  • Page 1 & s m a r t e a s y C O N T R O L M O D U L E Bedienungsanleitung – Seite 2 Mode d‘emploi – page 12 Instructions for use – page 22 Instrucciones de uso – página 32 Istruzioni per l‘uso –...
  • Page 2: Scope Of Delivery

    Introduction Congratulations on the purchase of your Smart&Easy Control Module. With this module, in combination with your Automatic, you can control any function of your pool. The connected functions can be controlled either directly via your Automatic or conveniently via the Automatic app. Please be sure to follow the “Safety Instructions”...
  • Page 3: Installation

    Connections & Specifications The following table describes the connections and indicators: Number Designation Property 1, 2, 3, 4 4 x NO relays, potential-free Relay switching outputs: OUT 1 – 4 4 A / 230 V AC / 24 V DC 4 x Digital Relays: Variable Speed Pump (VSP) outputs...
  • Page 4 Electric connection of additional functions The following installation instructions provide an overview of the various connection options. Here, various examples are used to illustrate how the Smart&Easy Control Module is connected to the various electronic components. Important: It must be ensured that all safety regulations are complied with during the electrical installation and that all component- specific connection specifications are observed! To do this, carefully read the operating instructions of the devices to be connected and compare them with the technical data of the Smart&Easy Control Module.
  • Page 5 5.2 Frequency-controlled filter pump (VS pumps) General connection diagram for illustrative purposes: 230V AC + RCD (≤ 30 mA) Circuit breaker VSP Filter Pump Digital control cable of the filter pump Digital Inputs for the pump control cable A frequency-controlled pump is connected via the digital inputs exclusively designed for this purpose : Digital inputs: 150 mW / 35 V DC / 50 mA each The Smart&...
  • Page 6 5.2.1 Speck Badu ECO Applies to Speck BADU ECO (Touch, Touch-pro, Flow and 90 Eco VS) Connection table Connection Definition Wire color Smart&Easy Control Module Brown Green White High Stop Stop GND / common Black 5.2.2 Hayward VSTD Connection table Connection Definition Wire Color...
  • Page 7 5.3 Pool heating The following connection variants are supported by the Smart&Easy Control Module. To choose the right type of wiring, please consult the instructions for your heating system. A) Direct control of the heating system Controls the heating directly. Depending on the model, there is a separate input (terminal) dedicated to the remote control of the heat pump, where the switching cable from the Smart&Easy Control Module can be connected.
  • Page 8 5.4 Pool Lighting (Underwater Light) When installing a 12 V pool lighting, a transformer is required, which can be installed according to the following figure. 230V AC + RCS (≤ 30 mA) Circuit breaker Transformer for pool lighting Pool Lighting OUT 1 –...
  • Page 9 Initial commissioning and pairing with the Automatic device 1) Make sure your Automatic has the latest software installed. An update is carried out via USB stick (see the operating instructions of your Automatic). The latest version can be found on our Bayrol Technik support page: https://www.bayrol.de/bayrol-technik-support 2) As soon as the Smart&Easy Control Module-Icon...
  • Page 10: Function Configuration

    Function Configuration Once you have successfully connected your Smart&Easy Control Module, you can use the Smart&Easy Control Module icon to define your connected functions (pool equipment). → It is best to use the step-by-step instructions for the initial commissioning. 8.1 Filter Pump Use the toggle button to select whether you are using a frequency-controlled or single-stage filter pump.
  • Page 11: Disposal Instructions

    EN61000-4-6, EN61000-4-8, EN61000-4-11 Date, Manufacturer’s Signature: 01.03.2024 Signatory details: Lars Birckenstaedt, Managing Director BAYROL Group Note! UK CA Declaration of Conformity see page 52. Disposal instructions Disposal of electrical and electronic household appliances in the European Union All products marked with this symbol must not be disposed of with household waste after use. It is the user’s responsibility to dispose of this type of waste by dropping it off at a recycling point suitable for the selective disposal of electrical and electronic waste.
