USER MANUAL
Please read the instructions carefully before using this product.
It is strictly prohibited to squeeze without the contact mold to avoid damaging the parts.
Technical Specification
Contact Mould(mm²)
AL
CU
Terminal
Terminal
10-50
4-70
Features and purpose
This product can automatically adjust pressure in all directions. It has stable contact and
pressing, low resistance, and high work efficiency. It is an ideal tool for contacting copper
and lead terminals, as well as connecting tubes used in cable conductors and other
power operations.
Operation Instructions
When compressing the cable, select the required size of cable and suitable contact mold.
Install the terminal in the middle of the contact mold, tighten the oil valve, and turn the
movable handle to start the plunger pump. When the hydraulic pressure increases, the
piston pushes the contact die forward until the two contact molds meet.
(After the two contact molds are in contact, do not continue to apply pressure to avoid
damaging the components.) If there is a pressure relief valve, when the specified
pressure is reached, a slight hissing sound will be heard, indicating that the internal
pressure has been automatically released and the work has been completed. Release
the oil valve, and the piston will automatically retract. Repeat the above operation, and
after repeated operation, it is normal to see slight oil stains on the exterior of the plunger
and large piston.
Repair and maintenance
This product has components that fit tightly together. Do not disassemble the
components. Avoid knocking on the tools and keeping them away from moisture.
After repeated use of this tool for a period of time, check the oil level in the reservoir of
the hand tool. Use #20 oil for replenishment. The refilled oil should be cleaned of dust
and gravel. Remove the fixed handle, pull out the rear oil plug from the oil tank, and add
No. 20 machine oil filtered through a 200-mesh filter until it overflows. Loosen the oil
valve and slowly turn the movable handle several times to release the air in the oil
reservoir. Replace the oil plug and tighten the fixed handle.
HYDRAULIC CRIMPING TOOL
Max
Max.
stroke
pressure
(mm)
(T)
6
12
Size of Contact Mould
(mm²)
4,6,10,16,25,35,50,70
TH2130
Hydraulic
Oil
#20
Mechanical
oil
