Ameriwood HOME 7853341COM Manual

Ameriwood HOME 7853341COM Manual

Desk side cabinet
Hide thumbs

Advertisement

Available languages

Available languages

Table of Contents

7853341COM
Desk Side Cabinet
Date of Purchase ___ / ___ / ___
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-800-489-3351 (toll free)
Visit: www.ameriwoodhome.com
WARNING
- Unit can tip over causing severe injury or death.
- Anchor unit to stud in wall (if instructed to).
- Do Not allow children to climb on unit.
- Put heavy items on lower shelves or drawers.
Easy
Assembly Difficulty Meter
Follow Ameriwood Home
B347853341COM1
Tough

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7853341COM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ameriwood HOME 7853341COM

Summary of Contents for Ameriwood HOME 7853341COM

  • Page 1 Easy Tough Assembly Difficulty Meter WARNING Follow Ameriwood Home - Unit can tip over causing severe injury or death. - Anchor unit to stud in wall (if instructed to). - Do Not allow children to climb on unit. - Put heavy items on lower shelves or drawers.

  • Page 2: Helpful Hints

    Contact Us! Do NOT return this product! Contact our friendly customer service team first for help. Assembly Tips Call us! 1-800-489-3351 Tube Visit ameriwoodhome.com to view the limited warranty valid in the U.S. and Canada. Helpful Hints PEOPLE NEEDED FOR ASSEMBLY: 1-2 - Open your item in the area you plan to keep it to avoid excessive heavy lifting.

  • Page 3: Before You Start

    Before You Start Read through each step carefully and follow the proper order Separate and count all your parts and hardware Parts are labeled on the surface or edge of the part Give yourself enough room for the assembly process Have the following tools: #2 Phillips Head Screwdriver and Hammer Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight.
  • Page 4 Before You Start Please Note: You may need to lightly tap the wood dowels into the holes during your assembly process. ameriwoodhome.com...

  • Page 5: Board Identification

    Board Identification Not actual size Adjustable Shelf 37853341030 37853341040 Upper Back Panel (x2) 37853000060 Fixed Shelf 37853341050 Left Panel Right Panel 37853341011 37853341021 Back Rail Valance (x2) (x2) (x2) Stringer 37853341081 37853341090 Door Panel Door Molding 37853000070 37853341100 37853341110 ameriwoodhome.com...
  • Page 6 Board Identification Not actual size Drawer Front Drawer Front Molding Drawer False Front 37853341120 37853341130 39991070078015F BACK SIDE SIDE Drawer Side Left Drawer Side Right Drawer Back 39991070340430L 39991070340430R 39991070078015B BACK Drawer Bottom Back Panel 39991324079120D K785334100 ameriwoodhome.com...
  • Page 7 Board Identification Not actual size SIDE BACK SIDE ameriwoodhome.com...

