intel®...
  • Page 11 Operating 10G peak acceleration (11ms duration), follow IEC 60068-2-27 Shock CE/FCC Class B Front IP65 compliant Waterproof AS56PCC-12 Product Name AS56PCC-12 Intel® Core™ GEN6-9 Intel® Core™ gen 6th/7th/8th i7/i5/i3/Pentium/Celeron LGA1151 type CPU. Max.65W TDP Intel® Core™ gen 6th/7th/8th i7/i5/i3/Pentium/Celeron LGA1151 . Max.35W TDP (FANLESS) Intel®...
  • Page 12 Operating Temperature -0 ~ 50° Storage Temperature -20 ~ 60° Relative Humidity 5~95% (40°Non-condensing) Environment Vibration SSD applied: 1.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis Shock Operating 10G peak acceleration (11ms duration), follow IEC 60068-2-27 CE/FCC Class B Waterproof Front IP65 compliant AS56PCC-15...
  • Page 13 15" XGA TFT LCD Size 1024 x 768 Resolution 30000hrs MTBF (hours) 400cd/m2 Luminance 800:1 Contrast Ratio (L) 85 / (R) 85 / (T) 85 / (B) 85 Viewing Angle Capacitive touchscreen Touch Screen Type Touch Screen > 87% Transmittance Controller Interface -0 ~ 50°...
  • Page 14 Weight 4.7kg Embedded & VESA Mounting Installation Mechanical Dimensions (W x H x D) 405mm * 258mm * 74mm 387mm * 240mm Cut out size (W x H) Operating Windows 7, Windows8, System Windows10，Linux DC12~24V ±10%, support reverse polarity protection, overvoltage protection, overcurrent protection Input Voltage Power Consumption...
  • Page 15 Operating System Windows 7, Windows8, Windows10，Linux Input Voltage DC12~24V ±10%, support reverse polarity protection, overvoltage protection, overcurrent protection Power Consumption Idle Power Consumption LCD Size 17" SXGA TFT Resolution 1280 x 1024 MTBF (hours) 30000hrs Luminance 250cd/m2 Contrast Ratio 1000:1 Viewing Angle (L) 85 / (R) 85 / (T) 80 / (B) 80 Touch Screen Type...
  • Page 16 3 x Intel 1000Mbps RJ-45 Network 4 x USB3.0 + 2 x USB2.0 4 x RS-232 / RS-485 ,RS485 support automatic flow control Serial port 8DI Wet contact input(24V), 8DO OC gate output(24V 500mA) NPN I/O port 8DI Wet contact input(24V), 8DO Output (24V 500mA) PNP HDMI 1920x1080 60Hz Expansion slot...
  • Page 17 AS56PCC-19 Product Name AS56PCC-19 Intel® Core™ GEN6-9 Intel® Core™ gen 6th/7th/8th i7/i5/i3/Pentium/Celeron LGA1151 type CPU. Max.65W TDP Intel® Core™ gen 6th/7th/8th i7/i5/i3/Pentium/Celeron LGA1151 . Max.35W TDP (FANLESS) Intel® Core™ GEN10-11 System Intel® Core™ gen 10 i5/i3 LGA1200 type CPU . Max.65W TDP Intel®...
  • Page 18 -0 ~ 50° Operating Temperature -20 ~ 60° Storage Temperature Relative Humidity 5~95% (40°Non-condensing) Environment SSD applied: 1.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis Vibration Shock Operating 10G peak acceleration (11ms duration), follow IEC 60068-2-27 CE/FCC Class B Front IP65 compliant Waterproof AS56PCC-22...
  • Page 19 Capacitive touch screen Touch Screen Type Touch Screen > 87% Transmittance Controller Interface -0 ~ 50° Operating Temperature -20 ~ 60° Storage Temperature 5~95% (40°Non-condensing) Relative Humidity SSD applied: 1.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis Vibration Environment Operating 10G peak acceleration (11ms duration), follow IEC 60068-2-27...
  • Page 20 2.1.2 Dimension AS56PCC series, the same display size of the machine, the same dimensions and use common structural parts AS56PCC-10 Dimension :298.5mm * 238.5mm * 74mm Cut out :221.5mm * 281.5mm Figure 2.1- 1. AS56PCC-10 Dimension AS56PCC-12 Dimension:328mm * 239mm * 74mm Cut out : 311mm * 242mm Figure 2.1- 2.
  • Page 21 AS56PCC-15 Dimension: 371mm * 295mm * 74mm Cut out : 354mm * 278mm Figure 2.1- 3. AS56PCC-15 Dimension AS56PCC-16 Dimension: 405mm * 258mm * 75mm Cut out : 387mm * 240mm Figure 2.1- 4. AS56PCC_16 Dimension Page: 27 / 97...
  • Page 22 AS56PCC-17 Dimension:428mm * 342mm * 74mm Cut out : 411mm * 325mm Figure 2.1- 5. AS56PCC-17 Dimension AS56PCC-18 Dimension:480mm * 304mm * 74mm Cut out : 463mm * 287mm Figure 2.1- 6. AS56PCC-18 Dimension Page: 28 / 97...
  • Page 23 AS56PCC-19 Dimension:460mm * 369mm * 74mm Cut out : 442mm * 351mm Figure 2.1- 7. AS56PCC-19 Dimension AS56PCC-22 Dimension:550mm * 342mm * 74mm Cut out : 533mm * 325mm Figure 2.1- 8. AS56PCC-22 Dimension Page: 30 / 97...
  • Page 24 2.1.3 I/O Definition Figure 2.1-9. AS56PCC I/O Definition Page: 31 / 97...
  • Page 25 2.1.3.1 PWR LED/HDD LED There are 2 LEDs on the front panel to indicate power status and HDD status. Figure 2.1- 10. AS56PCC LEDs LED NAME STATUS DESCRIPTION Without power PWR LED On (green) Power on HDD LED Blink (orange) It indicates the HDD is being accessed.

