RETROFIRE FIXED SCREEN KIT
Model RA24ZC Zero Clearance Kit on the heater Model RF24BN/BP
The RA24FS Retrofire Fixed Screen Kit is used with the RA24ZC Zero Clearance kit installed in the model RF24B(N/P)
Retrofire B-Vent heater (see Assembly Overview below).
This kit requires the use of a cast fret and an outer trim listed in the RA24ZC instruction manual.
Kit Component
29-1/2"
4001109/01
RA24FS
INSTALLATION INSTRUCTIONS
CSA approved for use only with
Assembly Overview
INSTALLATION
1.
2.
23"
Outer Trim
Designed and Manufactured by
Miles Industries Ltd.
190 – 2255 Dollarton Highway, North Vancouver B.C, CANADA. V7H 3B1
Tel. (604) 984-3496 Fax (604) 984-0246
www.milesfireplaces.com
© Copyright Miles Industries Ltd., 2006
Unpack the kit.
Hook the screen
to the mounting
brackets of the
ZC box.