  • Page 8: Part List

    Note: Your unit may contain extra hardware. Part List Actual Size (x28) (x28) (x14) (x8) (x12) (x3) #A22620 #A22610 #A21670 #A23025 #A12810 #A22770 cam lock cam bolt wood dowel confirmat screw #8 x 1" screw quicklock (x16) (x10) (x4) (x4) #A12120 #A54710 #A13950...
  • Page 9 Note: Your unit may contain extra hardware. Part List Actual Size (x4) (x2) #A65685 #A65690 hinge plate glissando soft close Not Actual Size (x4) (x1) #A65680 #A56100 euro hinge slide ameriwoodhome.com...
  • Page 10 Note: Your unit may contain extra hardware. Part List Not Actual Size Your unit comes with four (2) drawer slides. For each slide, extend the slide as shown and press the release lever to remove the inner slide. Set the inner slide aside for later. For Step 1 and 2, you will be attaching the slide to the panels at the rear of the slide.
  • Page 11 STEP 1 (x14) (x3) (x1) ameriwoodhome.com...
  • Page 12 STEP 2 (x14) (x3) (x1) ameriwoodhome.com...
  • Page 13 STEP 3 Quick Assembly Proper orientation of CAM LOCK (x12) (x6) (x3) ameriwoodhome.com...
  • Page 14 STEP 4 Turn clockwise to lock in place. unfinished side ameriwoodhome.com...
  • Page 15 STEP 5 Quick Assembly Proper orientation of CAM LOCK (x12) (x6) ameriwoodhome.com...
  • Page 16 STEP 6 finished edge finished edge ameriwoodhome.com...
  • Page 17 STEP 7 ameriwoodhome.com...
  • Page 18 STEP 8 ameriwoodhome.com...
  • Page 19 STEP 9 Place your unit on its front. Slide back Panel into the grooves in the Left & Right Panels (A & B). BACK unfinished side Line up holes in bottom of Back Panel with the holes in the Back Rail (H) ameriwoodhome.com...
  • Page 20 STEP 10 (x4) (x4) BACK ameriwoodhome.com...
  • Page 21 STEP 11 (x10) (x2) (x2) Slide the Wedges (10) into the groove against the back Panel, and secure with screw. BACK Tap in T-Nut (14) with a hammer. Screw in Glides (13) all the way. ameriwoodhome.com...
  • Page 22 STEP The next steps are to assemble your unit to the wall Assembled unit MUST be square on the height, width, and depth to function properly Assembled unit MUST be placed flat against the wall Assembled unit MUST be screwed into wall studs at the top and bottom for safety You need to locate at least 1 stud, but 2 is better DO NOT use wall anchors to fasten your unit to the wall...
  • Page 23 STEP 12 Place your unit FLUSH against the wall There are notches provided at the back of your unit. These notches are to fit around the baseboard on your wall. If your baseboard is higher or thicker than the notches provided on the unit, you will need to remove the baseboard, cut it down to fit on both sides of your...
  • Page 24 STEP 13 Assembled unit MUST be square on the height, width, and depth to function properly A ladder will be required. Do not lean against the top of the unit, it may cause sagging. If required, unscrew the Glides counter-clockwise as necessary in all 4 corners until your unit is level in all directions.
  • Page 25 STEP 14 Locate the studs in the wall using a stud finder. Using a pencil, mark the stud locations at the top of the Upper Back Panel (F) and on the Stringer (G). Wall Studs You need to locate 2 studs (2 marks at the top &...
  • Page 26 STEP 15 (x4) First, make sure that your unit is still level in all directions. Drill 1/8" (3mm) pilot holes through the Upper Back Panel (F) and through the Stringer (G) at the the stud locator marks. Fasten the unit to the studs in the wall with Screws (7).
  • Page 27 STEP 16 (x4) SIDE SIDE ameriwoodhome.com...
  • Page 28 STEP 17 (x4) BACK SIDE SIDE ameriwoodhome.com...
  • Page 29 STEP 18 (x6) drawer front molding (M) goes on first ameriwoodhome.com...
  • Page 30 STEP 19 (x2) (x6) SIDE SIDE Inner Slide Use these holes Flat edge against Drawer Front ameriwoodhome.com...
  • Page 31 STEP 20 Install drawers by engaging the inner slides (attached to the Drawer Sides) with the outer slides (attached to the Left and Right Panel). Push in until the plastic lever snaps into the outer slide. Outer Slide Note: To adjust Drawer Front, loosen screws (5), make needed adjustments and retighten.
  • Page 32 STEP 21 (x4) ameriwoodhome.com...
  • Page 33 STEP 22 (x6) (x4) (x8) (x4) ameriwoodhome.com...
  • Page 34 STEP 23 (x4) Arrow faces front of unit. ameriwoodhome.com...
  • Page 35 STEP 24 hook Eccentric adjustment screw. Shifts the whole hinge up and down. Adjust the gaps between the door and the left and right panels (side to side) Adjust the gaps between the face of the door and the front edge of the left and right panels when in the closed position.