  • Page 26: Power Button

    2.1.3.2 Power Button There is a power button on the front panel which can be used to power on/ off the PANEL PC. Figure 2.1- 11. AS56PCC Power button Page: 33 / 97...
  • Page 27 2.1.3.3 DC IN There are two 2 pin power input interfaces provided on the front panel which ensures reliable power connection. These power input interfaces support DC 12V-24V. Paying attention to the positive and negative marks before connecting any power input interfaces to the PANEL PC.
  • Page 28 2.1.3.4 LAN PORTS ： LAN1, LAN2 , LAN3 There are three gigabit Ethernets ports on the carry board, which are LAN1, LAN2 and LAN3. Figure 2.1- 13 AS56PCC Gigabit Ethernet Ports TYPE Parameters Network Type 1000BASE-T/100BASE-TX/10BASE-T Transmission Speed 1000M/100M/10M bps Maximum Cable 100m/segment Distance...
  • Page 29 2.1.3.5 USB The front panel of AS56PCC provides four separate 4*USB3.0 ports Compatible with USB2.0，additional 2*USB2.0 ports. 2.1.3.5.1 USB3.0/2.0 The carry board has four USB3.0 TYPE-A type. Figure 2.1- 14. AS56PCC USB USB3.0 Connector Pin Definiton： Pin No. Signal USB_VCC DATA- DATA+ USB_GND...
  • Page 30 2.1.3.6 Serial Ports: COM1, COM2,COM3, COM4 AS56PCC provides 4 serial ports which are COM1—COM4. They all use standard DB9 male connector terminals supporting RS232 or RS485 communication protocol( can be selected by the switch at the bottom). Figure 2.1- 15. AS56PCC Serial Ports Setting The serial ports signal definition of DB9 male terminal is shown as below: Signal Name Pin No.

