Summary of Contents for IPR FlexiRun
-
Page 2: Important Note
Always check the correct tensioning of the curtain, correct it if necessary, using the two side guides, then finally secure the uprights. If the curtain does not descend and/or descends with difficulty, adjust the compression of the springs by decreasing the tension of the curtain. Installation, use and maintenance manual – FlexiRun® / Chill / Cold1... - Page 3 DRIVE SWITCH IS SET TO "OFF" IN ORDER TO AVOID ABRUPT AND CAUTION UNEXPECTED LIFTING OF THE CURTAIN WITH THE POSSIBILITY OF DAMAGE TO THE DOOR AND POSSIBLE RISKS TO OPERATORS IN THE VICINITY OF THE DOOR. Installation, use and maintenance manual – FlexiRun® / Chill / Cold1...
-
Page 4: Press Enter
Execute 4 complete open/close movement of the door to complete the process. During this phase is normal if the door doesn’t reach the limits set. Do not cross the photocells or trigger safety devices during this calibration. Installation, use and maintenance manual – FlexiRun® / Chill / Cold1... - Page 5 "3" according to the direction of rotation for end of stroke - slowing down closure. Clockwise Anti-clockwise C – Bring the curtain to approximately 60 cm from the maximum opening and adjust cam “2” according to the direction of rotation. Clockwise Anti-clockwise Installation, use and maintenance manual – FlexiRun® / Chill / Cold1...
- Page 6 This behaviour is normal and allows the electronics to make a control cycle on the IMPORTANT movements. NOTE Check with the second opening and second closing that the limit switch/encoder is working properly and that the fabric stops in the desired positions. Installation, use and maintenance manual – FlexiRun® / Chill / Cold1...
- Page 7 MOTOR GROUNDING BRAKE MOTOR - W MOTOR V MOTOR U MOTOR The machine's safety functions guarantee a Performance Level “c” in Category 2, according to EN ISO 13849- 1:2015. Installation, use and maintenance manual – FlexiRun® / Chill / Cold1...
- Page 8 BROWN BLACK BRAKE BRAKE GREY CABLE (SHIELDED) COLOUR FUNCTION GREEN/YELLOW GROUND+SHIELD GREY ISOLATE SHIELDING GREY WITH INSULATING GREY TAPE OR SEEVE BRAKE BRAKE Flashing light COLOUR FUNCTION L-230VAC N-230VAC Installation, use and maintenance manual – FlexiRun® / Chill / Cold1...
- Page 9 IPR - Italiana Porte Rapide BLACK CABLE Main connections (ENCODER) COLOUR FUNCTION BROWN STOP (NC) BROWN/WHITE BLUE +24VDC BLUE/WHITE ANTI-JAM (NC) RS485A RED/WHITE RS485B GREEN + SHIELD GREEN/WHITE +12VDC Installation, use and maintenance manual – FlexiRun® / Chill / Cold1...
- Page 10 Main connections (MECHANICAL LIMIT SWITCH) COLOUR FUNCTION BROWN STOP (NC) BROWN/WHITE BLUE +24VDC BLUE/WHITE ANTI-JAM (NC) GREEN/WHITE LIMIT OPEN (NC) LIMIT SLOW OPEN (NC) RED/WHITE LIMIT SLOW CLOSE (NC) GREEN Installation, use and maintenance manual – FlexiRun® / Chill / Cold1...
- Page 11 BLACK PHOTOCELL(NC) WHITE + BLUE COMMON CEDES light barriers BLACK CABLE – BLUE CONNECTOR COLOUR FUNCTION BROWN + GREY + +24VDC WHITE BLACK PHOTOCELL(NC) BLUE COMMON GREEN NOT CONNECTED Installation, use and maintenance manual – FlexiRun® / Chill / Cold1...
- Page 12 CAUTION In the interests of safety, it is necessary to train and inform the personnel using the machinery about its operation and any dangers arising from its use. Installation, use and maintenance manual – FlexiRun® / Chill / Cold1...
- Page 13 Allows you to choose the flashing mode between Lamp mode Wave WAVE, PULSE or FIXED Output mode Allows you to set the dry contact closure mode Limits 11-14 of pins 11-12-13-14 Installation, use and maintenance manual – FlexiRun® / Chill / Cold1...
- Page 14 CAUTION In the interests of safety, it is necessary to train and inform the personnel using the machinery about its operation and any dangers arising from its use. Installation, use and maintenance manual – FlexiRun® / Chill / Cold1...
- Page 15 Requires enabling parameter 24 – “Extra limit switch” in the controller's LEVEL 2 settings. Second open limit switch and anti jam position COMPONENTS: Anti jam sensors Second open limit switch CABLAGGI Wiring for second limit switch Installation, use and maintenance manual – FlexiRun® / Chill / Cold1...
- Page 16 Rev. 03 – nov-24 IPR - Italiana Porte Rapide Additional accessories connection BLACK CABLE Second open limit switch COLOUR FUNCTION BLUE COMMON BROWN-GREY- +24VDC WHITE BLACK LIMIT OPEN(NC) Installation, use and maintenance manual – FlexiRun® / Chill / Cold1...