  • Page 36 STEP 25 hook Eccentric adjustment screw. Shifts the whole hinge up and down. Adjust the gaps between the door and the left and right panels (side to side) Adjust the gaps between the face of the door and the front edge of the left and right panels when in the closed position.
  • Page 37 STEP 26 This step is optional... Place Glissando Soft Close (17) on the lower hinge of each door (J). ameriwoodhome.com...
  • Page 38 Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. 10 lbs (4.54 kg) Adjustable Shelf 30 lbs (13.63 kg) Fixed Shelf 40 lbs (18.18 kg) Vanity / Desk Shelf 40 lbs (18.18 kg) Drawers...
  • Page 39 Register your product to receive the following: * New trend details - sneak peek on what's new * Surveys - have a voice within our community * Exclusive deals and discount codes * Quick and easy replacement part service To register your product, visit ameriwoodhome.com Visit your local retailer's website, rate your purchased product and leave us some feedback! ameriwoodhome.com...
  • Page 40 Espa ol Cubierta Delantera Este libro de instrucciones contiene informaci n IMPORTANTE de seguridad. Por favor lea y mant ngalo para referencia en el futuro. No Regrese este producto! Comuniquese con nuestro amistoso equipo de servicio al cliente para obtener ayuda.
  • Page 41 Espa ol P gina 5 - Identificaci n de las tablas P gina 8 - Lista de piezas No es tama o real Tama o real Panel izquierdo (A) Cerrojo de leva (1) Panel derecho (B) Tornillo de leva (2) Parte superior (C) Durmiente de madera (3) Estante ajustable (D)
  • Page 42 Espa ol P gina 15 - Orientaci n adecuada del cerrojo de leva P gina 16 - Borde terminado P gina 19 - Coloca tu unidad en su parte frontal * Desliza el panel trasero en las ranuras de los paneles izquierdo y derecho (A & B) * Lado no terminado * Alinea los agujeros en la parte inferior del panel trasero con los agujeros en el riel trasero (H) P gina 21...
  • Page 43 Espa ol P gina 26 - Se requerir una escalera. NO te apoyes en la parte superior de la unidad, puede causar que se deforme. * Primero, aseg rate de que tu unidad est a n nivelada en todas las direcciones. * Taladra agujeros gu a de 1/8 (3mm) a trav s del panel trasero superior (F) y a trav s del larguero (G) en las marcas del localizador de montantes.
  • Page 44 Espa ol P gina 39 Registre su producto para recibir lo siguiente: * Detalles de nuevas tendencias - Vistazo a lo nuevo * Encuestas - alec su voz entre su comunidad * C digos de ofertas y descuentos exclusivos * F cil y r pido servicio de partes de remplace Para registrar su producto, visite ameriwoodhome.com Clasificasi n de 5 estrellas Visite el sitio web de su tienda local, califique su comprado...
  • Page 45 Fran ais Couverture Avant CE LIVRET D'INSTRUCTION CONTIENT DES INFORMATIONS IMPORTANTES SUR LA S CURIT . VEUILLEZ LIRE ET GARDER POUR UNE R F RENCE FUTURE Ne retournez pas ce produit! Contactez notre quipe de service la client le amicale d'abord pour obtenir de l'aide.
  • Page 46 Fran ais Page 5 - Liste des pi ces Page 8 - Liste des pi ces Taille non r elle Taille r elle Panneau gauche (A) Serrure came (1) Panneau droit (B) Boulon came (2) Panneau sup rieur (C) Cheville en bois (3) tag re r glable (D) Vis de contr le (4) tag re fixe (E)
  • Page 47 Fran ais Page 15 - Orientation correcte de la serrure came Page 16 - Bord fini Page 19 - Placez votre unit sur sa face avant * Glissez le panneau arri re dans les rainures des panneaux gauche et droit (A et B). * C t inachev * Alignez les trous de la partie inf rieure du panneau arri re avec les trous du rail arri re (H).
  • Page 48 Fran ais Page 26 - Une chelle est n cessaire pour cette tape. Ne pas s'appuyer sur la partie sup rieure de l'unit ; cela pourrait provoquer un affaissement. * Tout d'abord, assurez-vous que votre unit est toujours de niveau dans toutes les directions. * Percez des avant-trous de 3 mm (1/8 ) travers le panneau arri re sup rieur (F) et travers le longeron (G), au niveau des marques de rep rage des montants.
  • Page 49 Fran ais PAGE 39 Enregistrez votre produit pour recevoir les l ments suivantes: * D tails sur les nouvelles tendances - un aper u sur les nouveaut s * Sondages - avoir une voix au sein de notre communaut * Offres exclusives et codes promo * Service de pi ces de rechange rapide et facile Pour enregistrer votre produit, visitez ameriwoodhome.com 5 toiles...