  • Page 31: Display Interface

    2.1.3.7 Display Interface AS56PCC provides standard HDMI video interface. Figure 2.1- 16. AS56PCC Video Interface The device also has HDMI TYPE A high definition multimedia video display interface. The terminal signal is defined as below: HDMI-A Terminal Pin No. Signal Name Pin No.
  • Page 32 2.1.3.8 DIO - NPN Figure 2.1- 17. AS56PCC DIO DIO signal definition is shown as below: Pin No. Signal Name Signal Name PCOM DOGND DI-24V DIGND DICOM 2.1.3.8.1 DI 8-channel DI is provided on the expansion board. Users can choose DI wet and dry contact.
  • Page 33  During dry contact，use + 24V provided by the device: A, Connecting terminal pin11 connects to pin13 B, DIGND/DI0-7 short-circuit input signal Notice：When +24V is provided internally, a circuit has been formed internally on the motherboard without additional access to GND signal. 2.1.3.8.2 DO 8-channel DO is provided on the expansion board.
  • Page 34 2.1.18. AS56PCC DIO DIO signal definition is shown as below: Pin No. Signal Name Pin No. Signal Name DO-24V DOGND DICOM 2.1.3.9.1 DI 8-channel DI is provided on the expansion board. Users can choose DI wet and dry contact. The wiring must comply with the wiring diagram. ...
  • Page 35 2.1.3.9.2 DO PNP Provides eight DO channels with PNP output and single-channel overcurrent capability of 1A. The DO24V signal connects to +24v, and the DO GND signal connects to 0V. Through software control switch DOGND/DO0... 7, the output has 24V voltage Electrical wiring diagram Digital Output Output...
  • Page 36  Click “start” to test after opening the program. 1. If the DI has input signals, the LED of the corresponding channel will be green. 2. Mannually set DO as output  After test, click” stop” to exit. 2.1.3.10.2 IO API Open a subdirectory file on system disk "C: NODKA”...
  • Page 37  Open“NODKA”file，all the files will be shown as below：  IO API user manual is in the file “ Manual”, shown as below picture:  Presents an example of a function application under the folder "Sample" as shown below picture: Page: 44 / 97...
  • Page 38 NOTICE: The corresponding files for IO can be found in “NODKA->NKDIO_SDK”. If you have any problems, please contact technical personnel. Page: 45 / 97...

  • Page 39: Chapter 3 Bios Setting

    Chapter 3 BIOS Setting Page: 46 / 97...
  • Page 40 3.1 Introduction of this chapter This section describes how to set up your system using AMI's BIOS configurator. Correct setting of BIOS parameters can make the system work stably and reliably, and also improve the overall performance of the system. Improper or even incorrect SETTING of BIOS parameters will greatly reduce the system performance, making the system unstable or even unable to work properly.
  • Page 41 3.3 BIOS method In general, use the arrow keys on the keyboard to select the Settings, <Enter> to enter the settings, + and - to switch settings, <F1> to get help information, and <Esc> to exit the settings. See the table below. Keys Function Description <↑>...
  • Page 42 3.4 BIOS Setting Items ：Since BIOS programs are updated from time to time, the following BIOS setup interface and description are for reference only. BIOS Main Once enter BIOS to set the system, Mian interface will show up. Figure 3.4- 1. AS56PCC BIOS-Main The menu bar which is anchored to the top of the BIOS screen has the following main items: ...
  • Page 43  Boot - Changes the system boot configuration.  Save & Exit - Selects exit options and loads default settings. Page: 50 / 97...
  • Page 44 3.4.1 Main Mian is used to confirm basic system configuration information.  Items Items Content Description Project Version xxxxx x.xx x64 BIOS virson Build Date and Time xx/xx/xxxx xx:xx:xx BIOS create time  Settable Items Items Content Description System Language [English] Set BIOS language, the default is English.
  • Page 45 3.4.3 Advanced In this menu, you can set detailed system functions as below: Figure 3.4- ２ AS56PCC BIOS-Advanced  CPU Configuration The main function of this item is to display CPU information and configuration items.  ACPI Settings This is the setting item related to Advanced Configuration and Power Management Interface (ACPI) ...
  • Page 46  Wake up settings This item is mainly to set sleep or wake up function.  Watch Dog Configuration This item is for watch dog setting.  Super IO Configuration This item is for IO setting.  Hardware Monitor The primary function of this item is to display hardware monitoring parameters such as CPU temperature ...

  • Page 47: Cpu Configuration

    3.4.4 CPU Configuration On this screen, you can view CPU configuration information and configure the CPU. Figure 3.4- ３ AS56PCC BIOS-CPU Configuration  CPU Configuration: Items Contents Description The hardware prefetch option indicates that the CPU has the hardware prefetch function.
  • Page 48 usage to reduce power consumption and heat. The state must be Disabled. The CPU is in standby state. The clock and voltage can be adjusted according to C states Disabled / Enabled the state, or the CPU can be turned off completely.

  • Page 49: Acpi Settings

    3.4.5 ACPI Settings On this screen, you can set ACPI (Advanced Configuration and Power Management interface) parameters. Figure 3.4- ４ AS56PCC ACPI Settings  ACPI Settings: Items Contents Description Whether to allow ACPI to be configured Enable ACPI Auto Disabled / Enabled automatically.

  • Page 50: Sata Configuration

    3.4.6 SATA Configuration Configure SATA controllers on this screen. Figure 3.4-5. AS56PCC BIOS SATA Configuration  SATA Configuration: Items Contents Description Whether to enable SATA controller. If you change this parameter, you may SATA Controller(s) Disabled / Enabled need to reinstall the system. Do not change this parameter.

  • Page 51: Display Configuration

    3.4.7 Display Configuration On this screen, you can set the parameters related to the integrated graphics card. Figure 3.4- 6. AS56PCC BIOS-Display Configuration  Display Configuration: Items Contents Description Indicates which device connected to the integrated Primary IGFX graphics card is displayed VBIOS Default / DVI / HDMI / VGA Boot Display from when starting POST...
  • Page 52 when the system starts up. If the memory is insufficient, system allocates memory again. The default is 32 MB The default value is 256 MB. DVMT Total Gfx Do not change the total 256M/128M/MAX capacity allocated dynamic video memory. Page: 59 / 97...

  • Page 53: Ac Power Loss

    3.4.8 AC Power Loss In this interface, you can set the power-on self-start. Figure 3.4- ７. AS56PCC BIOS-AC Power Loss Items Contents Description Indicates the power status of mainboard after switched on again. – Power off ： No matter what the state of the last power failure is, the motherboard power supply after...
  • Page 54 Do not change this item. ME State Enabled / Disabled ME Unconfig on RTC Enabled / Disabled Do not change this item. Clear The way to shut down a computer when click "Shut down computer" or run the shutdown command in the system. Soft-off by PWR-BTTN Delay 4 sec / Instant-off default mode is instant-off.

  • Page 55: Wake Up Settings

    3.4.9 Wake up settings On this screen, you can set the wake up mode of the system in sleep mode Figure 3.4- ８ AS56BOX-22/32 BIOS-Wake up Settings  Wake up Settings: Items Contents Description Wake system form s5 Enabled / Disabled Don’t change this item.

  • Page 56: Watch Dog Configuration

    3.4.10 Watch Dog Configuration On this interface, you can enable the watch dog timer and set its parameters. Figure 3.4- ９. AS56PCC BIOS-Watch Dog Settings Items Contents Description Watch Dog Control Enabled / Disabled The watch dog function is on and off. The unit of set point of watchdog Watch Dog Degree Second / Minute...

  • Page 57: Super Io Configuration

    3.4.11 Super IO Configuration On the Super IO screen, you can configure the Serial Port X and Parallel Port. Figure 3.4- 10.AS56PCC BIOS-Super IO Configuration Page: 64 / 97...
  • Page 58 3.4.12 Serial Port x Configuration This interface is mainly used to set the interrupt and IO address of the serial port, including Auto and IO and interrupt address Figure 3.4- 11. AS56PCC BIOS-Serial Port Configuration  Serial Port x Configuration: Items Contents Description...

  • Page 59: Hardware Monitor

    3.4.13 Hardware Monitor This interface is used for hardware check. Figure 3.4- 12. AS56PCC BIOS-Hardware Monitor Page: 66 / 97...

  • Page 60: Usb Configuration

    3.4.14 USB Configuration This interface is used to configure USB controller connectors. Figure 3.4- 13. AS56PCC BIOS-USB Configuration  USB Configuration: Items Contents Description Configure whether USB keyboards and similar devices can be used Legacy USB Support Enabled / Disabled / Auto with older operating systems (such as MS-DOS).

  • Page 61: Csm Configuration

    3.4.15 CSM Configuration This interface is designed to work with devices that only work in Legacy mode and operating systems that do not or do not fully support UEFI. CSM enables UEFI and NON-UEFI booting. To start a traditional MBR device, enable CSM. If CSM is disabled, UEFI starts and supports secure startup.
  • Page 62 Postponed: execute the trap during legacy boot. UEFI and Legacy / This option controls Legacy/UEFI Boot option filter Legacy only / UEFI ROMs priority only Do not launch / UEFI / Controls the execution of UEFI and Onboard Lan Pxe Rom Legacy PXE OpROM Legacy Launch Storage OpRom...
  • Page 63 3.4.16 Chipset This interface is used to display chipset information or set functions of the chipset. Figure 3.4-15. AS56PCC BIOS-Chipset View or set the following functions under this interface:  System Agent(SA) Configuration  Supporting information for system  PCH-IO Configuration ...

  • Page 64: System Agent Configuration

    3.4.17 System Agent Configuration Display the current auxiliary configuration items. Figure 3.4- 16. AS56PCC BIOS-System Agent Configuration Page: 71 / 97...
  • Page 65 3.4.18 Memory Configuration Display the current memory channel configartion information. Figure 3.4- 17. AS56PCC BIOS-Memory Configuration Page: 72 / 97...

  • Page 66: Pch-Io Configuration

    3.4.19 PCH-IO Configuration This interface is used to configurate PCI Express、LAN、USB and HD Audio device connectors on carry board. Figure 3.4- 18 AS56PCC BIOS-PCH-IO Configuration Mainly contains the sub-menus as below:  PCI Express Configuration  LAN Configuration  USB Configuration ...
  • Page 67 3.4.20 PCI Express Configuration This interface configures the onboard PCI Express bus. Do not change the Settings on this interface! Figure 3.4- 19 AS56PCC BIOS-PCI Express Configuration Page: 74 / 97...
  • Page 68 This interface is used to configurate LAN on carry board. Figure 3.4- 20 AS56PCC BIOS-LAN Configuration Items Contents Descripton Onboard LAN 1 controller Enabled / Disabled Enable or disable LAN 1 Onboard LAN 2 controller Enabled / Disabled Enable or disable LAN 2 Do not launch / UEFI / Onboard Lan Pxe Rom Don’t change this setting...
  • Page 69 3.4.21 USB Configuration This interface is used to configurate carry board USB Figure 3.4- 21. AS56PCC BIOS-USB Configuration Items Contents Description Disable XHCI compatibility XHCI Disable Compliance FALSE / TRUE mode. Mode Don’t change. xDCI Support Enabled / Disabled Don’t change this setting. Port Disable Enabled / Disabled...
  • Page 70 3.4.22 Security This interface is used to set keys related to system security protection. Figure 3.4- 22. AS56PCC BIOS-Security  Administrator Password   User Password Once the password is set, you need to remember the password, otherwise it will lead to no access to the system because there is no authority! Additional maintenance costs may be incurred.

  • Page 71: Boot Configuration

    3.4.23 Boot This interface is used to set parameters related to BIOS startup and device loading sequence. Figure 3.4- 23. AS56PCC BIOS-Boot  Boot Configuration: Items Contents Description When start the system, the Setup Prompt Timeout waiting time for BIOS setting ( second) .
  • Page 72 3.4.24 Save & Exit This menu is used to save configuration items, load default configuration parameters, and exit BIOS Settings. Figure 3.4- 24. AS56PCC BIOS-Save&Exit  Save Changes and Reset  Discard Changes and Reset  Restore Defaults  Boot Override Select the appropriate system storage media here when the system needs to be temporarily loaded from another connected system storage medium.

  • Page 73: Chapter 4 System

    Chapter 4 System Installation This chapter mainly introduce the system hardware installation and related drive software installation. Page: 80 / 97...

  • Page 74: Hardware Installation

    4.1 Hardware Installation 4.1.1 SSD and Wifi module installation In the AS56PCC provides mSATA and M.2 storage ports To add or replace a hard disk, follow the steps below. The maximum tightening torque for the retaining clips is 1 Nm. Step1.
  • Page 75 4.1.2 miniPCIE expension card installation In the AS56PCC provides miniPCIe expansion interfaces add or replace an expansion card, follow these steps. The maximum tightening torque for the retaining clips is 1 Nm Step1. Remove screws ①，②，③ and ④;  Step2. Install SSD card in the SSD hard disk slot ⑤ ⑦ ...

  • Page 76: Fan Installation

    4.1.3 Fan installation In the AS56PCC high-performance product series, fans are needed to assist in heat dissipation. In order to ensure the complete sealing of the internal circuit board, the fan is embedded in the aluminum profile. Steps for removing fan is shown as below. the screws can not be lost, need to be used Again.

  • Page 77: Vesa Installation

    4.1.4 VESA installation AS56PCC series products support VESA installation. The mounting plate is fixed to the shell of the product with 4 screws. When installing or removing, just remove 4 screws. VESA brackets are optional and need to be purchased separately.Select a support based on the distance between mounting holes 75 * 75/100 *100.

  • Page 78: Embedded Installation

    4.1.5 Embedded installation AS56PCC series products support embedded installation. The number of retaining clips depends on the panel. The thickness of the wall or cabinet plate must be between 1 mm and 5 mm The maximum tightening torque for the retaining clips is 1 Nm.
  • Page 79 red circles). The number of retaining clips may vary depending on the panel. For the exact number of retaining clips  The tightening torque should be max. 1 Nm to provide an optimal seal. 4.1.6 DC power Connector In order to ensure a reliable power connection, the front panel of the device provides a power input interface with a 4-pin distance of 5.08mm.
  • Page 80 The signal of the power input connector is defined as follows: Pin No. Define NOTE: The AS56PCC series provides 2-channel power input, two channels of independent input, and cannot be used as a DC output interface. +24 VDC power supply table: Electrical characteristics Nominal voltage 12-24V±10%...
  • Page 81 4.1.7 Remote power button Connector The AS56PCC provides a remote switching interface, which can be switched on and off at a distance of up to 5M using a wire connection. The signal of the power input connector is defined as follows: Pin No.
  • Page 82 2.5KV Pitch（mm） 3.81mm torsion（N-m） screws strip length 8-9mm wire diameter（AWG/mm ²） 0.2-1.5 4.1.9 Drive installation Please download the drivers from https://www.astor.com.pl/wsparcie.html. Select the correct diver corresponding with the model of your product. Page: 89 / 97...

  • Page 83: Chapter 5 Optional Accessory List

    Chapter 5 Optional Accessory List Page: 90 / 97...
  • Page 84 5.1 Optional Accessory List Name Type Description Celeron：G3930 ..Pentium ：G4400、G4560、G4600 ..Support 6th/7th/8th/9th generation Intel® Core™ i7/i5/i3 LGA 1151 socket type processors Intel® Core™ i3-6100, Dual Core, 3.7GHz, 3MB Cache Intel® Core™ i3-7100, Dual Core, 3.9GHz, 3MB Cache Intel®...

  • Page 85: Chapter 6 Safety Precautions And Maintenance

    Chapter 6 Safety Precautions and Maintenance ： The precautions outlined in this chapter should be strictly followed. Failure to follow such precautions may result in serious damage to the PANEL PC. Page: 92 / 97...

  • Page 86: Safety Precaution

    6.1 Safety precaution Follow the safety precautions outlined as below. 6.1.1 General Safety Precaution Please read the following safety precautions carefully. Make sure you always follow the precautions. Always follow the Anti-static precautions (A.2) when the product is opened.  Make sure the power is turned off and the power cord is disconnected when ...
  • Page 87 When configuring or working with an electrical component, please put the component on  an anti-static pad in order to reduce the possibility of ESD damage. Only touch the edges of the electrical component, when handling it.  8.1.3 Disposing the Equipment ：If the battery of the wrong type is replaced, there may be explosion risk.
  • Page 88 1. Cloth – Although paper towels or tissues can be used, a soft, clean piece of cloth is recommended. 2. Water or rubbing alcohol – A cloth moistened with water or rubbing alcohol should be used. 3. Using solvents – The use of solvents is not recommended as they may damage the plastic parts.
  • Page 89 Chapter 7 FAQ 7.1 Technical Support and Service Please visit the official website of ASTOR https://www.astor.com.pl/wsparcie.html to download the documentation and related driver software, or directly contact the local distributor to provide support and service. Page: 96 / 97...
